Running Kubernetes on AlmaLinux 9: Production-Ready Container Orchestration 🚢

Kubernetes has become the de facto standard for container orchestration, and AlmaLinux 9 provides an excellent, enterprise-grade foundation for running production Kubernetes clusters. This comprehensive guide walks you through deploying Kubernetes on AlmaLinux 9, from single-node development environments to multi-node production clusters, covering networking, storage, security, and real-world application deployment.

🌟 Why Kubernetes on AlmaLinux 9?

The combination of Kubernetes and AlmaLinux 9 offers a powerful platform for modern containerized applications, bringing together enterprise stability with cutting-edge container orchestration capabilities.

Key Advantages

Enterprise Stability - AlmaLinux 9’s RHEL compatibility ensures production-grade reliability 🏢
Long-term Support - AlmaLinux 9 supported until 2032, perfect for Kubernetes LTS 📅
Cost-Effective - No licensing fees while maintaining enterprise features 💰
Container-Optimized - Modern kernel with advanced container features 🐳
Security-First - SELinux integration with Kubernetes security policies 🔒

📋 Prerequisites and System Requirements

Hardware Requirements

# Minimum Requirements (Development)
- Control Plane: 2 CPU cores, 2 GB RAM, 20 GB storage
- Worker Nodes: 1 CPU core, 1 GB RAM, 20 GB storage

# Recommended Production Requirements
- Control Plane: 4 CPU cores, 8 GB RAM, 100 GB SSD
- Worker Nodes: 4 CPU cores, 16 GB RAM, 200 GB SSD
- Network: 1 Gbps minimum, 10 Gbps recommended

Network Planning

# Example Network Layout
- Pod Network: 10.244.0.0/16
- Service Network: 10.96.0.0/12
- Node Network: 192.168.1.0/24
- External Load Balancer: 192.168.1.10

🔧 Preparing AlmaLinux 9 for Kubernetes

System Preparation

# Update system
sudo dnf update -y

# Install essential packages
sudo dnf install -y \
  curl \
  wget \
  vim \
  git \
  net-tools \
  bridge-utils \
  bash-completion \
  yum-utils \
  device-mapper-persistent-data \
  lvm2

# Set hostname (on each node)
sudo hostnamectl set-hostname k8s-master-01  # On master
sudo hostnamectl set-hostname k8s-worker-01  # On worker nodes

Configure System Settings

# Disable swap (Kubernetes requirement)
sudo swapoff -a
sudo sed -i '/ swap / s/^/#/' /etc/fstab

# Configure kernel modules
cat <<EOF | sudo tee /etc/modules-load.d/k8s.conf
overlay
br_netfilter
EOF

sudo modprobe overlay
sudo modprobe br_netfilter

# Configure sysctl settings
cat <<EOF | sudo tee /etc/sysctl.d/k8s.conf
net.bridge.bridge-nf-call-iptables  = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward                 = 1
EOF

sudo sysctl --system

Configure Firewall

# Master node firewall rules
sudo firewall-cmd --permanent --add-port=6443/tcp       # Kubernetes API server
sudo firewall-cmd --permanent --add-port=2379-2380/tcp  # etcd server client API
sudo firewall-cmd --permanent --add-port=10250/tcp      # Kubelet API
sudo firewall-cmd --permanent --add-port=10259/tcp      # kube-scheduler
sudo firewall-cmd --permanent --add-port=10257/tcp      # kube-controller-manager
sudo firewall-cmd --permanent --add-port=30000-32767/tcp # NodePort Services

# Worker node firewall rules
sudo firewall-cmd --permanent --add-port=10250/tcp      # Kubelet API
sudo firewall-cmd --permanent --add-port=30000-32767/tcp # NodePort Services

# Calico networking (if using Calico)
sudo firewall-cmd --permanent --add-port=179/tcp        # BGP
sudo firewall-cmd --permanent --add-port=4789/udp       # VXLAN

sudo firewall-cmd --reload

Configure SELinux

# Set SELinux to permissive mode (for initial setup)
sudo setenforce 0
sudo sed -i 's/^SELINUX=enforcing$/SELINUX=permissive/' /etc/selinux/config

# Install SELinux utilities for Kubernetes
sudo dnf install -y container-selinux

🐳 Installing Container Runtime

Option 1: containerd (Recommended)

# Install containerd
sudo dnf config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo
sudo dnf install -y containerd.io

# Configure containerd
sudo mkdir -p /etc/containerd
sudo containerd config default | sudo tee /etc/containerd/config.toml

# Configure SystemdCgroup
sudo sed -i 's/SystemdCgroup = false/SystemdCgroup = true/g' /etc/containerd/config.toml

# Start and enable containerd
sudo systemctl enable --now containerd

Option 2: CRI-O

# Define versions
OS=CentOS_9_Stream
VERSION=1.28

# Add CRI-O repository
sudo curl -L -o /etc/yum.repos.d/devel:kubic:libcontainers:stable.repo https://download.opensuse.org/repositories/devel:/kubic:/libcontainers:/stable/$OS/devel:kubic:libcontainers:stable.repo
sudo curl -L -o /etc/yum.repos.d/devel:kubic:libcontainers:stable:cri-o:$VERSION.repo https://download.opensuse.org/repositories/devel:kubic:libcontainers:stable:cri-o:$VERSION/$OS/devel:kubic:libcontainers:stable:cri-o:$VERSION.repo

# Install CRI-O
sudo dnf install -y cri-o

# Start and enable CRI-O
sudo systemctl enable --now crio

📦 Installing Kubernetes Components

Add Kubernetes Repository

# Add Kubernetes repository
cat <<EOF | sudo tee /etc/yum.repos.d/kubernetes.repo
[kubernetes]
name=Kubernetes
baseurl=https://packages.cloud.google.com/yum/repos/kubernetes-el7-\$basearch
enabled=1
gpgcheck=1
gpgkey=https://packages.cloud.google.com/yum/doc/rpm-package-key.gpg
exclude=kubelet kubeadm kubectl
EOF

# Install Kubernetes components
sudo dnf install -y kubelet kubeadm kubectl --disableexcludes=kubernetes

# Enable kubelet
sudo systemctl enable --now kubelet

Configure crictl (Container Runtime Interface)

# Configure crictl
cat <<EOF | sudo tee /etc/crictl.yaml
runtime-endpoint: unix:///var/run/containerd/containerd.sock
image-endpoint: unix:///var/run/containerd/containerd.sock
timeout: 2
debug: false
pull-image-on-create: false
EOF

🚀 Initializing Kubernetes Cluster

Initialize Master Node

# Initialize cluster with kubeadm
sudo kubeadm init \
  --pod-network-cidr=10.244.0.0/16 \
  --service-cidr=10.96.0.0/12 \
  --control-plane-endpoint=k8s-master-01:6443 \
  --upload-certs

# Configure kubectl for regular user
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

# Enable kubectl autocompletion
echo 'source <(kubectl completion bash)' >> ~/.bashrc
echo 'alias k=kubectl' >> ~/.bashrc
echo 'complete -o default -F __start_kubectl k' >> ~/.bashrc
source ~/.bashrc

Install Network Plugin

Option 1: Calico (Recommended for Production)

# Install Calico
kubectl create -f https://raw.githubusercontent.com/projectcalico/calico/v3.26.1/manifests/tigera-operator.yaml

# Create Calico custom resource
cat <<EOF | kubectl create -f -
apiVersion: operator.tigera.io/v1
kind: Installation
metadata:
  name: default
spec:
  calicoNetwork:
    ipPools:
    - blockSize: 26
      cidr: 10.244.0.0/16
      encapsulation: VXLANCrossSubnet
      natOutgoing: Enabled
      nodeSelector: all()
---
apiVersion: operator.tigera.io/v1
kind: APIServer
metadata:
  name: default
spec: {}
EOF

# Verify Calico installation
kubectl get pods -n calico-system

Option 2: Flannel (Simple Alternative)

# Install Flannel
kubectl apply -f https://github.com/flannel-io/flannel/releases/latest/download/kube-flannel.yml

# Verify Flannel installation
kubectl get pods -n kube-flannel

Join Worker Nodes

# On master node, generate join command
kubeadm token create --print-join-command

# On worker nodes, run the join command (example)
sudo kubeadm join k8s-master-01:6443 --token abcdef.0123456789abcdef \
  --discovery-token-ca-cert-hash sha256:1234567890abcdef1234567890abcdef1234567890abcdef1234567890abcdef

📊 Deploying Essential Add-ons

Metrics Server

# Install Metrics Server
kubectl apply -f https://github.com/kubernetes-sigs/metrics-server/releases/latest/download/components.yaml

# Patch for self-signed certificates (development only)
kubectl patch deployment metrics-server -n kube-system --type='json' -p='[
  {
    "op": "add",
    "path": "/spec/template/spec/containers/0/args/-",
    "value": "--kubelet-insecure-tls"
  }
]'

# Verify metrics
kubectl top nodes
kubectl top pods --all-namespaces

Kubernetes Dashboard

# Install Dashboard
kubectl apply -f https://raw.githubusercontent.com/kubernetes/dashboard/v2.7.0/aio/deploy/recommended.yaml

# Create admin user
cat <<EOF | kubectl apply -f -
apiVersion: v1
kind: ServiceAccount
metadata:
  name: admin-user
  namespace: kubernetes-dashboard
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: admin-user
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: cluster-admin
subjects:
- kind: ServiceAccount
  name: admin-user
  namespace: kubernetes-dashboard
EOF

# Get token
kubectl -n kubernetes-dashboard create token admin-user

# Access dashboard (run on local machine)
kubectl proxy
# Visit: http://localhost:8001/api/v1/namespaces/kubernetes-dashboard/services/https:kubernetes-dashboard:/proxy/

Ingress Controller (NGINX)

# Install NGINX Ingress Controller
kubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/controller-v1.8.2/deploy/static/provider/baremetal/deploy.yaml

# Verify installation
kubectl get pods -n ingress-nginx
kubectl get services -n ingress-nginx

💾 Storage Configuration

Local Storage Provider

# Create StorageClass for local storage
cat <<EOF | kubectl apply -f -
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: local-storage
provisioner: kubernetes.io/no-provisioner
volumeBindingMode: WaitForFirstConsumer
EOF

# Create local persistent volume
cat <<EOF | kubectl apply -f -
apiVersion: v1
kind: PersistentVolume
metadata:
  name: local-pv-1
spec:
  capacity:
    storage: 10Gi
  accessModes:
  - ReadWriteOnce
  persistentVolumeReclaimPolicy: Retain
  storageClassName: local-storage
  local:
    path: /mnt/k8s-local-storage/pv1
  nodeAffinity:
    required:
      nodeSelectorTerms:
      - matchExpressions:
        - key: kubernetes.io/hostname
          operator: In
          values:
          - k8s-worker-01
EOF

# Create directory on worker node
sudo mkdir -p /mnt/k8s-local-storage/pv1

NFS Storage Provider

# Install NFS server (on storage node)
sudo dnf install -y nfs-utils
sudo systemctl enable --now nfs-server

# Configure NFS exports
echo "/srv/nfs/k8s *(rw,sync,no_subtree_check,no_root_squash)" | sudo tee -a /etc/exports
sudo mkdir -p /srv/nfs/k8s
sudo exportfs -rav

# Install NFS client on all nodes
sudo dnf install -y nfs-utils

# Deploy NFS provisioner
kubectl create namespace nfs-provisioner

cat <<EOF | kubectl apply -f -
apiVersion: v1
kind: ServiceAccount
metadata:
  name: nfs-client-provisioner
  namespace: nfs-provisioner
---
kind: ClusterRole
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: nfs-client-provisioner-runner
rules:
  - apiGroups: [""]
    resources: ["persistentvolumes"]
    verbs: ["get", "list", "watch", "create", "delete"]
  - apiGroups: [""]
    resources: ["persistentvolumeclaims"]
    verbs: ["get", "list", "watch", "update"]
  - apiGroups: ["storage.k8s.io"]
    resources: ["storageclasses"]
    verbs: ["get", "list", "watch"]
  - apiGroups: [""]
    resources: ["events"]
    verbs: ["create", "update", "patch"]
---
kind: ClusterRoleBinding
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: run-nfs-client-provisioner
subjects:
  - kind: ServiceAccount
    name: nfs-client-provisioner
    namespace: nfs-provisioner
roleRef:
  kind: ClusterRole
  name: nfs-client-provisioner-runner
  apiGroup: rbac.authorization.k8s.io
EOF

🔒 Security Hardening

Network Policies

# Default deny all ingress traffic
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: default-deny-ingress
  namespace: production
spec:
  podSelector: {}
  policyTypes:
  - Ingress

---
# Allow traffic from specific namespace
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-from-frontend
  namespace: backend
spec:
  podSelector:
    matchLabels:
      app: api
  policyTypes:
  - Ingress
  ingress:
  - from:
    - namespaceSelector:
        matchLabels:
          name: frontend
    ports:
    - protocol: TCP
      port: 8080

Pod Security Standards

# Enable Pod Security Standards
kubectl label namespace production pod-security.kubernetes.io/enforce=restricted
kubectl label namespace production pod-security.kubernetes.io/audit=restricted
kubectl label namespace production pod-security.kubernetes.io/warn=restricted

# Create restricted pod example
cat <<EOF | kubectl apply -f -
apiVersion: v1
kind: Pod
metadata:
  name: security-compliant-pod
  namespace: production
spec:
  securityContext:
    runAsNonRoot: true
    runAsUser: 1000
    fsGroup: 2000
    seccompProfile:
      type: RuntimeDefault
  containers:
  - name: app
    image: nginx:alpine
    securityContext:
      allowPrivilegeEscalation: false
      readOnlyRootFilesystem: true
      capabilities:
        drop:
        - ALL
    volumeMounts:
    - name: tmp
      mountPath: /tmp
    - name: var-cache
      mountPath: /var/cache/nginx
    - name: var-run
      mountPath: /var/run
  volumes:
  - name: tmp
    emptyDir: {}
  - name: var-cache
    emptyDir: {}
  - name: var-run
    emptyDir: {}
EOF

RBAC Configuration

# Create namespace-specific admin
apiVersion: v1
kind: ServiceAccount
metadata:
  name: namespace-admin
  namespace: production
---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: namespace-admin
  namespace: production
rules:
- apiGroups: ["*"]
  resources: ["*"]
  verbs: ["*"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: namespace-admin
  namespace: production
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: Role
  name: namespace-admin
subjects:
- kind: ServiceAccount
  name: namespace-admin
  namespace: production

🚀 Deploying Applications

Sample Microservices Application

# Frontend Deployment
apiVersion: apps/v1
kind: Deployment
metadata:
  name: frontend
  namespace: production
spec:
  replicas: 3
  selector:
    matchLabels:
      app: frontend
  template:
    metadata:
      labels:
        app: frontend
    spec:
      containers:
      - name: frontend
        image: nginx:alpine
        ports:
        - containerPort: 80
        resources:
          requests:
            memory: "64Mi"
            cpu: "250m"
          limits:
            memory: "128Mi"
            cpu: "500m"
        livenessProbe:
          httpGet:
            path: /
            port: 80
          initialDelaySeconds: 30
          periodSeconds: 10
        readinessProbe:
          httpGet:
            path: /
            port: 80
          initialDelaySeconds: 5
          periodSeconds: 5
---
# Frontend Service
apiVersion: v1
kind: Service
metadata:
  name: frontend
  namespace: production
spec:
  selector:
    app: frontend
  ports:
  - protocol: TCP
    port: 80
    targetPort: 80
  type: ClusterIP
---
# Ingress
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: frontend
  namespace: production
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  ingressClassName: nginx
  rules:
  - host: app.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: frontend
            port:
              number: 80

Deploying with Helm

# Install Helm
curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash

# Add Helm repositories
helm repo add stable https://charts.helm.sh/stable
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo update

# Deploy PostgreSQL using Helm
helm install postgresql bitnami/postgresql \
  --namespace production \
  --create-namespace \
  --set auth.postgresPassword=secretpassword \
  --set primary.persistence.size=10Gi

# Deploy Redis
helm install redis bitnami/redis \
  --namespace production \
  --set auth.password=secretpassword \
  --set master.persistence.size=8Gi

📊 Monitoring and Observability

Prometheus and Grafana Stack

# Add Prometheus community Helm repository
helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo update

# Install kube-prometheus-stack
helm install monitoring prometheus-community/kube-prometheus-stack \
  --namespace monitoring \
  --create-namespace \
  --set prometheus.prometheusSpec.retention=30d \
  --set prometheus.prometheusSpec.storageSpec.volumeClaimTemplate.spec.resources.requests.storage=50Gi

# Access Grafana (get password)
kubectl get secret --namespace monitoring monitoring-grafana -o jsonpath="{.data.admin-password}" | base64 --decode

# Port forward to access Grafana
kubectl port-forward -n monitoring svc/monitoring-grafana 3000:80

Application Monitoring

# ServiceMonitor for application
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
  name: app-metrics
  namespace: production
spec:
  selector:
    matchLabels:
      app: myapp
  endpoints:
  - port: metrics
    interval: 30s
    path: /metrics

🔧 Cluster Maintenance

Backup and Restore

# Backup etcd
ETCDCTL_API=3 etcdctl \
  --endpoints=https://127.0.0.1:2379 \
  --cacert=/etc/kubernetes/pki/etcd/ca.crt \
  --cert=/etc/kubernetes/pki/etcd/server.crt \
  --key=/etc/kubernetes/pki/etcd/server.key \
  snapshot save /backup/etcd-snapshot-$(date +%Y%m%d-%H%M%S).db

# Backup Kubernetes resources
kubectl get all --all-namespaces -o yaml > /backup/k8s-resources-$(date +%Y%m%d-%H%M%S).yaml

Cluster Upgrades

# Check available versions
sudo dnf list --showduplicates kubeadm

# Upgrade control plane
sudo dnf install -y kubeadm-1.28.2-0 --disableexcludes=kubernetes
sudo kubeadm upgrade plan
sudo kubeadm upgrade apply v1.28.2

# Upgrade kubelet and kubectl
sudo dnf install -y kubelet-1.28.2-0 kubectl-1.28.2-0 --disableexcludes=kubernetes
sudo systemctl daemon-reload
sudo systemctl restart kubelet

# Upgrade worker nodes (on each worker)
sudo dnf install -y kubeadm-1.28.2-0 --disableexcludes=kubernetes
sudo kubeadm upgrade node
sudo dnf install -y kubelet-1.28.2-0 kubectl-1.28.2-0 --disableexcludes=kubernetes
sudo systemctl daemon-reload
sudo systemctl restart kubelet

Node Maintenance

# Drain node for maintenance
kubectl drain k8s-worker-01 --ignore-daemonsets --delete-emptydir-data

# Perform maintenance...

# Uncordon node
kubectl uncordon k8s-worker-01

🚨 Troubleshooting

Common Issues and Solutions

# Check component status
kubectl get componentstatuses
kubectl get nodes
kubectl get pods --all-namespaces

# Check kubelet logs
sudo journalctl -u kubelet -f

# Check container runtime
sudo crictl ps
sudo crictl logs <container-id>

# DNS troubleshooting
kubectl run -it --rm debug --image=busybox --restart=Never -- nslookup kubernetes.default

# Network connectivity test
kubectl run -it --rm debug --image=nicolaka/netshoot --restart=Never -- bash

# Check cluster events
kubectl get events --all-namespaces --sort-by='.lastTimestamp'

Performance Tuning

# Adjust kube-apiserver flags
--max-requests-inflight=400
--max-mutating-requests-inflight=200

# Optimize etcd
--quota-backend-bytes=8589934592  # 8GB

# Configure kubelet
--max-pods=110
--kube-api-qps=50
--kube-api-burst=100

🎯 Best Practices

Production Readiness Checklist

High Availability
- ✅ Multiple control plane nodes (3 or 5)
- ✅ Load balancer for API server
- ✅ etcd cluster with odd number of members
- ✅ Multiple worker nodes across availability zones
Security
- ✅ Network policies enabled
- ✅ Pod Security Standards enforced
- ✅ RBAC properly configured
- ✅ Secrets encryption at rest
- ✅ Regular security updates
Monitoring
- ✅ Metrics collection (Prometheus)
- ✅ Log aggregation (EFK stack)
- ✅ Alerting configured
- ✅ Dashboard access secured
Backup and Recovery
- ✅ Regular etcd backups
- ✅ Disaster recovery plan tested
- ✅ Application data backed up
- ✅ Configuration in version control
Resource Management
- ✅ Resource quotas per namespace
- ✅ LimitRanges configured
- ✅ Pod Disruption Budgets
- ✅ Horizontal Pod Autoscaling

📚 Advanced Topics

Custom Resource Definitions (CRDs)

apiVersion: apiextensions.k8s.io/v1
kind: CustomResourceDefinition
metadata:
  name: applications.apps.example.com
spec:
  group: apps.example.com
  versions:
  - name: v1
    served: true
    storage: true
    schema:
      openAPIV3Schema:
        type: object
        properties:
          spec:
            type: object
            properties:
              replicas:
                type: integer
              image:
                type: string
  scope: Namespaced
  names:
    plural: applications
    singular: application
    kind: Application

Operators

# Install Operator SDK
curl -LO https://github.com/operator-framework/operator-sdk/releases/latest/download/operator-sdk_linux_amd64
chmod +x operator-sdk_linux_amd64
sudo mv operator-sdk_linux_amd64 /usr/local/bin/operator-sdk

# Create new operator
operator-sdk init --domain example.com --repo github.com/example/app-operator
operator-sdk create api --group apps --version v1 --kind Application --resource --controller

🌐 Next Steps and Resources

Learning Path

Container Fundamentals - Deep dive into container technology
Kubernetes Architecture - Understanding internal components
Cloud Native Patterns - Microservices and 12-factor apps
Service Mesh - Istio or Linkerd implementation
GitOps - ArgoCD or Flux for declarative deployments

Useful Resources

Running Kubernetes on AlmaLinux 9 provides a robust, enterprise-ready platform for container orchestration. Start with a single-node cluster for learning, then scale to multi-node production deployments as your needs grow. Remember that Kubernetes is a journey, not a destination – continuous learning and adaptation are key to success in the cloud-native ecosystem. Happy orchestrating! 🚢
