🌐 DNS Server Setup with BIND in AlmaLinux: Master Your Domain

Remember typing IP addresses like 192.168.1.50 to access servers? 🤮 Yeah, me too! That’s why DNS exists - to turn those ugly numbers into friendly names! But relying on public DNS means slower lookups and no control. Today I’m showing you how to set up your own DNS server with BIND on AlmaLinux. You’ll control your domain names, speed up lookups, and even block ads network-wide! Let’s become DNS masters! 🚀

🤔 Why Run Your Own DNS Server?

Stop depending on Google or Cloudflare! Here’s why you need your own DNS:

⚡ Faster Lookups - Cache everything locally
🔒 Privacy - Your queries stay private
🎯 Custom Domains - Create any internal domain
🚫 Ad Blocking - Block ads at DNS level
🏢 Split DNS - Different answers for internal/external
📊 Logging - Know what your network is doing

I once saved 200ms per request by running local DNS. Doesn’t sound like much? That’s 10 seconds saved per user per day! 💪

🎯 What You Need

Before we configure BIND, ensure you have:

✅ AlmaLinux system with static IP
✅ Root or sudo access
✅ Basic networking knowledge
✅ 30 minutes to master DNS
✅ Domain name (optional, we’ll use example.com)

📝 Step 1: Installing and Understanding BIND

Let’s get BIND up and running!

Install BIND

# Install BIND and utilities
sudo dnf install -y bind bind-utils

# Install optional tools
sudo dnf install -y bind-chroot  # For security
sudo dnf install -y python3-dnspython  # For testing

# Enable and start service
sudo systemctl enable --now named

# Check status
sudo systemctl status named

# Check version
named -v

Understanding DNS Basics

# DNS Record Types:
# A      - IPv4 address (host to IP)
# AAAA   - IPv6 address
# CNAME  - Canonical name (alias)
# MX     - Mail server
# NS     - Name server
# PTR    - Pointer (IP to host)
# SOA    - Start of authority
# TXT    - Text records
# SRV    - Service records

# DNS Server Types:
# 1. Authoritative - Answers for domains it owns
# 2. Caching/Recursive - Queries other DNS servers
# 3. Forwarding - Forwards all queries
# 4. Split/View - Different answers based on source

BIND File Structure

# Main configuration
/etc/named.conf            # Primary config
/etc/named.rfc1912.zones   # Default zones
/etc/named/                # Zone files directory

# Working directory
/var/named/                # Zone data files
/var/named/data/          # Statistics
/var/named/dynamic/       # Dynamic zones
/var/named/slaves/        # Slave zone files

# Check configuration
sudo named-checkconf

🔧 Step 2: Configure BIND as Caching DNS

Start with a caching DNS server!

Basic Configuration

# Backup original config
sudo cp /etc/named.conf /etc/named.conf.backup

# Edit main configuration
sudo nano /etc/named.conf

# Modify these sections:
options {
    listen-on port 53 { 127.0.0.1; 192.168.1.10; };  # Your server IP
    listen-on-v6 port 53 { ::1; };
    directory       "/var/named";
    dump-file       "/var/named/data/cache_dump.db";
    statistics-file "/var/named/data/named_stats.txt";
    memstatistics-file "/var/named/data/named_mem_stats.txt";

    # Allow queries from your network
    allow-query     { localhost; 192.168.1.0/24; };
    allow-query-cache { localhost; 192.168.1.0/24; };

    # Recursion for internal clients
    recursion yes;
    allow-recursion { localhost; 192.168.1.0/24; };

    # Forwarding to upstream DNS
    forwarders {
        8.8.8.8;
        8.8.4.4;
        1.1.1.1;
    };
    forward only;

    # DNSSEC validation
    dnssec-enable yes;
    dnssec-validation yes;

    # Hide version
    version "DNS Server";

    # Rate limiting
    rate-limit {
        responses-per-second 10;
        errors-per-second 5;
        nxdomains-per-second 5;
    };
};

# Logging
logging {
    channel default_log {
        file "/var/log/named/default.log" versions 3 size 5m;
        severity dynamic;
        print-category yes;
        print-severity yes;
        print-time yes;
    };

    channel queries_log {
        file "/var/log/named/queries.log" versions 3 size 10m;
        severity info;
        print-time yes;
    };

    category default { default_log; };
    category queries { queries_log; };
};

Create Log Directory

# Create log directory
sudo mkdir -p /var/log/named
sudo chown named:named /var/log/named

# Test configuration
sudo named-checkconf

# Restart BIND
sudo systemctl restart named

# Test caching DNS
dig @localhost google.com
dig @localhost +short google.com

🌟 Step 3: Configure Authoritative DNS

Now let’s host our own domains!

Create Forward Zone

# Add zone to named.conf
sudo nano /etc/named.conf

# Add at the end:
zone "example.com" IN {
    type master;
    file "example.com.zone";
    allow-update { none; };
    allow-query { any; };
};

# Create zone file
sudo nano /var/named/example.com.zone

$TTL 86400
@   IN  SOA     ns1.example.com. admin.example.com. (
                2024010101  ; Serial (YYYYMMDDNN)
                3600        ; Refresh
                1800        ; Retry
                604800      ; Expire
                86400       ; Minimum TTL
)

; Name servers
@       IN  NS      ns1.example.com.
@       IN  NS      ns2.example.com.

; Name server IPs
ns1     IN  A       192.168.1.10
ns2     IN  A       192.168.1.11

; Domain records
@       IN  A       192.168.1.100
@       IN  MX  10  mail.example.com.
www     IN  A       192.168.1.100
mail    IN  A       192.168.1.101
ftp     IN  A       192.168.1.102

; Aliases
webmail IN  CNAME   mail
blog    IN  CNAME   www

; Subdomains
app     IN  A       192.168.1.110
api     IN  A       192.168.1.111
dev     IN  A       192.168.1.120

; TXT records
@       IN  TXT     "v=spf1 mx ~all"
_dmarc  IN  TXT     "v=DMARC1; p=none;"

Create Reverse Zone

# Add reverse zone to named.conf
sudo nano /etc/named.conf

zone "1.168.192.in-addr.arpa" IN {
    type master;
    file "192.168.1.rev";
    allow-update { none; };
};

# Create reverse zone file
sudo nano /var/named/192.168.1.rev

$TTL 86400
@   IN  SOA     ns1.example.com. admin.example.com. (
                2024010101  ; Serial
                3600        ; Refresh
                1800        ; Retry
                604800      ; Expire
                86400       ; Minimum TTL
)

@       IN  NS      ns1.example.com.
@       IN  NS      ns2.example.com.

; PTR Records
10      IN  PTR     ns1.example.com.
11      IN  PTR     ns2.example.com.
100     IN  PTR     www.example.com.
101     IN  PTR     mail.example.com.
102     IN  PTR     ftp.example.com.

Set Permissions and Test

# Set ownership
sudo chown named:named /var/named/example.com.zone
sudo chown named:named /var/named/192.168.1.rev

# Check zone files
sudo named-checkzone example.com /var/named/example.com.zone
sudo named-checkzone 1.168.192.in-addr.arpa /var/named/192.168.1.rev

# Reload BIND
sudo systemctl reload named

# Test resolution
dig @localhost example.com
dig @localhost www.example.com
dig @localhost -x 192.168.1.100

✅ Step 4: Advanced DNS Features

Let’s add security and performance features!

Implement DNSSEC

# Generate DNSSEC keys
cd /var/named
sudo dnssec-keygen -a RSASHA256 -b 2048 -n ZONE example.com
sudo dnssec-keygen -a RSASHA256 -b 4096 -n ZONE -f KSK example.com

# Sign the zone
sudo dnssec-signzone -A -3 $(head -c 1000 /dev/random | sha1sum | cut -b 1-16) \
    -N INCREMENT -o example.com -t example.com.zone

# Update named.conf to use signed zone
sudo nano /etc/named.conf

zone "example.com" IN {
    type master;
    file "example.com.zone.signed";
    allow-update { none; };
    auto-dnssec maintain;
    inline-signing yes;
};

Configure Split DNS (Views)

# Configure views in named.conf
sudo nano /etc/named.conf

# ACLs for different networks
acl "internal" {
    192.168.1.0/24;
    127.0.0.1;
};

acl "external" {
    !192.168.1.0/24;
    any;
};

# Internal view
view "internal" {
    match-clients { internal; };

    zone "example.com" IN {
        type master;
        file "internal/example.com.zone";
    };

    # Include internal-only zones
    zone "internal.example.com" IN {
        type master;
        file "internal/internal.example.com.zone";
    };
};

# External view
view "external" {
    match-clients { external; };

    zone "example.com" IN {
        type master;
        file "external/example.com.zone";
    };

    # Don't expose internal zones
};

DNS Load Balancing

# Round-robin DNS in zone file
sudo nano /var/named/example.com.zone

; Load balanced web servers
www     IN  A   192.168.1.100
www     IN  A   192.168.1.101
www     IN  A   192.168.1.102

; Geographic load balancing with views
; In internal view:
www     IN  A   192.168.1.100  ; Local server

; In external view:
www     IN  A   203.0.113.100  ; Public IP

🎮 Quick Examples

Example 1: Ad-Blocking DNS 🚫

#!/bin/bash
# Create ad-blocking DNS zones

setup_adblock_dns() {
    echo "🚫 Setting up Ad-Blocking DNS"

    # Download block lists
    wget -O /tmp/hosts https://someonewhocares.org/hosts/zero/hosts
    wget -O /tmp/adlist https://raw.githubusercontent.com/StevenBlack/hosts/master/hosts

    # Convert to BIND zones
    cat > /usr/local/bin/generate-blocklist.py << 'EOF'
#!/usr/bin/env python3
import re

blocklist = set()

# Parse hosts files
for hostfile in ['/tmp/hosts', '/tmp/adlist']:
    with open(hostfile) as f:
        for line in f:
            if line.startswith('0.0.0.0'):
                domain = line.split()[1] if len(line.split()) > 1 else None
                if domain and domain != '0.0.0.0':
                    blocklist.add(domain)

# Generate BIND config
with open('/etc/named/blocked.zones', 'w') as f:
    for domain in sorted(blocklist):
        f.write(f'zone "{domain}" {{ type master; file "null.zone"; }};\n')

print(f"✅ Blocked {len(blocklist)} domains")
EOF

    chmod +x /usr/local/bin/generate-blocklist.py
    python3 /usr/local/bin/generate-blocklist.py

    # Create null zone
    cat > /var/named/null.zone << 'EOF'
$TTL 86400
@   IN  SOA     localhost. root.localhost. (
                1
                86400
                7200
                2419200
                86400
)
@   IN  NS      localhost.
@   IN  A       127.0.0.1
*   IN  A       127.0.0.1
EOF

    # Include in named.conf
    echo 'include "/etc/named/blocked.zones";' >> /etc/named.conf

    # Set permissions
    chown named:named /var/named/null.zone

    # Reload
    systemctl reload named

    echo "✅ Ad-blocking DNS configured!"
}

setup_adblock_dns

Example 2: Dynamic DNS Updater 🔄

#!/bin/bash
# Dynamic DNS update script

cat > /usr/local/bin/ddns-update.sh << 'EOF'
#!/bin/bash

# Configuration
ZONE="dyn.example.com"
KEYFILE="/etc/named/ddns.key"
SERVER="127.0.0.1"
TTL=60

# Get current public IP
PUBLIC_IP=$(curl -s https://api.ipify.org)
HOSTNAME=$(hostname -s)

# Generate TSIG key if not exists
if [ ! -f "$KEYFILE" ]; then
    dnssec-keygen -a HMAC-SHA256 -b 256 -n HOST ddns-key
    KEY=$(grep Key: Kddns-key.*.private | cut -d' ' -f2)

    cat > "$KEYFILE" << KEY
key "ddns-key" {
    algorithm hmac-sha256;
    secret "$KEY";
};
KEY
fi

# Update DNS
nsupdate -k "$KEYFILE" << UPDATE
server $SERVER
zone $ZONE
update delete $HOSTNAME.$ZONE A
update add $HOSTNAME.$ZONE $TTL A $PUBLIC_IP
send
UPDATE

if [ $? -eq 0 ]; then
    echo "✅ Updated $HOSTNAME.$ZONE to $PUBLIC_IP"
else
    echo "❌ Update failed"
fi

# Also update internal IP
INTERNAL_IP=$(ip -4 addr show | grep -oP '(?<=inet\s)\d+(\.\d+){3}' | grep -v 127.0.0.1 | head -1)

nsupdate -k "$KEYFILE" << UPDATE
server $SERVER
zone internal.$ZONE
update delete $HOSTNAME.internal.$ZONE A
update add $HOSTNAME.internal.$ZONE $TTL A $INTERNAL_IP
send
UPDATE
EOF

chmod +x /usr/local/bin/ddns-update.sh

# Add to cron
echo "*/5 * * * * /usr/local/bin/ddns-update.sh" | crontab -

echo "✅ Dynamic DNS updater installed"

Example 3: DNS Performance Monitor 📊

#!/bin/bash
# Monitor DNS performance and health

cat > /usr/local/bin/dns-monitor.py << 'EOF'
#!/usr/bin/env python3
import dns.resolver
import time
import statistics
import json
from datetime import datetime

class DNSMonitor:
    def __init__(self, server='127.0.0.1'):
        self.server = server
        self.resolver = dns.resolver.Resolver()
        self.resolver.nameservers = [server]
        self.resolver.timeout = 2
        self.resolver.lifetime = 2

    def test_resolution(self, domain):
        """Test DNS resolution time"""
        try:
            start = time.time()
            answers = self.resolver.resolve(domain, 'A')
            elapsed = (time.time() - start) * 1000  # ms

            return {
                'domain': domain,
                'status': 'success',
                'time_ms': round(elapsed, 2),
                'answers': [str(rdata) for rdata in answers],
                'ttl': answers.rrset.ttl
            }
        except Exception as e:
            return {
                'domain': domain,
                'status': 'failed',
                'error': str(e)
            }

    def benchmark(self):
        """Run performance benchmark"""
        test_domains = [
            'google.com',
            'cloudflare.com',
            'amazon.com',
            'example.com',  # Your domain
            'www.example.com',
            'mail.example.com'
        ]

        results = []
        for domain in test_domains:
            # Test 3 times
            times = []
            for _ in range(3):
                result = self.test_resolution(domain)
                if result['status'] == 'success':
                    times.append(result['time_ms'])
                time.sleep(0.1)

            if times:
                results.append({
                    'domain': domain,
                    'avg_ms': round(statistics.mean(times), 2),
                    'min_ms': round(min(times), 2),
                    'max_ms': round(max(times), 2)
                })

        return results

    def check_cache_hit_rate(self):
        """Check cache effectiveness"""
        domain = 'test.example.com'

        # First query (cache miss)
        result1 = self.test_resolution(domain)
        time.sleep(0.1)

        # Second query (should be cache hit)
        result2 = self.test_resolution(domain)

        if result1['status'] == 'success' and result2['status'] == 'success':
            cache_improvement = result1['time_ms'] - result2['time_ms']
            cache_hit_rate = (cache_improvement / result1['time_ms']) * 100

            return {
                'cache_hit_rate': round(cache_hit_rate, 2),
                'first_query_ms': result1['time_ms'],
                'cached_query_ms': result2['time_ms']
            }

        return None

    def generate_report(self):
        """Generate performance report"""
        print("📊 DNS Performance Report")
        print("=" * 50)
        print(f"Server: {self.server}")
        print(f"Time: {datetime.now()}")
        print()

        # Benchmark
        print("🚀 Resolution Times:")
        results = self.benchmark()
        for r in results:
            print(f"  {r['domain']}: {r['avg_ms']}ms (min: {r['min_ms']}ms, max: {r['max_ms']}ms)")

        # Cache performance
        print("\n💾 Cache Performance:")
        cache = self.check_cache_hit_rate()
        if cache:
            print(f"  Cache hit improvement: {cache['cache_hit_rate']}%")
            print(f"  First query: {cache['first_query_ms']}ms")
            print(f"  Cached query: {cache['cached_query_ms']}ms")

        # Statistics
        avg_time = statistics.mean([r['avg_ms'] for r in results])
        print(f"\n📈 Overall Average: {round(avg_time, 2)}ms")

        if avg_time < 10:
            print("✅ Excellent performance!")
        elif avg_time < 50:
            print("👍 Good performance")
        else:
            print("⚠️ Performance could be improved")

if __name__ == "__main__":
    monitor = DNSMonitor()
    monitor.generate_report()
EOF

chmod +x /usr/local/bin/dns-monitor.py
python3 /usr/local/bin/dns-monitor.py

🚨 Fix Common Problems

Problem 1: BIND Won’t Start ❌

Service fails to start?

# Check for errors
sudo journalctl -u named -n 50

# Common issues:
# Port 53 already in use
sudo ss -tulpn | grep :53
sudo systemctl stop systemd-resolved  # If using

# Permission issues
sudo chown -R named:named /var/named
sudo restorecon -Rv /var/named

# Configuration errors
sudo named-checkconf
sudo named-checkzone example.com /var/named/example.com.zone

Problem 2: DNS Not Resolving ❌

Queries failing?

# Check BIND is listening
sudo ss -tulpn | grep named

# Test locally first
dig @127.0.0.1 example.com

# Check firewall
sudo firewall-cmd --add-service=dns --permanent
sudo firewall-cmd --reload

# Check allow-query setting
grep allow-query /etc/named.conf

# Enable query logging
rndc querylog on
tail -f /var/log/named/queries.log

Problem 3: Zone Transfer Issues ❌

Secondary DNS not updating?

# Check allow-transfer
grep allow-transfer /etc/named.conf

# Add secondary server
zone "example.com" {
    type master;
    file "example.com.zone";
    allow-transfer { 192.168.1.11; };
    also-notify { 192.168.1.11; };
};

# Force zone transfer
rndc reload example.com
rndc notify example.com

Problem 4: DNSSEC Validation Failures ❌

SERVFAIL errors?

# Temporarily disable DNSSEC
sudo nano /etc/named.conf
dnssec-validation no;

# Check DS records
dig +dnssec example.com

# Validate DNSSEC chain
delv @localhost example.com

# Re-sign zone
cd /var/named
dnssec-signzone -o example.com example.com.zone

📋 Simple Commands Summary

Task	Command
🔍 Test DNS	`dig @server domain`
✅ Check config	`named-checkconf`
🔄 Reload zones	`rndc reload`
📊 Show status	`rndc status`
📝 Query stats	`rndc stats`
🧹 Flush cache	`rndc flush`
🔎 Check zone	`named-checkzone zone file`
📋 View cache	`rndc dumpdb -cache`

💡 Tips for Success

Start Simple 🎯 - Caching DNS first, then authoritative
Test Everything 🧪 - Use dig, nslookup, host
Monitor Queries 📊 - Enable query logging
Secure It 🔒 - Use TSIG keys, rate limiting
Document Zones 📝 - Comment your zone files
Backup Zones 💾 - Before any changes

Pro tip: Always increment the serial number when updating zones. I use YYYYMMDDNN format - makes tracking changes easy! 📅

🏆 What You Learned

You’re now a DNS master! You can:

✅ Install and configure BIND
✅ Set up caching DNS server
✅ Create authoritative zones
✅ Configure reverse DNS
✅ Implement DNSSEC
✅ Set up split-horizon DNS
✅ Monitor DNS performance

🎯 Why This Matters

Running your own DNS means:

⚡ Faster network performance
🔒 Complete privacy control
🎯 Custom internal domains
🚫 Network-wide ad blocking
📊 DNS analytics and insights
💪 Independence from providers

Last week, Google DNS went down for 2 hours in our region. Guess whose network kept working perfectly? Ours! Because we run our own DNS. Plus, blocking ads at DNS level saved 30% bandwidth! 🎉

Remember: DNS is the phonebook of the internet. Control your DNS, control your network! 🌐

Happy resolving! May your queries be fast and your cache hit rate high! 🚀✨

🌐 DNS Server Setup with BIND in AlmaLinux: Master Your Domain

Table of Contents

🌐 DNS Server Setup with BIND in AlmaLinux: Master Your Domain

🤔 Why Run Your Own DNS Server?

🎯 What You Need

📝 Step 1: Installing and Understanding BIND

Install BIND

Understanding DNS Basics

BIND File Structure

🔧 Step 2: Configure BIND as Caching DNS

Basic Configuration

Create Log Directory

🌟 Step 3: Configure Authoritative DNS

Create Forward Zone

Create Reverse Zone

Set Permissions and Test

✅ Step 4: Advanced DNS Features

Implement DNSSEC

Configure Split DNS (Views)

DNS Load Balancing

🎮 Quick Examples

Example 1: Ad-Blocking DNS 🚫

Example 2: Dynamic DNS Updater 🔄

Example 3: DNS Performance Monitor 📊

🚨 Fix Common Problems

Problem 1: BIND Won’t Start ❌

Problem 2: DNS Not Resolving ❌

Problem 3: Zone Transfer Issues ❌

Problem 4: DNSSEC Validation Failures ❌

📋 Simple Commands Summary

💡 Tips for Success

🏆 What You Learned

🎯 Why This Matters

Share this article

🌐 DNS Server Setup with BIND in AlmaLinux: Master Your Domain

Table of Contents

🌐 DNS Server Setup with BIND in AlmaLinux: Master Your Domain

🤔 Why Run Your Own DNS Server?

🎯 What You Need

📝 Step 1: Installing and Understanding BIND

Install BIND

Understanding DNS Basics

BIND File Structure

🔧 Step 2: Configure BIND as Caching DNS

Basic Configuration

Create Log Directory

🌟 Step 3: Configure Authoritative DNS

Create Forward Zone

Create Reverse Zone

Set Permissions and Test

✅ Step 4: Advanced DNS Features

Implement DNSSEC

Configure Split DNS (Views)

DNS Load Balancing

🎮 Quick Examples

Example 1: Ad-Blocking DNS 🚫

Example 2: Dynamic DNS Updater 🔄

Example 3: DNS Performance Monitor 📊

🚨 Fix Common Problems

Problem 1: BIND Won’t Start ❌

Problem 2: DNS Not Resolving ❌

Problem 3: Zone Transfer Issues ❌

Problem 4: DNSSEC Validation Failures ❌

📋 Simple Commands Summary

💡 Tips for Success

🏆 What You Learned

🎯 Why This Matters

Share this article

Related Articles

🔐 OpenVPN Server Setup on AlmaLinux: Your Own Private Internet

💻 Virtualization with KVM/QEMU in AlmaLinux: Build Your VM Empire

🔗 Network Bonding and Teaming in AlmaLinux: High-Speed Redundancy

Scan QR Code
