🔄 Managing Service Failover: Simple Guide

Let me show you how to set up service failover in Alpine Linux! This ensures your services keep running even when things go wrong. It’s like having a backup plan for your important services!

🤔 What is Service Failover?

Service failover automatically switches to a backup service when the main one fails. Think of it like having a spare tire - when the main tire goes flat, you can quickly switch to the spare and keep driving. In Alpine Linux, we can set this up easily!

Why use failover?

• Keep services running 24/7
• Minimize downtime
• Automatic recovery
• Better reliability
• Peace of mind

🎯 What You Need

Before starting, you’ll need:

• Two Alpine Linux servers
• Network connectivity between them
• A service to protect (like nginx)
• Basic terminal knowledge
• About 20 minutes

📋 Step 1: Install Monitoring Tools

First, let’s install what we need:

# On both servers
apk update

# Install keepalived for failover
apk add keepalived

# Install monitoring tools
apk add monit

# Install networking tools
apk add ipvsadm iproute2

# Enable services
rc-update add keepalived
rc-update add monit

📋 Step 2: Configure Primary Server

Set up the main server:

# Create keepalived config
cat > /etc/keepalived/keepalived.conf << 'EOF'
global_defs {
    router_id SERVER1
    script_user root
    enable_script_security
}

vrrp_script check_service {
    script "/usr/local/bin/check_service.sh"
    interval 2
    weight 2
}

vrrp_instance VI_1 {
    state MASTER
    interface eth0
    virtual_router_id 51
    priority 100
    advert_int 1

    authentication {
        auth_type PASS
        auth_pass alpine123
    }

    virtual_ipaddress {
        192.168.1.100/24
    }

    track_script {
        check_service
    }

    notify_master "/usr/local/bin/notify_master.sh"
    notify_backup "/usr/local/bin/notify_backup.sh"
    notify_fault "/usr/local/bin/notify_fault.sh"
}
EOF

# Create service check script
cat > /usr/local/bin/check_service.sh << 'EOF'
#!/bin/sh
# Check if nginx is running
if pgrep nginx > /dev/null; then
    exit 0
else
    exit 1
fi
EOF

chmod +x /usr/local/bin/check_service.sh

📋 Step 3: Configure Backup Server

Set up the backup server:

# Create keepalived config (on backup server)
cat > /etc/keepalived/keepalived.conf << 'EOF'
global_defs {
    router_id SERVER2
    script_user root
    enable_script_security
}

vrrp_script check_service {
    script "/usr/local/bin/check_service.sh"
    interval 2
    weight 2
}

vrrp_instance VI_1 {
    state BACKUP
    interface eth0
    virtual_router_id 51
    priority 90
    advert_int 1

    authentication {
        auth_type PASS
        auth_pass alpine123
    }

    virtual_ipaddress {
        192.168.1.100/24
    }

    track_script {
        check_service
    }

    notify_master "/usr/local/bin/notify_master.sh"
    notify_backup "/usr/local/bin/notify_backup.sh"
    notify_fault "/usr/local/bin/notify_fault.sh"
}
EOF

# Copy check script from primary
# (Same as primary server)

📋 Step 4: Create Notification Scripts

Set up alerts when failover happens:

# Master notification script
cat > /usr/local/bin/notify_master.sh << 'EOF'
#!/bin/sh
echo "$(date): Became MASTER" >> /var/log/keepalived-state.log
# Start services if needed
rc-service nginx start
EOF

# Backup notification script
cat > /usr/local/bin/notify_backup.sh << 'EOF'
#!/bin/sh
echo "$(date): Became BACKUP" >> /var/log/keepalived-state.log
# Optional: Stop non-critical services
EOF

# Fault notification script
cat > /usr/local/bin/notify_fault.sh << 'EOF'
#!/bin/sh
echo "$(date): FAULT detected" >> /var/log/keepalived-state.log
# Alert admin
logger "Keepalived FAULT state detected!"
EOF

# Make scripts executable
chmod +x /usr/local/bin/notify_*.sh

📋 Step 5: Configure Service Monitoring

Set up Monit to restart failed services:

# Configure Monit
cat > /etc/monitrc << 'EOF'
set daemon 30
set log /var/log/monit.log

set httpd port 2812 and
    use address localhost
    allow localhost
    allow admin:monit

check process nginx with pidfile /run/nginx.pid
    start program = "/etc/init.d/nginx start"
    stop program = "/etc/init.d/nginx stop"
    if failed host 127.0.0.1 port 80 protocol http then restart
    if 3 restarts within 5 cycles then unmonitor

check process keepalived with pidfile /run/keepalived.pid
    start program = "/etc/init.d/keepalived start"
    stop program = "/etc/init.d/keepalived stop"
    if 3 restarts within 5 cycles then unmonitor

check system $HOST
    if loadavg (1min) > 4 then alert
    if loadavg (5min) > 2 then alert
    if cpu usage > 95% for 10 cycles then alert
    if memory usage > 75% then alert
EOF

chmod 600 /etc/monitrc

📋 Step 6: Test Basic Failover

Let’s test if failover works:

# Start services on both servers
rc-service keepalived start
rc-service monit start
rc-service nginx start

# Check virtual IP (on primary)
ip addr show | grep 192.168.1.100

# Test failover
# On primary server:
rc-service nginx stop

# Check if IP moved to backup
# On backup server:
ip addr show | grep 192.168.1.100

# Verify in logs
tail -f /var/log/keepalived-state.log

📋 Step 7: Advanced Configuration

Add more sophisticated checks:

# Enhanced service check
cat > /usr/local/bin/check_service_advanced.sh << 'EOF'
#!/bin/sh
# Multiple service checks

# Check nginx
curl -f -s -o /dev/null http://localhost || exit 1

# Check disk space
DISK_USAGE=$(df / | awk 'NR==2 {print $5}' | sed 's/%//')
[ $DISK_USAGE -gt 90 ] && exit 1

# Check load average
LOAD=$(cat /proc/loadavg | awk '{print $1}' | cut -d. -f1)
[ $LOAD -gt 10 ] && exit 1

# All checks passed
exit 0
EOF

chmod +x /usr/local/bin/check_service_advanced.sh

# Update keepalived to use advanced check
sed -i 's/check_service.sh/check_service_advanced.sh/g' /etc/keepalived/keepalived.conf

📋 Step 8: Set Up Split-Brain Prevention

Prevent both servers from becoming master:

# Add fencing script
cat > /usr/local/bin/fence_peer.sh << 'EOF'
#!/bin/sh
# Simple fencing to prevent split-brain

PEER_IP="192.168.1.2"  # Other server's IP
VIP="192.168.1.100"

# Check if peer is responding
ping -c 1 -W 1 $PEER_IP > /dev/null 2>&1
PEER_ALIVE=$?

# Check if peer has VIP
ssh -o ConnectTimeout=2 root@$PEER_IP "ip addr show | grep -q $VIP" 2>/dev/null
PEER_HAS_VIP=$?

if [ $PEER_ALIVE -eq 0 ] && [ $PEER_HAS_VIP -eq 0 ]; then
    # Peer is alive and has VIP, we should be backup
    echo "Peer has VIP, staying as backup"
    exit 1
fi

exit 0
EOF

chmod +x /usr/local/bin/fence_peer.sh

🎮 Practice Exercise

Try this failover scenario:

1. Set up two test services
2. Configure failover between them
3. Test different failure modes
4. Monitor the results

# Practice setup
# Create test service
cat > /usr/local/bin/test_service.sh << 'EOF'
#!/bin/sh
while true; do
    echo "Service running on $(hostname)" > /tmp/service.status
    sleep 1
done
EOF

chmod +x /usr/local/bin/test_service.sh

# Add to monit
echo "
check process test_service matching test_service.sh
    start program = '/usr/local/bin/test_service.sh &'
    stop program = 'pkill -f test_service.sh'
" >> /etc/monitrc

🚨 Troubleshooting Common Issues

Failover Not Working

Check these common problems:

# Verify keepalived is running
ps aux | grep keepalived

# Check configuration syntax
keepalived -t

# Look for errors
tail -f /var/log/messages | grep keepalived

# Test network connectivity
ping -c 3 <other_server_ip>

# Check firewall rules
iptables -L -n | grep vrrp

Split-Brain Situation

Fix when both servers think they’re master:

# Check who has VIP
ip addr show | grep 192.168.1.100

# Force one to backup
rc-service keepalived restart

# Check VRRP communication
tcpdump -i eth0 -n vrrp

# Verify passwords match
grep auth_pass /etc/keepalived/keepalived.conf

Service Won’t Restart

Debug service monitoring:

# Check monit status
monit status

# Test service manually
/etc/init.d/nginx restart

# Check monit logs
tail -f /var/log/monit.log

# Validate monit config
monit -t

💡 Pro Tips

Tip 1: Email Alerts

Set up email notifications:

# Add to notify scripts
cat >> /usr/local/bin/notify_master.sh << 'EOF'
# Send email alert
echo "Server $(hostname) is now MASTER" | \
    mail -s "Failover Alert" [email protected]
EOF

Tip 2: Multiple Virtual IPs

Handle multiple services:

# Add more VIPs in keepalived.conf
virtual_ipaddress {
    192.168.1.100/24
    192.168.1.101/24
    192.168.1.102/24
}

Tip 3: Priority Tuning

Adjust failover sensitivity:

# In keepalived.conf
vrrp_instance VI_1 {
    # Faster failover
    advert_int 1

    # Preempt settings
    preempt_delay 30

    # Priority adjustment
    priority 100  # Higher = preferred master
}

✅ Monitoring Dashboard

Create a simple status page:

# Status check script
cat > /var/www/localhost/htdocs/status.html << 'EOF'
<!DOCTYPE html>
<html>
<head>
    <title>Failover Status</title>
    <meta http-equiv="refresh" content="5">
</head>
<body>
    <h1>Service Failover Status</h1>
    <pre id="status"></pre>
    <script>
    fetch('/status.txt')
        .then(r => r.text())
        .then(t => document.getElementById('status').textContent = t);
    </script>
</body>
</html>
EOF

# Generate status file
cat > /usr/local/bin/update_status.sh << 'EOF'
#!/bin/sh
{
    echo "Generated: $(date)"
    echo "Hostname: $(hostname)"
    echo "Keepalived: $(rc-status | grep keepalived)"
    echo "Virtual IPs:"
    ip addr show | grep "inet.*scope global"
    echo "Service Status:"
    rc-status
} > /var/www/localhost/htdocs/status.txt
EOF

chmod +x /usr/local/bin/update_status.sh

# Add to cron
echo "* * * * * /usr/local/bin/update_status.sh" | crontab -

🏆 What You Learned

Excellent work! You can now:

• ✅ Set up keepalived for failover
• ✅ Configure service monitoring
• ✅ Handle automatic failover
• ✅ Prevent split-brain issues
• ✅ Monitor failover status

Your services are now highly available!

🎯 What’s Next?

Now that you have failover working, explore:

• Load balancing with HAProxy
• Database replication
• Clustered file systems
• Advanced monitoring with Prometheus

Keep your services running 24/7! 🔄
