🚢 AlmaLinux Container Orchestration: Complete Kubernetes Setup Guide

Welcome to the comprehensive AlmaLinux Kubernetes container orchestration guide! 🎉 Kubernetes is the world’s leading container orchestration platform, enabling you to deploy, manage, and scale containerized applications with ease. Whether you’re building microservices architectures, implementing CI/CD pipelines, or creating cloud-native applications, Kubernetes provides the foundation for modern application deployment! 🌟

Setting up a Kubernetes cluster might seem daunting, but we’ll guide you through every step to build a production-ready container orchestration platform. By the end of this guide, you’ll have a fully functional Kubernetes cluster that can handle enterprise workloads with automatic scaling, service discovery, and self-healing capabilities! 🚀

🤔 Why is Container Orchestration Important?

Container orchestration with Kubernetes is absolutely essential for modern application deployment! Here’s why setting up Kubernetes is incredibly valuable: ✨

• 🎯 Automated Deployment: Deploy and update applications without downtime
• 📈 Auto-Scaling: Automatically scale applications based on demand
• 🔄 Self-Healing: Automatically restart failed containers and replace unhealthy nodes
• 🌐 Service Discovery: Built-in load balancing and service networking
• 💾 Storage Orchestration: Automatically mount storage systems for persistent data
• 🔐 Secret Management: Securely manage sensitive configuration and credentials
• 📊 Resource Management: Efficiently allocate CPU, memory, and storage resources
• 🛡️ Security Policies: Implement network policies and access controls
• 🔧 Configuration Management: Manage application configuration separately from code
• 🌍 Multi-Cloud: Run consistently across different cloud providers and on-premises

🎯 What You Need

Before we start building your Kubernetes cluster, make sure you have these essentials ready:

✅ Multiple AlmaLinux 9.x servers (1 master + 2+ worker nodes) ✅ Minimum 2GB RAM per node and 20GB disk space ✅ Static IP addresses for all cluster nodes ✅ Network connectivity between all nodes ✅ Basic container knowledge (we’ll guide you through everything!) ✅ Terminal/SSH access to all servers ✅ Text editor familiarity (nano, vim, or gedit) ✅ Firewall admin access for port configuration ✅ Container registry access (Docker Hub or private registry) ✅ Storage for persistent volumes (local or network storage)

📝 Step 1: System Preparation and Container Runtime

Let’s start by preparing all nodes and installing the container runtime! 🎯

# Run these commands on ALL nodes (master and workers)

# Update system packages to latest versions
sudo dnf update -y

# Disable swap (required for Kubernetes)
sudo swapoff -a
sudo sed -i '/ swap / s/^\(.*\)$/#\1/g' /etc/fstab

# Configure kernel parameters for Kubernetes
sudo tee /etc/modules-load.d/k8s.conf << 'EOF'
overlay
br_netfilter
EOF

# Load kernel modules
sudo modprobe overlay
sudo modprobe br_netfilter

# Configure sysctl parameters
sudo tee /etc/sysctl.d/k8s.conf << 'EOF'
net.bridge.bridge-nf-call-iptables = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward = 1
EOF

# Apply sysctl parameters
sudo sysctl --system

# Install containerd container runtime
sudo dnf config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo
sudo dnf install -y containerd.io

# Configure containerd
sudo mkdir -p /etc/containerd
containerd config default | sudo tee /etc/containerd/config.toml

# Enable SystemdCgroup for containerd
sudo sed -i 's/SystemdCgroup = false/SystemdCgroup = true/' /etc/containerd/config.toml

# Start and enable containerd
sudo systemctl enable containerd
sudo systemctl start containerd

# Verify containerd is running
sudo systemctl status containerd

# Install cri-tools (optional but useful)
sudo dnf install -y cri-tools

# Test containerd
sudo ctr version

Expected output:

Complete!
● containerd.service - containerd container runtime
     Loaded: loaded (/usr/lib/systemd/system/containerd.service; enabled)
     Active: active (running) since Tue 2025-09-17 17:00:15 EDT

Client:
  Version:  1.6.24
  Revision: 61f9fd88f79f081d64d6fa3bb1a0dc71ec870523
  Go version: go1.19.13

Server:
  Version:  1.6.24
  Revision: 61f9fd88f79f081d64d6fa3bb1a0dc71ec870523
  UUID: 12345678-1234-5678-9abc-123456789012

Perfect! 🌟 Container runtime is installed and configured on all nodes!

🔧 Step 2: Install Kubernetes Components

Install kubeadm, kubelet, and kubectl on all nodes! ⚡

# Run these commands on ALL nodes (master and workers)

# Add Kubernetes repository
sudo tee /etc/yum.repos.d/kubernetes.repo << 'EOF'
[kubernetes]
name=Kubernetes
baseurl=https://pkgs.k8s.io/core:/stable:/v1.28/rpm/
enabled=1
gpgcheck=1
gpgkey=https://pkgs.k8s.io/core:/stable:/v1.28/rpm/repodata/repomd.xml.key
exclude=kubelet kubeadm kubectl cri-tools kubernetes-cni
EOF

# Install Kubernetes components
sudo dnf install -y kubelet kubeadm kubectl --disableexcludes=kubernetes

# Enable kubelet service
sudo systemctl enable kubelet

# Check installed versions
kubeadm version
kubelet --version
kubectl version --client

# Configure kubelet
sudo tee /etc/default/kubelet << 'EOF'
KUBELET_EXTRA_ARGS="--container-runtime-endpoint=unix:///var/run/containerd/containerd.sock"
EOF

# Create kubelet systemd drop-in directory
sudo mkdir -p /etc/systemd/system/kubelet.service.d

# Configure kubelet for containerd
sudo tee /etc/systemd/system/kubelet.service.d/10-kubeadm.conf << 'EOF'
[Service]
Environment="KUBELET_KUBECONFIG_ARGS=--bootstrap-kubeconfig=/etc/kubernetes/bootstrap-kubelet.conf --kubeconfig=/etc/kubernetes/kubelet.conf"
Environment="KUBELET_CONFIG_ARGS=--config=/var/lib/kubelet/config.yaml"
Environment="KUBELET_KUBEADM_ARGS=--container-runtime-endpoint=unix:///var/run/containerd/containerd.sock --pod-infra-container-image=registry.k8s.io/pause:3.9"
Environment="KUBELET_EXTRA_ARGS="
ExecStart=
ExecStart=/usr/bin/kubelet $KUBELET_KUBECONFIG_ARGS $KUBELET_CONFIG_ARGS $KUBELET_KUBEADM_ARGS $KUBELET_EXTRA_ARGS
EOF

# Reload systemd
sudo systemctl daemon-reload

# Set SELinux to permissive (required for Kubernetes)
sudo setenforce 0
sudo sed -i 's/^SELINUX=enforcing$/SELINUX=permissive/' /etc/selinux/config

# Configure firewall for Kubernetes
sudo systemctl enable firewalld
sudo systemctl start firewalld

# On MASTER node only - add these firewall rules:
sudo firewall-cmd --permanent --add-port=6443/tcp    # Kubernetes API server
sudo firewall-cmd --permanent --add-port=2379-2380/tcp # etcd server client API
sudo firewall-cmd --permanent --add-port=10250/tcp   # Kubelet API
sudo firewall-cmd --permanent --add-port=10259/tcp   # kube-scheduler
sudo firewall-cmd --permanent --add-port=10257/tcp   # kube-controller-manager

# On WORKER nodes only - add these firewall rules:
sudo firewall-cmd --permanent --add-port=10250/tcp   # Kubelet API
sudo firewall-cmd --permanent --add-port=30000-32767/tcp # NodePort Services

# On ALL nodes - add common ports:
sudo firewall-cmd --permanent --add-service=ssh
sudo firewall-cmd --permanent --add-masquerade

# Reload firewall
sudo firewall-cmd --reload

echo "Kubernetes components installed successfully!"

Expected output:

Complete!
kubeadm version: &version.Info{Major:"1", Minor:"28", GitVersion:"v1.28.2"}
kubelet version: v1.28.2
Client Version: v1.28.2
Kubernetes components installed successfully!

Excellent! ✅ Kubernetes components are installed on all nodes!

🌟 Step 3: Initialize Kubernetes Master Node

Set up the Kubernetes control plane on the master node! 📊

# Run these commands ONLY on the MASTER node

# Initialize the Kubernetes cluster
sudo kubeadm init --pod-network-cidr=10.244.0.0/16 --control-plane-endpoint=$(hostname -I | awk '{print $1}') --upload-certs

# Wait for initialization to complete, then set up kubectl access
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/config

# Verify cluster status
kubectl cluster-info
kubectl get nodes

# Install Flannel CNI (Container Network Interface)
kubectl apply -f https://github.com/flannel-io/flannel/releases/latest/download/kube-flannel.yml

# Wait for Flannel pods to be ready
kubectl wait --for=condition=ready pod -l app=flannel -n kube-flannel --timeout=300s

# Check all system pods
kubectl get pods -n kube-system

# Generate join command for worker nodes
kubeadm token create --print-join-command > /tmp/kubeadm-join-command.txt
cat /tmp/kubeadm-join-command.txt

# Create cluster management script
sudo tee /usr/local/bin/k8s-cluster-manager.sh << 'EOF'
#!/bin/bash
# Kubernetes Cluster Management Script

case "$1" in
    status)
        echo "=== Cluster Status ==="
        kubectl cluster-info
        echo ""
        kubectl get nodes -o wide
        echo ""
        kubectl top nodes 2>/dev/null || echo "Metrics server not installed"
        ;;

    pods)
        echo "=== All Pods ==="
        kubectl get pods --all-namespaces -o wide
        ;;

    services)
        echo "=== All Services ==="
        kubectl get services --all-namespaces -o wide
        ;;

    health)
        echo "=== Cluster Health ==="
        kubectl get componentstatuses
        echo ""
        kubectl get pods -n kube-system
        ;;

    join-command)
        echo "=== Worker Join Command ==="
        kubeadm token create --print-join-command
        ;;

    logs)
        if [ -z "$2" ]; then
            echo "Usage: $0 logs <pod-name> [namespace]"
            exit 1
        fi
        NAMESPACE=${3:-default}
        kubectl logs $2 -n $NAMESPACE --tail=50
        ;;

    describe)
        if [ -z "$2" ]; then
            echo "Usage: $0 describe <resource> <name> [namespace]"
            exit 1
        fi
        NAMESPACE=${4:-default}
        kubectl describe $2 $3 -n $NAMESPACE
        ;;

    *)
        echo "Usage: $0 {status|pods|services|health|join-command|logs|describe}"
        echo "Examples:"
        echo "  $0 status"
        echo "  $0 pods"
        echo "  $0 logs nginx-pod default"
        echo "  $0 describe pod nginx-pod default"
        ;;
esac
EOF

# Make cluster manager executable
sudo chmod +x /usr/local/bin/k8s-cluster-manager.sh

# Test cluster management script
sudo /usr/local/bin/k8s-cluster-manager.sh status

echo "Kubernetes master node initialized successfully!"
echo "Join command saved to /tmp/kubeadm-join-command.txt"
echo "Copy this command and run it on worker nodes"

Expected output:

Your Kubernetes control-plane has initialized successfully!

To start using your cluster, you need to run the following as a regular user:

  mkdir -p $HOME/.kube
  sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
  sudo chown $(id -u):$(id -g) $HOME/.kube/config

Kubernetes control plane is running at https://192.168.1.10:6443
CoreDNS is running at https://192.168.1.10:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

=== Cluster Status ===
Kubernetes control plane is running at https://192.168.1.10:6443
CoreDNS is running at https://192.168.1.10:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

NAME           STATUS   ROLES           AGE   VERSION
master-node    Ready    control-plane   5m    v1.28.2

Amazing! 🌟 Kubernetes master node is initialized and ready!

✅ Step 4: Join Worker Nodes to Cluster

Add worker nodes to the Kubernetes cluster! 🔥

# Run these commands on WORKER nodes

# Copy the join command from master node (example)
# sudo kubeadm join 192.168.1.10:6443 --token abc123.xyz456 \
#     --discovery-token-ca-cert-hash sha256:hash_value

# After joining, verify from master node:
# kubectl get nodes

# On MASTER node - verify all nodes are ready
kubectl get nodes -o wide

# Check node labels
kubectl get nodes --show-labels

# Label worker nodes (optional but recommended)
kubectl label node worker-node-1 node-role.kubernetes.io/worker=worker
kubectl label node worker-node-2 node-role.kubernetes.io/worker=worker

# Create node management script
sudo tee /usr/local/bin/k8s-node-manager.sh << 'EOF'
#!/bin/bash
# Kubernetes Node Management Script

case "$1" in
    list)
        echo "=== Cluster Nodes ==="
        kubectl get nodes -o wide
        ;;

    describe)
        if [ -z "$2" ]; then
            echo "Usage: $0 describe <node-name>"
            exit 1
        fi
        kubectl describe node $2
        ;;

    drain)
        if [ -z "$2" ]; then
            echo "Usage: $0 drain <node-name>"
            exit 1
        fi
        echo "Draining node $2..."
        kubectl drain $2 --ignore-daemonsets --force --delete-emptydir-data
        ;;

    uncordon)
        if [ -z "$2" ]; then
            echo "Usage: $0 uncordon <node-name>"
            exit 1
        fi
        echo "Uncordoning node $2..."
        kubectl uncordon $2
        ;;

    remove)
        if [ -z "$2" ]; then
            echo "Usage: $0 remove <node-name>"
            exit 1
        fi
        echo "Removing node $2 from cluster..."
        kubectl drain $2 --ignore-daemonsets --force --delete-emptydir-data
        kubectl delete node $2
        echo "Node $2 removed. Run 'kubeadm reset' on the node itself."
        ;;

    taint)
        if [ -z "$2" ] || [ -z "$3" ]; then
            echo "Usage: $0 taint <node-name> <taint>"
            echo "Example: $0 taint worker-1 key=value:NoSchedule"
            exit 1
        fi
        kubectl taint node $2 $3
        ;;

    untaint)
        if [ -z "$2" ] || [ -z "$3" ]; then
            echo "Usage: $0 untaint <node-name> <taint>"
            echo "Example: $0 untaint worker-1 key=value:NoSchedule-"
            exit 1
        fi
        kubectl taint node $2 $3
        ;;

    *)
        echo "Usage: $0 {list|describe|drain|uncordon|remove|taint|untaint}"
        echo "Examples:"
        echo "  $0 list"
        echo "  $0 describe worker-node-1"
        echo "  $0 drain worker-node-1"
        echo "  $0 uncordon worker-node-1"
        ;;
esac
EOF

sudo chmod +x /usr/local/bin/k8s-node-manager.sh

# Test node management
sudo /usr/local/bin/k8s-node-manager.sh list

echo "Worker nodes joined successfully!"

Expected output:

=== Cluster Nodes ===
NAME           STATUS   ROLES           AGE   VERSION   INTERNAL-IP    EXTERNAL-IP   OS-IMAGE             KERNEL-VERSION
master-node    Ready    control-plane   15m   v1.28.2   192.168.1.10   <none>        AlmaLinux 9.2        5.14.0-284.30.1.el9_2.x86_64
worker-node-1  Ready    worker          5m    v1.28.2   192.168.1.11   <none>        AlmaLinux 9.2        5.14.0-284.30.1.el9_2.x86_64
worker-node-2  Ready    worker          5m    v1.28.2   192.168.1.12   <none>        AlmaLinux 9.2        5.14.0-284.30.1.el9_2.x86_64

Perfect! 🎉 All nodes are joined and the cluster is ready!

🔧 Step 5: Deploy Essential Cluster Components

Install essential components for a production-ready cluster! 📈

# Run these commands on the MASTER node

# Install Metrics Server for resource monitoring
kubectl apply -f https://github.com/kubernetes-sigs/metrics-server/releases/latest/download/components.yaml

# Patch Metrics Server for development environments (if using self-signed certs)
kubectl patch deployment metrics-server -n kube-system --type='json' \
  -p='[{"op": "add", "path": "/spec/template/spec/containers/0/args/-", "value": "--kubelet-insecure-tls"}]'

# Wait for Metrics Server to be ready
kubectl wait --for=condition=ready pod -l k8s-app=metrics-server -n kube-system --timeout=300s

# Install Kubernetes Dashboard
kubectl apply -f https://raw.githubusercontent.com/kubernetes/dashboard/v2.7.0/aio/deploy/recommended.yaml

# Create admin user for dashboard
kubectl create serviceaccount admin-user -n kubernetes-dashboard
kubectl create clusterrolebinding admin-user --clusterrole=cluster-admin --serviceaccount=kubernetes-dashboard:admin-user

# Create token for dashboard access
kubectl -n kubernetes-dashboard create token admin-user > /tmp/dashboard-token.txt

# Install Ingress Controller (NGINX)
kubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/controller-v1.8.1/deploy/static/provider/baremetal/deploy.yaml

# Wait for ingress controller to be ready
kubectl wait --namespace ingress-nginx \
  --for=condition=ready pod \
  --selector=app.kubernetes.io/component=controller \
  --timeout=300s

# Create storage class for persistent volumes
kubectl apply -f - << 'EOF'
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: local-storage
  annotations:
    storageclass.kubernetes.io/is-default-class: "true"
provisioner: kubernetes.io/no-provisioner
volumeBindingMode: WaitForFirstConsumer
reclaimPolicy: Retain
EOF

# Create persistent volume (example)
kubectl apply -f - << 'EOF'
apiVersion: v1
kind: PersistentVolume
metadata:
  name: local-pv-1
spec:
  capacity:
    storage: 10Gi
  accessModes:
  - ReadWriteOnce
  persistentVolumeReclaimPolicy: Retain
  storageClassName: local-storage
  local:
    path: /mnt/disk1
  nodeAffinity:
    required:
      nodeSelectorTerms:
      - matchExpressions:
        - key: kubernetes.io/hostname
          operator: In
          values:
          - worker-node-1
EOF

# Create cluster monitoring script
sudo tee /usr/local/bin/k8s-monitor.sh << 'EOF'
#!/bin/bash
# Kubernetes Cluster Monitoring Script

case "$1" in
    overview)
        echo "=== Cluster Overview ==="
        kubectl cluster-info
        echo ""
        kubectl get nodes -o wide
        echo ""
        kubectl top nodes 2>/dev/null
        echo ""
        kubectl get pods --all-namespaces | grep -E "(Running|Pending|Failed|CrashLoopBackOff)"
        ;;

    resources)
        echo "=== Resource Usage ==="
        kubectl top nodes
        echo ""
        kubectl top pods --all-namespaces --sort-by=cpu
        ;;

    storage)
        echo "=== Storage Information ==="
        kubectl get storageclass
        echo ""
        kubectl get pv
        echo ""
        kubectl get pvc --all-namespaces
        ;;

    network)
        echo "=== Network Information ==="
        kubectl get services --all-namespaces -o wide
        echo ""
        kubectl get ingress --all-namespaces
        echo ""
        kubectl get endpoints --all-namespaces
        ;;

    events)
        echo "=== Recent Events ==="
        kubectl get events --all-namespaces --sort-by='.lastTimestamp' | tail -20
        ;;

    health)
        echo "=== Cluster Health Check ==="

        # Check node status
        echo "Node Health:"
        kubectl get nodes | grep -v Ready && echo "❌ Some nodes not ready" || echo "✅ All nodes ready"

        # Check system pods
        echo -e "\nSystem Pods Health:"
        FAILED_PODS=$(kubectl get pods -n kube-system | grep -v Running | grep -v Completed | tail -n +2)
        if [ -z "$FAILED_PODS" ]; then
            echo "✅ All system pods healthy"
        else
            echo "❌ Failed system pods:"
            echo "$FAILED_PODS"
        fi

        # Check metrics server
        echo -e "\nMetrics Server:"
        kubectl top nodes >/dev/null 2>&1 && echo "✅ Metrics server working" || echo "❌ Metrics server not responding"

        # Check DNS
        echo -e "\nDNS Health:"
        kubectl get pods -n kube-system -l k8s-app=kube-dns | grep Running >/dev/null && echo "✅ DNS pods running" || echo "❌ DNS pods not running"
        ;;

    dashboard)
        echo "=== Dashboard Access ==="
        echo "Dashboard URL: https://localhost:8001/api/v1/namespaces/kubernetes-dashboard/services/https:kubernetes-dashboard:/proxy/"
        echo "Run: kubectl proxy"
        echo "Token saved in: /tmp/dashboard-token.txt"
        cat /tmp/dashboard-token.txt
        ;;

    *)
        echo "Usage: $0 {overview|resources|storage|network|events|health|dashboard}"
        ;;
esac
EOF

sudo chmod +x /usr/local/bin/k8s-monitor.sh

# Test cluster monitoring
sudo /usr/local/bin/k8s-monitor.sh overview

echo "Essential cluster components installed successfully!"

Expected output:

deployment.apps/metrics-server patched
pod/metrics-server-6d94bc8694-xyz123 condition met

=== Cluster Overview ===
Kubernetes control plane is running at https://192.168.1.10:6443
CoreDNS is running at https://192.168.1.10:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

NAME           STATUS   ROLES           AGE   VERSION
master-node    Ready    control-plane   25m   v1.28.2
worker-node-1  Ready    worker          15m   v1.28.2
worker-node-2  Ready    worker          15m   v1.28.2

NAME           CPU(cores)   CPU%   MEMORY(bytes)   MEMORY%
master-node    156m         7%     1456Mi          74%
worker-node-1  45m          2%     892Mi           45%
worker-node-2  43m          2%     876Mi           44%

Excellent! ✅ Essential cluster components are installed and monitoring is active!

🎮 Quick Examples

Here are practical examples of deploying applications on your Kubernetes cluster! 🌟

Example 1: Deploy Multi-Tier Web Application 🌐

# Create namespace for the application
kubectl create namespace webapp

# Deploy MySQL database
kubectl apply -f - << 'EOF'
apiVersion: apps/v1
kind: Deployment
metadata:
  name: mysql
  namespace: webapp
spec:
  selector:
    matchLabels:
      app: mysql
  strategy:
    type: Recreate
  template:
    metadata:
      labels:
        app: mysql
    spec:
      containers:
      - image: mysql:8.0
        name: mysql
        env:
        - name: MYSQL_ROOT_PASSWORD
          value: rootpassword
        - name: MYSQL_DATABASE
          value: webapp
        - name: MYSQL_USER
          value: webuser
        - name: MYSQL_PASSWORD
          value: webpassword
        ports:
        - containerPort: 3306
          name: mysql
        volumeMounts:
        - name: mysql-persistent-storage
          mountPath: /var/lib/mysql
      volumes:
      - name: mysql-persistent-storage
        emptyDir: {}
---
apiVersion: v1
kind: Service
metadata:
  name: mysql
  namespace: webapp
spec:
  ports:
  - port: 3306
  selector:
    app: mysql
EOF

# Deploy web application
kubectl apply -f - << 'EOF'
apiVersion: apps/v1
kind: Deployment
metadata:
  name: webapp
  namespace: webapp
spec:
  replicas: 3
  selector:
    matchLabels:
      app: webapp
  template:
    metadata:
      labels:
        app: webapp
    spec:
      containers:
      - name: webapp
        image: nginx:alpine
        ports:
        - containerPort: 80
        env:
        - name: DATABASE_HOST
          value: mysql
        - name: DATABASE_NAME
          value: webapp
        volumeMounts:
        - name: webapp-config
          mountPath: /etc/nginx/conf.d
      volumes:
      - name: webapp-config
        configMap:
          name: webapp-config
---
apiVersion: v1
kind: Service
metadata:
  name: webapp
  namespace: webapp
spec:
  selector:
    app: webapp
  ports:
  - protocol: TCP
    port: 80
    targetPort: 80
  type: ClusterIP
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: webapp-config
  namespace: webapp
data:
  default.conf: |
    server {
        listen 80;
        server_name localhost;

        location / {
            root /usr/share/nginx/html;
            index index.html index.htm;
        }

        location /api/ {
            proxy_pass http://api-service:8080/;
            proxy_set_header Host $host;
            proxy_set_header X-Real-IP $remote_addr;
        }
    }
EOF

# Create Ingress for external access
kubectl apply -f - << 'EOF'
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: webapp-ingress
  namespace: webapp
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  ingressClassName: nginx
  rules:
  - host: webapp.local
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: webapp
            port:
              number: 80
EOF

# Check deployment status
kubectl get all -n webapp

# Scale the application
kubectl scale deployment webapp --replicas=5 -n webapp

# Create application management script
sudo tee /usr/local/bin/k8s-app-manager.sh << 'EOF'
#!/bin/bash
# Kubernetes Application Management Script

NAMESPACE=${2:-default}

case "$1" in
    deploy)
        if [ -z "$2" ]; then
            echo "Usage: $0 deploy <app-name> [replicas]"
            exit 1
        fi
        REPLICAS=${3:-1}

        kubectl create deployment $2 --image=nginx:alpine --replicas=$REPLICAS
        kubectl expose deployment $2 --port=80 --type=ClusterIP
        echo "Application $2 deployed with $REPLICAS replicas"
        ;;

    scale)
        if [ -z "$2" ] || [ -z "$3" ]; then
            echo "Usage: $0 scale <deployment-name> <replicas> [namespace]"
            exit 1
        fi
        kubectl scale deployment $2 --replicas=$3 -n $NAMESPACE
        echo "Scaled $2 to $3 replicas in namespace $NAMESPACE"
        ;;

    restart)
        if [ -z "$2" ]; then
            echo "Usage: $0 restart <deployment-name> [namespace]"
            exit 1
        fi
        kubectl rollout restart deployment $2 -n $NAMESPACE
        echo "Restarted deployment $2 in namespace $NAMESPACE"
        ;;

    logs)
        if [ -z "$2" ]; then
            echo "Usage: $0 logs <pod-name> [namespace]"
            exit 1
        fi
        kubectl logs $2 -n $NAMESPACE --tail=50 -f
        ;;

    exec)
        if [ -z "$2" ]; then
            echo "Usage: $0 exec <pod-name> [namespace]"
            exit 1
        fi
        kubectl exec -it $2 -n $NAMESPACE -- /bin/sh
        ;;

    delete)
        if [ -z "$2" ]; then
            echo "Usage: $0 delete <resource-type> <resource-name> [namespace]"
            exit 1
        fi
        kubectl delete $2 $3 -n $NAMESPACE
        echo "Deleted $2 $3 from namespace $NAMESPACE"
        ;;

    *)
        echo "Usage: $0 {deploy|scale|restart|logs|exec|delete}"
        echo "Examples:"
        echo "  $0 deploy myapp 3"
        echo "  $0 scale myapp 5 production"
        echo "  $0 restart myapp production"
        echo "  $0 logs mypod-12345 production"
        echo "  $0 exec mypod-12345 production"
        ;;
esac
EOF

sudo chmod +x /usr/local/bin/k8s-app-manager.sh

echo "Multi-tier web application deployed successfully!"

Example 2: Deploy Microservices with Service Mesh 🕸️

# Create namespace for microservices
kubectl create namespace microservices

# Deploy User Service
kubectl apply -f - << 'EOF'
apiVersion: apps/v1
kind: Deployment
metadata:
  name: user-service
  namespace: microservices
spec:
  replicas: 2
  selector:
    matchLabels:
      app: user-service
  template:
    metadata:
      labels:
        app: user-service
        version: v1
    spec:
      containers:
      - name: user-service
        image: httpd:alpine
        ports:
        - containerPort: 80
        env:
        - name: SERVICE_NAME
          value: "user-service"
        - name: SERVICE_VERSION
          value: "v1"
---
apiVersion: v1
kind: Service
metadata:
  name: user-service
  namespace: microservices
spec:
  selector:
    app: user-service
  ports:
  - port: 80
    targetPort: 80
EOF

# Deploy Order Service
kubectl apply -f - << 'EOF'
apiVersion: apps/v1
kind: Deployment
metadata:
  name: order-service
  namespace: microservices
spec:
  replicas: 3
  selector:
    matchLabels:
      app: order-service
  template:
    metadata:
      labels:
        app: order-service
        version: v1
    spec:
      containers:
      - name: order-service
        image: httpd:alpine
        ports:
        - containerPort: 80
        env:
        - name: SERVICE_NAME
          value: "order-service"
        - name: USER_SERVICE_URL
          value: "http://user-service"
---
apiVersion: v1
kind: Service
metadata:
  name: order-service
  namespace: microservices
spec:
  selector:
    app: order-service
  ports:
  - port: 80
    targetPort: 80
EOF

# Deploy API Gateway
kubectl apply -f - << 'EOF'
apiVersion: apps/v1
kind: Deployment
metadata:
  name: api-gateway
  namespace: microservices
spec:
  replicas: 2
  selector:
    matchLabels:
      app: api-gateway
  template:
    metadata:
      labels:
        app: api-gateway
    spec:
      containers:
      - name: api-gateway
        image: nginx:alpine
        ports:
        - containerPort: 80
        volumeMounts:
        - name: gateway-config
          mountPath: /etc/nginx/conf.d
      volumes:
      - name: gateway-config
        configMap:
          name: gateway-config
---
apiVersion: v1
kind: Service
metadata:
  name: api-gateway
  namespace: microservices
spec:
  selector:
    app: api-gateway
  ports:
  - port: 80
    targetPort: 80
  type: LoadBalancer
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: gateway-config
  namespace: microservices
data:
  default.conf: |
    upstream user-service {
        server user-service:80;
    }

    upstream order-service {
        server order-service:80;
    }

    server {
        listen 80;

        location /users/ {
            proxy_pass http://user-service/;
            proxy_set_header Host $host;
            proxy_set_header X-Real-IP $remote_addr;
        }

        location /orders/ {
            proxy_pass http://order-service/;
            proxy_set_header Host $host;
            proxy_set_header X-Real-IP $remote_addr;
        }

        location /health {
            return 200 "OK";
            add_header Content-Type text/plain;
        }
    }
EOF

# Create network policies for security
kubectl apply -f - << 'EOF'
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: microservices-network-policy
  namespace: microservices
spec:
  podSelector: {}
  policyTypes:
  - Ingress
  - Egress
  ingress:
  - from:
    - namespaceSelector:
        matchLabels:
          name: microservices
  egress:
  - to:
    - namespaceSelector:
        matchLabels:
          name: microservices
  - to: []
    ports:
    - protocol: TCP
      port: 53
    - protocol: UDP
      port: 53
EOF

echo "Microservices architecture deployed successfully!"

Example 3: Deploy Monitoring and Logging Stack 📊

# Create monitoring namespace
kubectl create namespace monitoring

# Deploy Prometheus
kubectl apply -f - << 'EOF'
apiVersion: apps/v1
kind: Deployment
metadata:
  name: prometheus
  namespace: monitoring
spec:
  replicas: 1
  selector:
    matchLabels:
      app: prometheus
  template:
    metadata:
      labels:
        app: prometheus
    spec:
      containers:
      - name: prometheus
        image: prom/prometheus:latest
        ports:
        - containerPort: 9090
        volumeMounts:
        - name: prometheus-config
          mountPath: /etc/prometheus
        - name: prometheus-storage
          mountPath: /prometheus
        args:
        - '--config.file=/etc/prometheus/prometheus.yml'
        - '--storage.tsdb.path=/prometheus'
        - '--web.console.libraries=/etc/prometheus/console_libraries'
        - '--web.console.templates=/etc/prometheus/consoles'
        - '--storage.tsdb.retention.time=200h'
        - '--web.enable-lifecycle'
      volumes:
      - name: prometheus-config
        configMap:
          name: prometheus-config
      - name: prometheus-storage
        emptyDir: {}
---
apiVersion: v1
kind: Service
metadata:
  name: prometheus
  namespace: monitoring
spec:
  selector:
    app: prometheus
  ports:
  - port: 9090
    targetPort: 9090
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: prometheus-config
  namespace: monitoring
data:
  prometheus.yml: |
    global:
      scrape_interval: 15s

    scrape_configs:
    - job_name: 'prometheus'
      static_configs:
      - targets: ['localhost:9090']

    - job_name: 'kubernetes-apiservers'
      kubernetes_sd_configs:
      - role: endpoints
      scheme: https
      tls_config:
        ca_file: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt
      bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token
      relabel_configs:
      - source_labels: [__meta_kubernetes_namespace, __meta_kubernetes_service_name, __meta_kubernetes_endpoint_port_name]
        action: keep
        regex: default;kubernetes;https

    - job_name: 'kubernetes-nodes'
      kubernetes_sd_configs:
      - role: node
      scheme: https
      tls_config:
        ca_file: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt
      bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token
EOF

# Deploy Grafana
kubectl apply -f - << 'EOF'
apiVersion: apps/v1
kind: Deployment
metadata:
  name: grafana
  namespace: monitoring
spec:
  replicas: 1
  selector:
    matchLabels:
      app: grafana
  template:
    metadata:
      labels:
        app: grafana
    spec:
      containers:
      - name: grafana
        image: grafana/grafana:latest
        ports:
        - containerPort: 3000
        env:
        - name: GF_SECURITY_ADMIN_PASSWORD
          value: admin123
        volumeMounts:
        - name: grafana-storage
          mountPath: /var/lib/grafana
      volumes:
      - name: grafana-storage
        emptyDir: {}
---
apiVersion: v1
kind: Service
metadata:
  name: grafana
  namespace: monitoring
spec:
  selector:
    app: grafana
  ports:
  - port: 3000
    targetPort: 3000
  type: LoadBalancer
EOF

# Create monitoring management script
sudo tee /usr/local/bin/k8s-monitoring.sh << 'EOF'
#!/bin/bash
# Kubernetes Monitoring Management Script

case "$1" in
    status)
        echo "=== Monitoring Stack Status ==="
        kubectl get pods -n monitoring
        echo ""
        kubectl get services -n monitoring
        ;;

    prometheus-url)
        echo "=== Prometheus Access ==="
        echo "Port forward: kubectl port-forward -n monitoring svc/prometheus 9090:9090"
        echo "URL: http://localhost:9090"
        ;;

    grafana-url)
        echo "=== Grafana Access ==="
        echo "Port forward: kubectl port-forward -n monitoring svc/grafana 3000:3000"
        echo "URL: http://localhost:3000"
        echo "Username: admin"
        echo "Password: admin123"
        ;;

    logs)
        if [ -z "$2" ]; then
            echo "Usage: $0 logs <prometheus|grafana>"
            exit 1
        fi
        kubectl logs -n monitoring deployment/$2 --tail=50
        ;;

    *)
        echo "Usage: $0 {status|prometheus-url|grafana-url|logs}"
        ;;
esac
EOF

sudo chmod +x /usr/local/bin/k8s-monitoring.sh

echo "Monitoring and logging stack deployed successfully!"

🚨 Fix Common Problems

Here are solutions to common Kubernetes cluster issues you might encounter! 🔧

Problem 1: Pods Stuck in Pending State ❌

# Check pod status and events
kubectl get pods --all-namespaces | grep Pending
kubectl describe pod <pod-name> -n <namespace>

# Check node resources
kubectl top nodes
kubectl describe nodes

# Check for resource constraints
kubectl get events --all-namespaces --sort-by='.lastTimestamp' | grep -i "insufficient"

# Check for scheduling issues
kubectl get pods -o wide | grep Pending

# Check taints and tolerations
kubectl describe nodes | grep -A 5 Taints

# Common fixes:
echo "Common solutions for pending pods:"
echo "1. Check if nodes have sufficient CPU/Memory"
echo "2. Verify pod resource requests are reasonable"
echo "3. Check for node taints blocking scheduling"
echo "4. Ensure storage is available for PVC claims"

# Add more resources to nodes or reduce pod requests
# Example: Remove taints from master node
kubectl taint nodes master-node node-role.kubernetes.io/control-plane:NoSchedule-

# Check after fixes
kubectl get pods --all-namespaces

echo "✅ Pending pod issues diagnosed!"

Problem 2: Service Discovery and DNS Issues ❌

# Check CoreDNS status
kubectl get pods -n kube-system -l k8s-app=kube-dns

# Test DNS resolution from a pod
kubectl run -it --rm debug --image=busybox --restart=Never -- nslookup kubernetes.default

# Check CoreDNS configuration
kubectl get configmap coredns -n kube-system -o yaml

# Test service connectivity
kubectl get services --all-namespaces

# Create debug pod for network testing
kubectl apply -f - << 'EOF'
apiVersion: v1
kind: Pod
metadata:
  name: network-debug
spec:
  containers:
  - name: debug
    image: nicolaka/netshoot
    command: ["sleep", "3600"]
EOF

# Wait for pod to be ready
kubectl wait --for=condition=ready pod network-debug --timeout=60s

# Test DNS from debug pod
kubectl exec -it network-debug -- nslookup kubernetes.default.svc.cluster.local

# Test service connectivity
kubectl exec -it network-debug -- curl http://kubernetes.default:443 -k

# Check iptables rules (on nodes)
sudo iptables -t nat -L | grep -i kube

# Restart CoreDNS if needed
kubectl rollout restart deployment coredns -n kube-system

# Clean up debug pod
kubectl delete pod network-debug

echo "✅ DNS and service discovery issues resolved!"

Problem 3: Network Plugin Issues ❌

# Check Flannel status
kubectl get pods -n kube-flannel -o wide

# Check Flannel logs
kubectl logs -n kube-flannel -l app=flannel --tail=50

# Check node network configuration
ip addr show flannel.1
ip route show | grep flannel

# Verify CNI configuration
ls -la /etc/cni/net.d/
cat /etc/cni/net.d/10-flannel.conflist

# Check for network policy conflicts
kubectl get networkpolicy --all-namespaces

# Test pod-to-pod connectivity
kubectl run test1 --image=busybox --restart=Never -- sleep 3600
kubectl run test2 --image=busybox --restart=Never -- sleep 3600

# Get pod IPs
POD1_IP=$(kubectl get pod test1 -o jsonpath='{.status.podIP}')
POD2_IP=$(kubectl get pod test2 -o jsonpath='{.status.podIP}')

# Test connectivity
kubectl exec test1 -- ping -c 3 $POD2_IP

# Reinstall Flannel if needed
kubectl delete -f https://github.com/flannel-io/flannel/releases/latest/download/kube-flannel.yml
kubectl apply -f https://github.com/flannel-io/flannel/releases/latest/download/kube-flannel.yml

# Clean up test pods
kubectl delete pod test1 test2

echo "✅ Network plugin issues resolved!"

Problem 4: Storage and Persistent Volume Issues ❌

# Check storage classes
kubectl get storageclass

# Check persistent volumes
kubectl get pv

# Check persistent volume claims
kubectl get pvc --all-namespaces

# Check for failed PVC bindings
kubectl get events --all-namespaces | grep -i "persistentvolume"

# Describe failed PVC
kubectl describe pvc <pvc-name> -n <namespace>

# Check node storage
df -h

# Create test storage
sudo mkdir -p /mnt/disk{1,2,3}
sudo chmod 777 /mnt/disk{1,2,3}

# Create additional persistent volumes
for i in {2..3}; do
kubectl apply -f - << EOF
apiVersion: v1
kind: PersistentVolume
metadata:
  name: local-pv-$i
spec:
  capacity:
    storage: 10Gi
  accessModes:
  - ReadWriteOnce
  persistentVolumeReclaimPolicy: Retain
  storageClassName: local-storage
  local:
    path: /mnt/disk$i
  nodeAffinity:
    required:
      nodeSelectorTerms:
      - matchExpressions:
        - key: kubernetes.io/hostname
          operator: In
          values:
          - $(kubectl get nodes -o jsonpath='{.items[0].metadata.name}')
EOF
done

# Test PVC creation
kubectl apply -f - << 'EOF'
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: test-pvc
spec:
  accessModes:
  - ReadWriteOnce
  resources:
    requests:
      storage: 5Gi
  storageClassName: local-storage
EOF

# Check PVC status
kubectl get pvc test-pvc

# Clean up test PVC
kubectl delete pvc test-pvc

echo "✅ Storage and PV issues resolved!"

📋 Simple Commands Summary

Here’s a quick reference for essential Kubernetes cluster management commands! 📚

💡 Tips for Success

Here are expert tips to make your Kubernetes cluster even better! 🌟

Cluster Management Excellence 🎯

• 📊 Resource monitoring: Regularly monitor node and pod resource usage
• 🔄 Rolling updates: Use rolling updates for zero-downtime deployments
• 💾 Backup strategy: Implement etcd backups and disaster recovery
• 🎛️ Resource quotas: Set resource quotas to prevent resource exhaustion
• 📈 Autoscaling: Implement horizontal and vertical pod autoscaling

Security Best Practices 🛡️

• 🔐 RBAC: Implement Role-Based Access Control for fine-grained permissions
• 🚫 Network policies: Use network policies to restrict pod communication
• 📝 Pod security: Implement pod security standards and admission controllers
• 🔍 Image scanning: Scan container images for vulnerabilities
• 🎛️ Secrets management: Use Kubernetes secrets for sensitive data

Performance Optimization ⚡

• 🎯 Resource requests: Set appropriate CPU and memory requests/limits
• 📊 Node sizing: Right-size nodes based on workload requirements
• 🔄 Efficient scheduling: Use node affinity and anti-affinity rules
• 💾 Storage optimization: Choose appropriate storage classes for workloads
• 🌐 Network optimization: Optimize CNI plugin configuration

Operational Excellence 🏢

• 📚 GitOps: Implement GitOps for configuration management
• 🎛️ Monitoring: Deploy comprehensive monitoring with Prometheus/Grafana
• 👥 Documentation: Maintain clear documentation of cluster architecture
• 📊 Capacity planning: Monitor usage and plan for growth
• 🔧 Automation: Automate cluster operations and maintenance tasks

🏆 What You Learned

Congratulations! You’ve successfully mastered AlmaLinux Kubernetes container orchestration! Here’s everything you’ve accomplished: 🎉

✅ Cluster Setup: Built a complete multi-node Kubernetes cluster from scratch ✅ Container Runtime: Configured containerd runtime for optimal performance ✅ Network Configuration: Set up Flannel CNI for pod-to-pod communication ✅ Storage Management: Implemented persistent storage with local volumes ✅ Application Deployment: Deployed multi-tier applications and microservices ✅ Service Discovery: Configured services and ingress for external access ✅ Monitoring Stack: Deployed Prometheus and Grafana for cluster monitoring ✅ Security Implementation: Applied network policies and RBAC controls ✅ Troubleshooting Skills: Learned to diagnose and fix common cluster issues ✅ Operational Tools: Created management scripts for daily operations

🎯 Why This Matters

Building a production-ready Kubernetes cluster is fundamental to modern application deployment! 🌍 Here’s the real-world impact of what you’ve accomplished:

For Modern Applications: Your Kubernetes cluster enables cloud-native application architectures with microservices, containerization, and automated scaling that handle millions of users. 🏗️

For DevOps Practices: Container orchestration provides the foundation for CI/CD pipelines, automated deployments, and infrastructure-as-code practices that accelerate development cycles. 🚀

For Operational Excellence: Kubernetes provides self-healing, automatic scaling, and efficient resource utilization that reduces operational overhead and improves reliability. 📈

For Business Agility: Your cluster enables rapid application deployment, easy scaling, and consistent environments from development to production, accelerating time-to-market. ⚡

Your AlmaLinux Kubernetes cluster is now providing the container orchestration platform that powers modern cloud-native applications with automatic scaling, self-healing, and enterprise-grade reliability! You’re not just running containers – you’re operating the infrastructure platform that enables modern application architecture! ⭐

Continue exploring advanced Kubernetes features like service mesh, serverless computing with Knative, and multi-cluster management. The container orchestration expertise you’ve developed is essential for modern infrastructure! 🙌
