Setting Up Cilium Service Mesh with eBPF on Rocky Linux

Cilium revolutionizes Kubernetes networking by leveraging eBPF technology to provide a high-performance, secure service mesh without sidecars. This comprehensive guide demonstrates deploying Cilium on Rocky Linux, implementing advanced networking features, security policies, and deep observability for cloud-native applications.

Understanding Cilium and eBPF

Cilium uses eBPF to implement networking, security, and observability directly in the Linux kernel:

• Sidecar-free: No proxy containers, reducing resource overhead
• Kernel-level performance: Near-native networking speed
• Identity-based security: Cryptographic workload identity
• Deep visibility: Kernel-level observability without performance penalty
• Protocol acceleration: HTTP/gRPC/Kafka awareness in-kernel

Architecture Overview

1. Cilium Agent: Runs on each node, programs eBPF
2. Cilium Operator: Manages cluster-wide operations
3. Hubble: Observability platform built on Cilium
4. eBPF Programs: Kernel-level data plane
5. Identity Management: Workload identity allocation

Prerequisites

Before deploying Cilium:

• Rocky Linux 9 with kernel 5.10+ (eBPF support)
• Kubernetes 1.23+ cluster
• Minimum 3 nodes with 8GB RAM each
• Helm 3.x installed
• kubectl configured
• No existing CNI plugin installed

Preparing Rocky Linux for Cilium

System Requirements

# Update system
sudo dnf update -y

# Install required packages
sudo dnf install -y \
    kernel-devel \
    kernel-headers \
    elfutils-libelf-devel \
    gcc \
    make \
    git \
    bpftool \
    perf

# Enable IP forwarding
cat <<EOF | sudo tee /etc/sysctl.d/99-cilium.conf
net.ipv4.ip_forward = 1
net.ipv6.conf.all.forwarding = 1
net.bridge.bridge-nf-call-iptables = 0
net.bridge.bridge-nf-call-ip6tables = 0
net.ipv4.conf.all.rp_filter = 0
net.ipv4.fib_multipath_use_neigh = 1
EOF

sudo sysctl -p /etc/sysctl.d/99-cilium.conf

# Disable firewalld (Cilium will handle firewalling)
sudo systemctl stop firewalld
sudo systemctl disable firewalld

# Load required kernel modules
sudo modprobe ip_tables
sudo modprobe ip6_tables
sudo modprobe netlink_diag
sudo modprobe tcp_diag
sudo modprobe udp_diag
sudo modprobe inet_diag
sudo modprobe unix_diag

# Make modules persistent
cat <<EOF | sudo tee /etc/modules-load.d/cilium.conf
ip_tables
ip6_tables
netlink_diag
tcp_diag
udp_diag
inet_diag
unix_diag
EOF

Kubernetes Cluster Setup

# Initialize Kubernetes cluster without CNI
sudo kubeadm init --pod-network-cidr=10.244.0.0/16 --skip-phases=addon/kube-proxy

# Configure kubectl
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

# Remove kube-proxy if exists
kubectl -n kube-system delete ds kube-proxy
kubectl -n kube-system delete cm kube-proxy

# Delete iptables rules installed by kube-proxy
sudo iptables-save | grep -v KUBE | sudo iptables-restore

Installing Cilium

Helm Installation

# Add Cilium Helm repository
helm repo add cilium https://helm.cilium.io/
helm repo update

# Create Cilium namespace
kubectl create namespace cilium

# Generate Cilium configuration
cat <<EOF > cilium-values.yaml
# Cilium configuration for service mesh
kubeProxyReplacement: strict
k8sServiceHost: ${API_SERVER_IP}
k8sServicePort: ${API_SERVER_PORT}

# Enable Hubble for observability
hubble:
  enabled: true
  relay:
    enabled: true
  ui:
    enabled: true
    service:
      type: NodePort
  metrics:
    enabled:
    - dns
    - drop
    - tcp
    - flow
    - icmp
    - http
    serviceMonitor:
      enabled: true

# Enable service mesh features
serviceAccounts:
  cilium:
    name: cilium
  operator:
    name: cilium-operator

# Security and encryption
encryption:
  enabled: true
  type: wireguard
  nodeEncryption: true

# Enable L7 proxy
l7Proxy: true

# eBPF features
bpf:
  masquerade: true
  clockProbe: true
  preallocateMaps: true
  lbMapMax: 65536
  policyMapMax: 16384
  monitorAggregation: medium
  monitorFlags: all

# IPAM configuration
ipam:
  mode: cluster-pool
  operator:
    clusterPoolIPv4PodCIDRList:
    - 10.244.0.0/16

# Enable bandwidth manager
bandwidthManager:
  enabled: true
  bbr: true

# Cluster mesh for multi-cluster
cluster:
  name: cluster1
  id: 1

# Enable BGP
bgp:
  enabled: false
  announce:
    loadbalancerIP: true

# Prometheus metrics
prometheus:
  enabled: true
  serviceMonitor:
    enabled: true

operator:
  replicas: 2
  prometheus:
    enabled: true
    serviceMonitor:
      enabled: true

# Debug and monitoring
debug:
  enabled: true
  verbose: flow

# Load balancing
loadBalancer:
  algorithm: maglev
  mode: hybrid
  acceleration: native

# MTU configuration
mtu: 0  # Auto-detect

# Enable endpoint routes
endpointRoutes:
  enabled: true

# Host firewall
hostFirewall:
  enabled: true

# Policy audit mode
policyAuditMode: false

# Enable CiliumEndpointSlice
enableCiliumEndpointSlice: true
EOF

# Install Cilium
helm install cilium cilium/cilium \
  --version 1.14.5 \
  --namespace cilium \
  --values cilium-values.yaml

# Wait for Cilium to be ready
kubectl -n cilium rollout status deployment/cilium-operator
kubectl -n cilium rollout status daemonset/cilium

Verify Installation

# Check Cilium status
kubectl -n cilium exec ds/cilium -- cilium status

# Validate installation
kubectl create ns cilium-test
kubectl apply -n cilium-test -f https://raw.githubusercontent.com/cilium/cilium/v1.14/examples/kubernetes/connectivity-check/connectivity-check.yaml

# Check connectivity test results
kubectl -n cilium-test get pods -w

Implementing Service Mesh Features

Ingress Controller with Cilium

# cilium-ingress.yaml
apiVersion: networking.k8s.io/v1
kind: IngressClass
metadata:
  name: cilium
spec:
  controller: cilium.io/ingress-controller
  parameters:
    apiGroup: cilium.io
    kind: CiliumIngressParameters
    name: cilium-ingress-params
---
apiVersion: cilium.io/v2
kind: CiliumIngressParameters
metadata:
  name: cilium-ingress-params
spec:
  loadBalancerMode: dedicated
  serviceType: LoadBalancer
  insecureNodePort: 30000
  secureNodePort: 30443
---
apiVersion: v1
kind: Service
metadata:
  name: cilium-ingress
  namespace: cilium
spec:
  type: LoadBalancer
  ports:
  - name: http
    port: 80
    protocol: TCP
    targetPort: 80
  - name: https
    port: 443
    protocol: TCP
    targetPort: 443
  selector:
    app.kubernetes.io/name: cilium-ingress

Service Mesh Configuration

# cilium-service-mesh.yaml
apiVersion: cilium.io/v2
kind: CiliumClusterwideNetworkPolicy
metadata:
  name: service-mesh-default
spec:
  description: "Default service mesh policy"
  endpointSelector: {}
  ingress:
  - fromEndpoints:
    - {}
  egress:
  - toEndpoints:
    - {}
  - toServices:
    - k8sService:
        serviceName: kube-dns
        namespace: kube-system
    toPorts:
    - ports:
      - port: "53"
        protocol: UDP
---
apiVersion: cilium.io/v2
kind: CiliumEnvoyConfig
metadata:
  name: envoy-prometheus-metrics
spec:
  services:
  - name: prometheus-metrics
    namespace: monitoring
  resources:
  - "@type": type.googleapis.com/envoy.config.listener.v3.Listener
    name: prometheus_metrics_listener
    address:
      socket_address:
        address: 0.0.0.0
        port_value: 9090
    filter_chains:
    - filters:
      - name: envoy.filters.network.http_connection_manager
        typed_config:
          "@type": type.googleapis.com/envoy.extensions.filters.network.http_connection_manager.v3.HttpConnectionManager
          stat_prefix: prometheus_metrics
          route_config:
            name: prometheus_metrics_route
            virtual_hosts:
            - name: prometheus_metrics_vhost
              domains: ["*"]
              routes:
              - match:
                  prefix: "/metrics"
                route:
                  prefix_rewrite: "/stats/prometheus"
                  cluster: envoy-admin

Advanced Networking Policies

Identity-Based Security

# identity-policy.yaml
apiVersion: cilium.io/v2
kind: CiliumNetworkPolicy
metadata:
  name: frontend-to-backend
  namespace: production
spec:
  description: "Allow frontend to communicate with backend"
  endpointSelector:
    matchLabels:
      app: backend
  ingress:
  - fromEndpoints:
    - matchLabels:
        app: frontend
    toPorts:
    - ports:
      - port: "8080"
        protocol: TCP
      rules:
        http:
        - method: "GET"
          path: "/api/v1/.*"
        - method: "POST"
          path: "/api/v1/users"
          headers:
          - "Content-Type: application/json"
---
apiVersion: cilium.io/v2
kind: CiliumNetworkPolicy
metadata:
  name: backend-to-database
  namespace: production
spec:
  description: "Allow backend to access database"
  endpointSelector:
    matchLabels:
      app: backend
  egress:
  - toEndpoints:
    - matchLabels:
        app: postgres
    toPorts:
    - ports:
      - port: "5432"
        protocol: TCP
  - toFQDNs:
    - matchPattern: "*.amazonaws.com"
    toPorts:
    - ports:
      - port: "443"
        protocol: TCP

Layer 7 Policy Enforcement

# l7-policy.yaml
apiVersion: cilium.io/v2
kind: CiliumNetworkPolicy
metadata:
  name: api-rate-limiting
  namespace: api
spec:
  endpointSelector:
    matchLabels:
      app: api-gateway
  ingress:
  - fromEndpoints:
    - matchLabels:
        role: external-lb
    toPorts:
    - ports:
      - port: "8080"
        protocol: TCP
      rules:
        http:
        - method: "GET"
          path: "/api/v1/public/.*"
          headers:
          - "X-API-Key: .*"
        - method: "POST"
          path: "/api/v1/auth/.*"
      rateLimit:
        burst: 100
        average: 50
        interval: "1m"
---
apiVersion: cilium.io/v2
kind: CiliumNetworkPolicy
metadata:
  name: grpc-service-policy
spec:
  endpointSelector:
    matchLabels:
      app: grpc-service
  ingress:
  - toPorts:
    - ports:
      - port: "9090"
        protocol: TCP
      rules:
        grpc:
        - serviceName: "user.UserService"
          method: "GetUser"
        - serviceName: "user.UserService"
          method: "ListUsers"

Kafka-Aware Policies

# kafka-policy.yaml
apiVersion: cilium.io/v2
kind: CiliumNetworkPolicy
metadata:
  name: kafka-producer-consumer
spec:
  endpointSelector:
    matchLabels:
      app: kafka
  ingress:
  - fromEndpoints:
    - matchLabels:
        role: producer
    toPorts:
    - ports:
      - port: "9092"
        protocol: TCP
      rules:
        kafka:
        - apiVersion: 3
          apiKeys:
          - "produce"
          - "metadata"
          topic: "events"
          clientID: "producer-.*"
  - fromEndpoints:
    - matchLabels:
        role: consumer
    toPorts:
    - ports:
      - port: "9092"
        protocol: TCP
      rules:
        kafka:
        - apiVersion: 3
          apiKeys:
          - "fetch"
          - "metadata"
          topic: "events"
          clientID: "consumer-.*"

Implementing Encryption and Security

Transparent Encryption

# Enable WireGuard encryption
kubectl -n cilium patch configmap cilium-config \
  --type merge \
  --patch '{"data":{"enable-wireguard":"true","encryption-type":"wireguard"}}'

# Restart Cilium pods
kubectl -n cilium rollout restart daemonset/cilium

# Verify encryption status
kubectl -n cilium exec ds/cilium -- cilium encrypt status

Certificate Management

# cert-manager-integration.yaml
apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
  name: cilium-server-cert
  namespace: cilium
spec:
  secretName: cilium-server-tls
  issuerRef:
    name: cilium-ca-issuer
    kind: ClusterIssuer
  commonName: cilium.cluster.local
  dnsNames:
  - cilium.cluster.local
  - "*.cilium.cluster.local"
  duration: 8760h # 1 year
  renewBefore: 720h # 30 days
---
apiVersion: cilium.io/v2
kind: CiliumNetworkPolicy
metadata:
  name: mutual-tls-enforcement
spec:
  endpointSelector:
    matchLabels:
      security: high
  ingress:
  - fromEndpoints:
    - matchLabels:
        tls: required
    authentication:
      mode: required
      mutual:
        spiffe:
          trustDomain: cluster.local

Observability with Hubble

Hubble UI and CLI Setup

# Install Hubble CLI
HUBBLE_VERSION=$(curl -s https://raw.githubusercontent.com/cilium/hubble/master/stable.txt)
curl -L --remote-name-all https://github.com/cilium/hubble/releases/download/$HUBBLE_VERSION/hubble-linux-amd64.tar.gz
sudo tar xzvfC hubble-linux-amd64.tar.gz /usr/local/bin
rm hubble-linux-amd64.tar.gz

# Port forward to Hubble Relay
kubectl port-forward -n cilium deployment/hubble-relay 4245:4245 &

# Configure Hubble CLI
hubble config set server localhost:4245

# Test Hubble
hubble status
hubble observe

Flow Visibility

# hubble-metrics.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: hubble-metrics-config
  namespace: cilium
data:
  metrics.yaml: |
    metrics:
    - name: "http_requests_total"
      context:
      - source_pod
      - destination_pod
      - http_status_code
      - http_method
      options:
        - labelsContext:
          - source_namespace
          - destination_namespace
    - name: "http_request_duration_seconds"
      context:
      - source_pod
      - destination_pod
      options:
        - buckets: [0.005, 0.01, 0.025, 0.05, 0.1, 0.25, 0.5, 1, 2.5, 5, 10]
    - name: "tcp_connections_total"
      context:
      - source_pod
      - destination_pod
      - verdict
    - name: "dns_queries_total"
      context:
      - source_pod
      - dns_query
      - dns_rcode
    - name: "network_bytes_total"
      context:
      - source_pod
      - destination_pod
      - direction

Service Map Generation

#!/usr/bin/env python3
# generate_service_map.py

import subprocess
import json
import networkx as nx
import matplotlib.pyplot as plt
from collections import defaultdict

def get_hubble_flows():
    """Fetch flows from Hubble"""
    cmd = ["hubble", "observe", "--output", "json", "--last", "1000"]
    result = subprocess.run(cmd, capture_output=True, text=True)

    flows = []
    for line in result.stdout.strip().split('\n'):
        if line:
            flows.append(json.loads(line))

    return flows

def build_service_graph(flows):
    """Build service dependency graph from flows"""
    G = nx.DiGraph()
    edge_counts = defaultdict(int)

    for flow in flows:
        if flow.get('verdict') == 'FORWARDED':
            source = flow.get('source', {})
            dest = flow.get('destination', {})

            src_name = source.get('pod_name', 'unknown')
            dst_name = dest.get('pod_name', 'unknown')

            if src_name != 'unknown' and dst_name != 'unknown':
                edge_counts[(src_name, dst_name)] += 1

    # Add edges with weights
    for (src, dst), count in edge_counts.items():
        G.add_edge(src, dst, weight=count)

    return G

def visualize_service_map(G):
    """Visualize service dependency graph"""
    plt.figure(figsize=(12, 8))

    # Calculate node positions
    pos = nx.spring_layout(G, k=2, iterations=50)

    # Draw nodes
    nx.draw_networkx_nodes(G, pos, node_size=3000, node_color='lightblue')

    # Draw edges with varying widths based on traffic
    edges = G.edges()
    weights = [G[u][v]['weight'] for u, v in edges]
    max_weight = max(weights) if weights else 1

    edge_widths = [5 * w / max_weight for w in weights]
    nx.draw_networkx_edges(G, pos, width=edge_widths, alpha=0.6, edge_color='gray')

    # Draw labels
    nx.draw_networkx_labels(G, pos, font_size=8)

    plt.title("Service Dependency Map")
    plt.axis('off')
    plt.tight_layout()
    plt.savefig('service_map.png', dpi=300)
    plt.show()

if __name__ == "__main__":
    flows = get_hubble_flows()
    G = build_service_graph(flows)
    visualize_service_map(G)

Advanced eBPF Features

Custom eBPF Programs

// custom_network_policy.c
#include <linux/bpf.h>
#include <linux/if_ether.h>
#include <linux/ip.h>
#include <linux/tcp.h>
#include <bpf/bpf_helpers.h>
#include <bpf/bpf_endian.h>

#define RATE_LIMIT_WINDOW_NS 1000000000 // 1 second
#define MAX_REQUESTS_PER_WINDOW 100

struct rate_limit_key {
    __u32 src_ip;
    __u16 dst_port;
};

struct rate_limit_value {
    __u64 last_seen_ns;
    __u32 request_count;
};

struct {
    __uint(type, BPF_MAP_TYPE_LRU_HASH);
    __uint(max_entries, 10000);
    __type(key, struct rate_limit_key);
    __type(value, struct rate_limit_value);
} rate_limit_map SEC(".maps");

SEC("tc")
int rate_limit_ingress(struct __sk_buff *skb)
{
    void *data = (void *)(long)skb->data;
    void *data_end = (void *)(long)skb->data_end;

    struct ethhdr *eth = data;
    if ((void*)(eth + 1) > data_end)
        return TC_ACT_OK;

    if (eth->h_proto != bpf_htons(ETH_P_IP))
        return TC_ACT_OK;

    struct iphdr *ip = (void*)(eth + 1);
    if ((void*)(ip + 1) > data_end)
        return TC_ACT_OK;

    if (ip->protocol != IPPROTO_TCP)
        return TC_ACT_OK;

    struct tcphdr *tcp = (void*)ip + (ip->ihl * 4);
    if ((void*)(tcp + 1) > data_end)
        return TC_ACT_OK;

    // Rate limiting logic
    struct rate_limit_key key = {
        .src_ip = ip->saddr,
        .dst_port = bpf_ntohs(tcp->dest)
    };

    __u64 now = bpf_ktime_get_ns();
    struct rate_limit_value *value = bpf_map_lookup_elem(&rate_limit_map, &key);

    if (value) {
        if (now - value->last_seen_ns > RATE_LIMIT_WINDOW_NS) {
            // New window
            value->last_seen_ns = now;
            value->request_count = 1;
        } else {
            value->request_count++;
            if (value->request_count > MAX_REQUESTS_PER_WINDOW) {
                // Drop packet - rate limit exceeded
                return TC_ACT_SHOT;
            }
        }
    } else {
        // First request
        struct rate_limit_value new_value = {
            .last_seen_ns = now,
            .request_count = 1
        };
        bpf_map_update_elem(&rate_limit_map, &key, &new_value, BPF_ANY);
    }

    return TC_ACT_OK;
}

char LICENSE[] SEC("license") = "GPL";

Loading Custom eBPF Programs

#!/bin/bash
# load_custom_ebpf.sh

# Compile eBPF program
clang -O2 -target bpf -c custom_network_policy.c -o custom_network_policy.o

# Load into Cilium
kubectl -n cilium create configmap custom-ebpf --from-file=custom_network_policy.o

# Apply custom program
kubectl apply -f - <<EOF
apiVersion: cilium.io/v2
kind: CiliumBPFProgram
metadata:
  name: custom-rate-limiter
spec:
  program: custom_network_policy.o
  attachType: TC
  direction: ingress
  selector:
    matchLabels:
      rate-limit: enabled
EOF

Multi-Cluster Service Mesh

Cluster Mesh Setup

# Enable cluster mesh on cluster 1
cilium clustermesh enable --context cluster1

# Enable cluster mesh on cluster 2
cilium clustermesh enable --context cluster2

# Connect clusters
cilium clustermesh connect --context cluster1 --destination-context cluster2

# Verify mesh status
cilium clustermesh status --context cluster1

Global Services

# global-service.yaml
apiVersion: v1
kind: Service
metadata:
  name: global-service
  annotations:
    service.cilium.io/global: "true"
    service.cilium.io/affinity: "local"
spec:
  selector:
    app: my-app
  ports:
  - port: 80
    targetPort: 8080
---
apiVersion: cilium.io/v2
kind: CiliumNetworkPolicy
metadata:
  name: allow-cross-cluster
spec:
  endpointSelector:
    matchLabels:
      app: my-app
  ingress:
  - fromEndpoints:
    - matchLabels:
        io.cilium.k8s.policy.cluster: cluster2
        app: client

Performance Optimization

eBPF Map Tuning

# cilium-performance-tuning.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: cilium-config
  namespace: cilium
data:
  bpf-lb-map-max: "65536"
  bpf-policy-map-max: "16384"
  bpf-ct-global-tcp-max: "524288"
  bpf-ct-global-any-max: "262144"
  bpf-nat-global-max: "524288"
  preallocate-bpf-maps: "true"
  enable-bpf-clock-probe: "true"
  enable-tcp-early-demux: "true"
  enable-bpf-bandwidth-manager: "true"
  enable-bbr: "true"
  kube-proxy-replacement: "strict"
  enable-host-reachable-services: "true"
  native-routing-cidr: "10.0.0.0/8"
  enable-endpoint-routes: "true"
  enable-local-redirect-policy: "true"

XDP Acceleration

# xdp-acceleration.yaml
apiVersion: cilium.io/v2alpha1
kind: CiliumLoadBalancerIPPool
metadata:
  name: xdp-pool
spec:
  cidrs:
  - cidr: "10.100.0.0/24"
  disabled: false
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: cilium-config
  namespace: cilium
data:
  enable-xdp-acceleration: "true"
  xdp-mode: "native"  # native, generic, or testing
  enable-xdp-prefilter: "true"

Monitoring and Troubleshooting

Prometheus Integration

# prometheus-scrape-config.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: prometheus-config
data:
  prometheus.yml: |
    global:
      scrape_interval: 15s

    scrape_configs:
    - job_name: 'cilium-agent'
      kubernetes_sd_configs:
      - role: pod
        namespaces:
          names:
          - cilium
      relabel_configs:
      - source_labels: [__meta_kubernetes_pod_label_k8s_app]
        action: keep
        regex: cilium
      - source_labels: [__meta_kubernetes_pod_name]
        target_label: instance
      - target_label: __address__
        replacement: ${1}:9962
        source_labels: [__meta_kubernetes_pod_ip]

    - job_name: 'hubble'
      kubernetes_sd_configs:
      - role: pod
        namespaces:
          names:
          - cilium
      relabel_configs:
      - source_labels: [__meta_kubernetes_pod_label_k8s_app]
        action: keep
        regex: hubble-relay
      - source_labels: [__meta_kubernetes_pod_name]
        target_label: instance
      - target_label: __address__
        replacement: ${1}:9965
        source_labels: [__meta_kubernetes_pod_ip]

Debugging Tools

#!/bin/bash
# cilium-debug.sh

# Check Cilium status
echo "=== Cilium Status ==="
kubectl -n cilium exec ds/cilium -- cilium status --verbose

# List endpoints
echo -e "\n=== Cilium Endpoints ==="
kubectl -n cilium exec ds/cilium -- cilium endpoint list

# Check BPF maps
echo -e "\n=== BPF Maps ==="
kubectl -n cilium exec ds/cilium -- cilium bpf lb list
kubectl -n cilium exec ds/cilium -- cilium bpf ct list global

# Monitor drops
echo -e "\n=== Monitoring Drops ==="
kubectl -n cilium exec ds/cilium -- cilium monitor --type drop

# Check policy enforcement
echo -e "\n=== Policy Trace ==="
kubectl -n cilium exec ds/cilium -- cilium policy trace --src-k8s-pod default:pod1 --dst-k8s-pod default:pod2

# Hubble flows
echo -e "\n=== Recent Flows ==="
hubble observe --last 100 --verdict DROPPED

Grafana Dashboards

{
  "dashboard": {
    "title": "Cilium Service Mesh Metrics",
    "panels": [
      {
        "title": "Request Rate by Service",
        "targets": [{
          "expr": "sum(rate(hubble_flows_processed_total[5m])) by (destination_service)"
        }]
      },
      {
        "title": "P95 Latency",
        "targets": [{
          "expr": "histogram_quantile(0.95, sum(rate(hubble_http_request_duration_seconds_bucket[5m])) by (le, destination_service))"
        }]
      },
      {
        "title": "Policy Drops",
        "targets": [{
          "expr": "sum(rate(cilium_drop_count_total[5m])) by (reason)"
        }]
      },
      {
        "title": "Endpoint Status",
        "targets": [{
          "expr": "cilium_endpoint_state"
        }]
      }
    ]
  }
}

Production Best Practices

High Availability Configuration

# ha-configuration.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: cilium-operator
  namespace: cilium
spec:
  replicas: 3
  selector:
    matchLabels:
      name: cilium-operator
  template:
    spec:
      affinity:
        podAntiAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
          - labelSelector:
              matchExpressions:
              - key: name
                operator: In
                values:
                - cilium-operator
            topologyKey: kubernetes.io/hostname
      containers:
      - name: cilium-operator
        resources:
          requests:
            cpu: 100m
            memory: 128Mi
          limits:
            cpu: 1000m
            memory: 512Mi

Backup and Recovery

#!/bin/bash
# backup-cilium.sh

BACKUP_DIR="/backup/cilium/$(date +%Y%m%d_%H%M%S)"
mkdir -p $BACKUP_DIR

# Backup Cilium configuration
kubectl -n cilium get cm cilium-config -o yaml > $BACKUP_DIR/cilium-config.yaml

# Backup network policies
kubectl get cnp -A -o yaml > $BACKUP_DIR/cilium-network-policies.yaml
kubectl get ccnp -o yaml > $BACKUP_DIR/cilium-clusterwide-policies.yaml

# Backup Cilium identities
kubectl -n cilium exec ds/cilium -- cilium identity list > $BACKUP_DIR/cilium-identities.txt

# Backup endpoints
kubectl -n cilium exec ds/cilium -- cilium endpoint list -o json > $BACKUP_DIR/cilium-endpoints.json

echo "Backup completed: $BACKUP_DIR"

Conclusion

Cilium with eBPF on Rocky Linux provides a powerful, high-performance service mesh solution that eliminates the overhead of traditional sidecar proxies. By leveraging kernel-level networking and security enforcement, Cilium enables advanced features like transparent encryption, L7 visibility, and multi-cluster connectivity while maintaining near-native performance.

The combination of eBPF’s efficiency, Cilium’s feature richness, and Rocky Linux’s stability creates an ideal platform for modern cloud-native applications requiring sophisticated networking, security, and observability capabilities.
