🔄 AlmaLinux Reverse Proxy Setup: Complete Nginx Gateway Configuration Guide

Welcome to the comprehensive AlmaLinux Nginx reverse proxy configuration guide! 🎉 A reverse proxy is the backbone of modern web architecture, acting as an intelligent gateway that sits between clients and your backend services. Whether you’re building a microservices architecture, implementing API gateways, or creating scalable web applications, Nginx reverse proxy provides the performance, security, and flexibility you need! 🌟

Setting up a reverse proxy might seem complex, but it’s actually one of the most powerful tools in modern web infrastructure. By the end of this guide, you’ll have a robust Nginx reverse proxy that can handle SSL termination, load balancing, caching, and intelligent routing for enterprise-grade applications! 🚀

🤔 Why is Reverse Proxy Important?

Reverse proxies are absolutely essential for modern web architecture! Here’s why setting up Nginx as a reverse proxy is incredibly valuable: ✨

🛡️ Security Layer: Hide backend servers and add security filtering at the edge
⚡ Performance Boost: Cache responses and reduce backend server load
🔐 SSL Termination: Handle encryption/decryption centrally for all services
📈 Load Distribution: Intelligently distribute traffic across multiple backend servers
🌐 API Gateway: Centralize API management, authentication, and rate limiting
🎯 Request Routing: Route requests based on URL, headers, or geographic location
💾 Compression: Compress responses to reduce bandwidth usage
🔄 Health Monitoring: Monitor backend server health and route around failures
📊 Analytics: Centralized logging and monitoring for all web traffic
🚀 Scalability: Enable horizontal scaling without client-side changes

🎯 What You Need

Before we start building your Nginx reverse proxy, make sure you have these essentials ready:

✅ AlmaLinux 9.x server with root or sudo access ✅ Minimum 2GB RAM and 10GB disk space ✅ Static IP address for the proxy server ✅ Backend servers to proxy requests to ✅ Basic networking knowledge (we’ll guide you through everything!) ✅ Terminal/SSH access to your server ✅ Text editor familiarity (nano, vim, or gedit) ✅ Firewall admin access for port configuration ✅ SSL certificates (optional but recommended) ✅ Domain names pointing to your proxy server

📝 Step 1: System Preparation and Nginx Installation

Let’s start by preparing your AlmaLinux system and installing Nginx! 🎯

# Update system packages to latest versions
sudo dnf update -y

# Install Nginx web server
sudo dnf install -y nginx

# Install additional tools for SSL and monitoring
sudo dnf install -y openssl curl wget htop

# Install network utilities for troubleshooting
sudo dnf install -y net-tools tcpdump nmap telnet

# Check installed Nginx version
nginx -v

# Check Nginx modules
nginx -V 2>&1 | grep -o with-[a-z_-]*

# Verify system resources
free -h
df -h

# Check network configuration
ip addr show
hostname -f

# Test network connectivity
ping -c 3 google.com

# Check if any web server is already running
sudo ss -tlnp | grep -E ":80|:443"

Expected output:

Complete!
nginx version: nginx/1.20.1
with-http_ssl_module
with-http_realip_module
with-http_addition_module
with-http_sub_module
with-http_dav_module
with-http_flv_module
with-http_mp4_module
with-http_gunzip_module
with-http_gzip_static_module

              total        used        free      shared  buff/cache   available
Mem:           2.0Gi       350Mi       1.3Gi        12Mi       320Mi       1.4Gi

Perfect! 🌟 Nginx is installed with all necessary modules for reverse proxy functionality!

🔧 Step 2: Configure Basic Reverse Proxy

Create a comprehensive Nginx reverse proxy configuration! ⚡

# Backup original Nginx configuration
sudo cp /etc/nginx/nginx.conf /etc/nginx/nginx.conf.backup

# Create new main Nginx configuration
sudo tee /etc/nginx/nginx.conf << 'EOF'
# Nginx Reverse Proxy Configuration

user nginx;
worker_processes auto;
error_log /var/log/nginx/error.log warn;
pid /run/nginx.pid;

# Load dynamic modules
include /usr/share/nginx/modules/*.conf;

events {
    worker_connections 1024;
    use epoll;
    multi_accept on;
}

http {
    # Basic settings
    log_format main '$remote_addr - $remote_user [$time_local] "$request" '
                    '$status $body_bytes_sent "$http_referer" '
                    '"$http_user_agent" "$http_x_forwarded_for"';

    # Enhanced log format for reverse proxy
    log_format proxy '$remote_addr - $remote_user [$time_local] "$request" '
                     '$status $body_bytes_sent "$http_referer" '
                     '"$http_user_agent" "$http_x_forwarded_for" '
                     'rt=$request_time uct="$upstream_connect_time" '
                     'uht="$upstream_header_time" urt="$upstream_response_time"';

    access_log /var/log/nginx/access.log proxy;

    sendfile on;
    tcp_nopush on;
    tcp_nodelay on;
    keepalive_timeout 65;
    types_hash_max_size 4096;
    server_tokens off;

    include /etc/nginx/mime.types;
    default_type application/octet-stream;

    # Gzip compression
    gzip on;
    gzip_vary on;
    gzip_min_length 10240;
    gzip_proxied expired no-cache no-store private must-revalidate auth;
    gzip_types
        text/plain
        text/css
        text/xml
        text/javascript
        application/x-javascript
        application/javascript
        application/xml+rss
        application/json;

    # Rate limiting
    limit_req_zone $binary_remote_addr zone=api:10m rate=10r/s;
    limit_req_zone $binary_remote_addr zone=login:10m rate=1r/s;

    # Upstream backend servers
    upstream backend_web {
        least_conn;
        server 192.168.1.101:8080 weight=3 max_fails=3 fail_timeout=30s;
        server 192.168.1.102:8080 weight=3 max_fails=3 fail_timeout=30s;
        server 192.168.1.103:8080 weight=1 max_fails=3 fail_timeout=30s backup;
        keepalive 32;
    }

    upstream backend_api {
        least_conn;
        server 192.168.1.111:3000 weight=5 max_fails=2 fail_timeout=20s;
        server 192.168.1.112:3000 weight=5 max_fails=2 fail_timeout=20s;
        server 192.168.1.113:3000 weight=3 max_fails=2 fail_timeout=20s;
        keepalive 64;
    }

    upstream backend_static {
        server 192.168.1.121:80 weight=1;
        server 192.168.1.122:80 weight=1;
        keepalive 16;
    }

    # SSL configuration
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers ECDHE-RSA-AES128-GCM-SHA256:ECDHE-RSA-AES256-GCM-SHA384:ECDHE-RSA-AES128-SHA256:ECDHE-RSA-AES256-SHA384;
    ssl_prefer_server_ciphers off;
    ssl_session_cache shared:SSL:10m;
    ssl_session_timeout 10m;

    # Include server configurations
    include /etc/nginx/conf.d/*.conf;
}
EOF

# Create the main reverse proxy server configuration
sudo tee /etc/nginx/conf.d/reverse-proxy.conf << 'EOF'
# Main Reverse Proxy Server Configuration

# HTTP to HTTPS redirect
server {
    listen 80;
    server_name _;
    return 301 https://$host$request_uri;
}

# Main HTTPS reverse proxy
server {
    listen 443 ssl http2;
    server_name proxy.company.local;

    # SSL certificates
    ssl_certificate /etc/ssl/nginx/nginx.crt;
    ssl_certificate_key /etc/ssl/nginx/nginx.key;

    # Security headers
    add_header X-Frame-Options "SAMEORIGIN" always;
    add_header X-XSS-Protection "1; mode=block" always;
    add_header X-Content-Type-Options "nosniff" always;
    add_header Referrer-Policy "no-referrer-when-downgrade" always;
    add_header Content-Security-Policy "default-src 'self' http: https: data: blob: 'unsafe-inline'" always;
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;

    # Main web application
    location / {
        proxy_pass http://backend_web;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection 'upgrade';
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_cache_bypass $http_upgrade;

        # Timeouts
        proxy_connect_timeout 60s;
        proxy_send_timeout 60s;
        proxy_read_timeout 60s;

        # Buffer settings
        proxy_buffer_size 4k;
        proxy_buffers 100 8k;
        proxy_busy_buffers_size 16k;
        proxy_temp_file_write_size 64k;
    }

    # API endpoints with rate limiting
    location /api/ {
        limit_req zone=api burst=20 nodelay;

        proxy_pass http://backend_api/;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection 'upgrade';
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_cache_bypass $http_upgrade;

        # API-specific timeouts
        proxy_connect_timeout 30s;
        proxy_send_timeout 30s;
        proxy_read_timeout 30s;
    }

    # Static content with caching
    location /static/ {
        proxy_pass http://backend_static/;
        proxy_http_version 1.1;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Caching for static content
        proxy_cache static_cache;
        proxy_cache_valid 200 301 302 1h;
        proxy_cache_valid 404 1m;
        proxy_cache_use_stale error timeout invalid_header updating;
        add_header X-Cache-Status $upstream_cache_status;

        expires 1y;
        add_header Cache-Control "public, immutable";
    }

    # Health check endpoint
    location /nginx-health {
        access_log off;
        return 200 "healthy\n";
        add_header Content-Type text/plain;
    }
}

# Cache configuration
proxy_cache_path /var/cache/nginx/static levels=1:2 keys_zone=static_cache:10m inactive=60m use_temp_path=off;
EOF

# Test Nginx configuration syntax
sudo nginx -t

# Create necessary directories
sudo mkdir -p /var/cache/nginx/static
sudo mkdir -p /etc/ssl/nginx

# Set proper ownership
sudo chown -R nginx:nginx /var/cache/nginx/

Expected output:

nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
nginx: configuration file /etc/nginx/nginx.conf test is successful

Excellent! ✅ Basic reverse proxy configuration is created and validated!

🌟 Step 3: Configure SSL/TLS Termination

Set up SSL certificates and secure connections for the reverse proxy! 🔐

# Generate self-signed SSL certificate for testing
sudo openssl req -x509 -nodes -days 365 -newkey rsa:2048 \
    -keyout /etc/ssl/nginx/nginx.key \
    -out /etc/ssl/nginx/nginx.crt \
    -subj "/C=US/ST=State/L=City/O=Company/OU=IT Department/CN=$(hostname -f)"

# Set secure permissions for SSL files
sudo chmod 600 /etc/ssl/nginx/nginx.key
sudo chmod 644 /etc/ssl/nginx/nginx.crt
sudo chown root:root /etc/ssl/nginx/nginx.*

# Create SSL certificate management script
sudo tee /usr/local/bin/manage-proxy-ssl.sh << 'EOF'
#!/bin/bash
# SSL Certificate Management for Nginx Reverse Proxy

CERT_DIR="/etc/ssl/nginx"
DOMAIN="$2"

case "$1" in
    generate)
        if [ -z "$DOMAIN" ]; then
            echo "Usage: $0 generate <domain>"
            exit 1
        fi

        echo "Generating SSL certificate for $DOMAIN..."

        # Generate private key
        openssl genrsa -out "$CERT_DIR/${DOMAIN}.key" 2048

        # Generate certificate signing request
        openssl req -new -key "$CERT_DIR/${DOMAIN}.key" \
            -out "$CERT_DIR/${DOMAIN}.csr" \
            -subj "/C=US/ST=State/L=City/O=Company/CN=$DOMAIN"

        # Generate self-signed certificate
        openssl x509 -req -days 365 \
            -in "$CERT_DIR/${DOMAIN}.csr" \
            -signkey "$CERT_DIR/${DOMAIN}.key" \
            -out "$CERT_DIR/${DOMAIN}.crt"

        # Set permissions
        chmod 600 "$CERT_DIR/${DOMAIN}.key"
        chmod 644 "$CERT_DIR/${DOMAIN}.crt"

        echo "Certificate generated for $DOMAIN"
        ;;

    install)
        if [ -z "$DOMAIN" ]; then
            echo "Usage: $0 install <domain>"
            echo "Place certificate in /tmp/${DOMAIN}.crt and key in /tmp/${DOMAIN}.key"
            exit 1
        fi

        if [ ! -f "/tmp/${DOMAIN}.crt" ] || [ ! -f "/tmp/${DOMAIN}.key" ]; then
            echo "Certificate files not found in /tmp/"
            exit 1
        fi

        # Install certificate
        cp "/tmp/${DOMAIN}.crt" "$CERT_DIR/"
        cp "/tmp/${DOMAIN}.key" "$CERT_DIR/"

        # Set permissions
        chmod 600 "$CERT_DIR/${DOMAIN}.key"
        chmod 644 "$CERT_DIR/${DOMAIN}.crt"

        echo "Certificate installed for $DOMAIN"
        ;;

    renew)
        if [ -z "$DOMAIN" ]; then
            echo "Usage: $0 renew <domain>"
            exit 1
        fi

        # Renew with Let's Encrypt (requires certbot)
        if command -v certbot >/dev/null; then
            certbot certonly --webroot -w /var/www/html -d "$DOMAIN"

            # Copy to nginx directory
            cp "/etc/letsencrypt/live/${DOMAIN}/fullchain.pem" "$CERT_DIR/${DOMAIN}.crt"
            cp "/etc/letsencrypt/live/${DOMAIN}/privkey.pem" "$CERT_DIR/${DOMAIN}.key"

            # Set permissions
            chmod 600 "$CERT_DIR/${DOMAIN}.key"
            chmod 644 "$CERT_DIR/${DOMAIN}.crt"

            # Reload nginx
            nginx -s reload

            echo "Certificate renewed for $DOMAIN"
        else
            echo "Certbot not installed. Install with: dnf install certbot"
        fi
        ;;

    list)
        echo "=== SSL Certificates ==="
        for cert in "$CERT_DIR"/*.crt; do
            if [ -f "$cert" ]; then
                domain=$(basename "$cert" .crt)
                echo "Domain: $domain"
                openssl x509 -in "$cert" -noout -subject -dates
                echo ""
            fi
        done
        ;;

    test)
        if [ -z "$DOMAIN" ]; then
            DOMAIN=$(hostname -f)
        fi

        echo "Testing SSL certificate for $DOMAIN..."

        # Test certificate validity
        openssl x509 -in "$CERT_DIR/nginx.crt" -text -noout | grep -E "(Subject|Not After)"

        # Test SSL connection
        echo | openssl s_client -servername "$DOMAIN" -connect localhost:443 2>/dev/null | \
            openssl x509 -noout -subject -dates

        echo "SSL test completed"
        ;;

    *)
        echo "Usage: $0 {generate|install|renew|list|test} [domain]"
        echo "Examples:"
        echo "  $0 generate api.company.com"
        echo "  $0 install api.company.com"
        echo "  $0 renew api.company.com"
        echo "  $0 list"
        echo "  $0 test"
        ;;
esac
EOF

# Make SSL management script executable
sudo chmod +x /usr/local/bin/manage-proxy-ssl.sh

# Create advanced SSL configuration for different domains
sudo tee /etc/nginx/conf.d/ssl-domains.conf << 'EOF'
# Multi-domain SSL configuration

# API subdomain
server {
    listen 443 ssl http2;
    server_name api.company.local;

    ssl_certificate /etc/ssl/nginx/nginx.crt;
    ssl_certificate_key /etc/ssl/nginx/nginx.key;

    # API-specific settings
    client_max_body_size 10m;

    location / {
        limit_req zone=api burst=10 nodelay;

        proxy_pass http://backend_api;
        proxy_http_version 1.1;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # API headers
        add_header X-API-Version "v1.0" always;
        add_header X-RateLimit-Limit "100" always;
    }
}

# Admin subdomain with IP restrictions
server {
    listen 443 ssl http2;
    server_name admin.company.local;

    ssl_certificate /etc/ssl/nginx/nginx.crt;
    ssl_certificate_key /etc/ssl/nginx/nginx.key;

    # Restrict access to admin networks
    allow 192.168.1.0/24;
    allow 10.0.0.0/8;
    deny all;

    location / {
        proxy_pass http://backend_web;
        proxy_http_version 1.1;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Admin-specific headers
        add_header X-Content-Type-Options nosniff always;
        add_header X-Frame-Options DENY always;
    }
}

# Static content subdomain
server {
    listen 443 ssl http2;
    server_name static.company.local;

    ssl_certificate /etc/ssl/nginx/nginx.crt;
    ssl_certificate_key /etc/ssl/nginx/nginx.key;

    location / {
        proxy_pass http://backend_static;
        proxy_http_version 1.1;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Aggressive caching for static content
        proxy_cache static_cache;
        proxy_cache_valid 200 301 302 24h;
        proxy_cache_valid 404 10m;
        proxy_cache_lock on;
        proxy_cache_use_stale error timeout updating;

        expires 1y;
        add_header Cache-Control "public, immutable";
        add_header X-Cache-Status $upstream_cache_status;
    }
}
EOF

# Test SSL certificate
sudo /usr/local/bin/manage-proxy-ssl.sh test

echo "SSL/TLS termination configured successfully!"

Expected output:

Generating a RSA private key
......+++++
......+++++
writing new private key to '/etc/ssl/nginx/nginx.key'
-----
Certificate generated for proxy.company.local
Subject: C = US, ST = State, L = City, O = Company, OU = IT Department, CN = proxy.company.local
Not After : Sep 17 16:30:45 2026 GMT
SSL/TLS termination configured successfully!

Amazing! 🌟 SSL/TLS termination is configured with multi-domain support!

✅ Step 4: Configure Firewall and Start Services

Set up firewall rules and start Nginx services! 🔥

# Enable and start firewalld
sudo systemctl enable firewalld
sudo systemctl start firewalld

# Add HTTP and HTTPS services to firewall
sudo firewall-cmd --permanent --add-service=http
sudo firewall-cmd --permanent --add-service=https

# Add custom ports if needed
sudo firewall-cmd --permanent --add-port=8080/tcp
sudo firewall-cmd --permanent --add-port=3000/tcp

# Add SSH for remote management
sudo firewall-cmd --permanent --add-service=ssh

# Reload firewall rules
sudo firewall-cmd --reload

# Verify firewall configuration
sudo firewall-cmd --list-all

# Configure SELinux for Nginx
sudo setsebool -P httpd_can_network_connect 1
sudo setsebool -P httpd_can_network_relay 1

# Check SELinux status
getsebool -a | grep httpd

# Enable and start Nginx service
sudo systemctl enable nginx
sudo systemctl start nginx

# Check service status
sudo systemctl status nginx

# Verify Nginx is listening on correct ports
sudo ss -tlnp | grep nginx

# Test reverse proxy functionality
curl -I http://localhost/
curl -k -I https://localhost/

# Check Nginx processes
ps aux | grep nginx

Expected output:

success
success
success
public (active)
  services: ssh http https
  ports: 8080/tcp 3000/tcp

httpd_can_network_connect --> on
httpd_can_network_relay --> on

● nginx.service - The nginx HTTP and reverse proxy server
     Loaded: loaded (/usr/lib/systemd/system/nginx.service; enabled)
     Active: active (running) since Tue 2025-09-17 16:45:15 EDT

LISTEN 0 128 *:80 *:* users:(("nginx",pid=1234,fd=6))
LISTEN 0 128 *:443 *:* users:(("nginx",pid=1234,fd=7))

Perfect! 🎉 Nginx reverse proxy is running and ready to handle traffic!

🔧 Step 5: Configure Advanced Features

Implement advanced reverse proxy features for enterprise use! 📊

# Create advanced caching configuration
sudo tee /etc/nginx/conf.d/advanced-cache.conf << 'EOF'
# Advanced Caching Configuration

# Cache zones
proxy_cache_path /var/cache/nginx/api levels=1:2 keys_zone=api_cache:50m inactive=60m use_temp_path=off;
proxy_cache_path /var/cache/nginx/images levels=1:2 keys_zone=image_cache:100m inactive=24h use_temp_path=off;
proxy_cache_path /var/cache/nginx/dynamic levels=1:2 keys_zone=dynamic_cache:30m inactive=10m use_temp_path=off;

# Cache bypass conditions
map $request_method $no_cache {
    default 0;
    POST 1;
    PUT 1;
    DELETE 1;
}

map $http_cache_control $no_cache_cc {
    default 0;
    "no-cache" 1;
    "no-store" 1;
    "private" 1;
}

server {
    listen 443 ssl http2;
    server_name cache.company.local;

    ssl_certificate /etc/ssl/nginx/nginx.crt;
    ssl_certificate_key /etc/ssl/nginx/nginx.key;

    # API caching with smart invalidation
    location /api/ {
        proxy_pass http://backend_api/;

        proxy_cache api_cache;
        proxy_cache_key "$scheme$request_method$host$request_uri";
        proxy_cache_valid 200 301 302 10m;
        proxy_cache_valid 404 1m;
        proxy_cache_bypass $no_cache $no_cache_cc;
        proxy_no_cache $no_cache $no_cache_cc;

        # Cache control headers
        add_header X-Cache-Status $upstream_cache_status;
        add_header X-Cache-Key "$scheme$request_method$host$request_uri";

        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }

    # Image caching with long expiration
    location ~* \.(jpg|jpeg|png|gif|ico|svg|webp)$ {
        proxy_pass http://backend_static;

        proxy_cache image_cache;
        proxy_cache_valid 200 30d;
        proxy_cache_valid 404 1h;
        proxy_cache_lock on;
        proxy_cache_use_stale error timeout updating;

        expires 30d;
        add_header Cache-Control "public, immutable";
        add_header X-Cache-Status $upstream_cache_status;

        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }

    # Dynamic content with short-term caching
    location / {
        proxy_pass http://backend_web;

        proxy_cache dynamic_cache;
        proxy_cache_valid 200 5m;
        proxy_cache_valid 404 30s;
        proxy_cache_bypass $arg_nocache $cookie_nocache;

        add_header X-Cache-Status $upstream_cache_status;

        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}
EOF

# Create load balancing and health check configuration
sudo tee /etc/nginx/conf.d/load-balancing.conf << 'EOF'
# Advanced Load Balancing Configuration

# Health check upstream
upstream backend_health {
    zone backend_health 64k;

    server 192.168.1.101:8080 max_fails=2 fail_timeout=30s;
    server 192.168.1.102:8080 max_fails=2 fail_timeout=30s;
    server 192.168.1.103:8080 max_fails=2 fail_timeout=30s backup;

    keepalive 32;
    keepalive_requests 100;
    keepalive_timeout 60s;
}

# Geographic load balancing
geo $backend_pool {
    default backend_web;
    192.168.1.0/24 backend_web;
    10.0.0.0/8 backend_api;
}

server {
    listen 443 ssl http2;
    server_name lb.company.local;

    ssl_certificate /etc/ssl/nginx/nginx.crt;
    ssl_certificate_key /etc/ssl/nginx/nginx.key;

    # Health check endpoint
    location /health {
        access_log off;
        return 200 "healthy\n";
        add_header Content-Type text/plain;
    }

    # Upstream health check
    location /upstream-health {
        proxy_pass http://backend_health/health;
        proxy_set_header Host $host;
        proxy_connect_timeout 5s;
        proxy_read_timeout 5s;
        access_log off;
    }

    # Main application with geographic routing
    location / {
        proxy_pass http://$backend_pool;
        proxy_http_version 1.1;
        proxy_set_header Connection "";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Circuit breaker
        proxy_next_upstream error timeout http_500 http_502 http_503 http_504;
        proxy_next_upstream_tries 3;
        proxy_next_upstream_timeout 30s;
    }
}
EOF

# Create monitoring and metrics configuration
sudo tee /etc/nginx/conf.d/monitoring.conf << 'EOF'
# Monitoring and Metrics Configuration

server {
    listen 8080;
    server_name localhost;

    # Metrics endpoint (basic)
    location /nginx-status {
        stub_status on;
        access_log off;
        allow 127.0.0.1;
        allow 192.168.1.0/24;
        deny all;
    }

    # Detailed metrics (if nginx-plus)
    location /api {
        api write=on;
        access_log off;
        allow 127.0.0.1;
        allow 192.168.1.0/24;
        deny all;
    }

    # Cache status
    location /cache-status {
        access_log off;
        return 200 "Cache Status: OK\n";
        add_header Content-Type text/plain;
    }
}
EOF

# Create cache management scripts
sudo tee /usr/local/bin/manage-nginx-cache.sh << 'EOF'
#!/bin/bash
# Nginx Cache Management

CACHE_DIR="/var/cache/nginx"

case "$1" in
    clear)
        echo "Clearing all Nginx caches..."
        sudo rm -rf $CACHE_DIR/*/
        sudo systemctl reload nginx
        echo "Cache cleared"
        ;;

    clear-api)
        echo "Clearing API cache..."
        sudo rm -rf $CACHE_DIR/api/
        echo "API cache cleared"
        ;;

    clear-images)
        echo "Clearing image cache..."
        sudo rm -rf $CACHE_DIR/images/
        echo "Image cache cleared"
        ;;

    status)
        echo "=== Cache Status ==="
        echo "API Cache:"
        du -sh $CACHE_DIR/api/ 2>/dev/null || echo "  No cache data"

        echo "Image Cache:"
        du -sh $CACHE_DIR/images/ 2>/dev/null || echo "  No cache data"

        echo "Static Cache:"
        du -sh $CACHE_DIR/static/ 2>/dev/null || echo "  No cache data"

        echo "Dynamic Cache:"
        du -sh $CACHE_DIR/dynamic/ 2>/dev/null || echo "  No cache data"

        echo "Total Cache Size:"
        du -sh $CACHE_DIR/ 2>/dev/null || echo "  No cache data"
        ;;

    stats)
        echo "=== Cache Statistics ==="
        curl -s http://localhost:8080/nginx-status
        ;;

    *)
        echo "Usage: $0 {clear|clear-api|clear-images|status|stats}"
        ;;
esac
EOF

# Make cache management script executable
sudo chmod +x /usr/local/bin/manage-nginx-cache.sh

# Create necessary cache directories
sudo mkdir -p /var/cache/nginx/{api,images,dynamic}
sudo chown -R nginx:nginx /var/cache/nginx/

# Test advanced configuration
sudo nginx -t

# Reload Nginx with new configuration
sudo systemctl reload nginx

echo "Advanced reverse proxy features configured!"

Expected output:

nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
nginx: configuration file /etc/nginx/nginx.conf test is successful
Advanced reverse proxy features configured!

Excellent! ✅ Advanced features including caching, load balancing, and monitoring are configured!

🎮 Quick Examples

Here are practical examples of using your Nginx reverse proxy in real scenarios! 🌟

Example 1: Microservices API Gateway 🏗️

# Configure Nginx as a microservices API gateway
sudo tee /etc/nginx/conf.d/api-gateway.conf << 'EOF'
# Microservices API Gateway Configuration

# Service upstreams
upstream user_service {
    server 192.168.1.201:3001 weight=2;
    server 192.168.1.202:3001 weight=2;
    server 192.168.1.203:3001 weight=1 backup;
    keepalive 16;
}

upstream order_service {
    server 192.168.1.211:3002 weight=3;
    server 192.168.1.212:3002 weight=3;
    keepalive 16;
}

upstream payment_service {
    server 192.168.1.221:3003 weight=1;
    server 192.168.1.222:3003 weight=1;
    keepalive 8;
}

upstream notification_service {
    server 192.168.1.231:3004;
    keepalive 8;
}

# Rate limiting zones
limit_req_zone $binary_remote_addr zone=auth:10m rate=5r/s;
limit_req_zone $binary_remote_addr zone=users:10m rate=10r/s;
limit_req_zone $binary_remote_addr zone=orders:10m rate=15r/s;
limit_req_zone $binary_remote_addr zone=payments:10m rate=2r/s;

server {
    listen 443 ssl http2;
    server_name api.company.com;

    ssl_certificate /etc/ssl/nginx/nginx.crt;
    ssl_certificate_key /etc/ssl/nginx/nginx.key;

    # Global API settings
    client_max_body_size 10m;

    # CORS headers
    add_header 'Access-Control-Allow-Origin' '*' always;
    add_header 'Access-Control-Allow-Methods' 'GET, POST, PUT, DELETE, OPTIONS' always;
    add_header 'Access-Control-Allow-Headers' 'Accept,Authorization,Cache-Control,Content-Type,DNT,If-Modified-Since,Keep-Alive,Origin,User-Agent,X-Requested-With' always;

    # API versioning
    location ~ ^/api/v([0-9]+)/ {
        set $api_version $1;

        # Version-specific routing
        if ($api_version = "1") {
            rewrite ^/api/v1/(.*)$ /v1/$1 break;
        }
        if ($api_version = "2") {
            rewrite ^/api/v2/(.*)$ /v2/$1 break;
        }

        proxy_pass http://backend_api;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_set_header X-API-Version $api_version;
    }

    # Authentication service
    location /api/auth/ {
        limit_req zone=auth burst=10 nodelay;

        proxy_pass http://user_service/auth/;
        proxy_http_version 1.1;
        proxy_set_header Connection "";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # No caching for auth
        proxy_cache_bypass 1;
        proxy_no_cache 1;
    }

    # User service
    location /api/users/ {
        limit_req zone=users burst=20 nodelay;

        # JWT token validation (add auth_request if available)
        # auth_request /auth;

        proxy_pass http://user_service/;
        proxy_http_version 1.1;
        proxy_set_header Connection "";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Cache user data for 5 minutes
        proxy_cache api_cache;
        proxy_cache_valid 200 5m;
        proxy_cache_key "$scheme$request_method$host$request_uri$http_authorization";
    }

    # Order service
    location /api/orders/ {
        limit_req zone=orders burst=30 nodelay;

        proxy_pass http://order_service/;
        proxy_http_version 1.1;
        proxy_set_header Connection "";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Longer timeout for complex order processing
        proxy_read_timeout 120s;
        proxy_send_timeout 120s;
    }

    # Payment service (high security)
    location /api/payments/ {
        limit_req zone=payments burst=5 nodelay;

        # Additional security headers
        add_header X-Content-Type-Options nosniff always;
        add_header X-Frame-Options DENY always;

        proxy_pass http://payment_service/;
        proxy_http_version 1.1;
        proxy_set_header Connection "";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # No caching for payments
        proxy_cache_bypass 1;
        proxy_no_cache 1;

        # Strict timeouts
        proxy_read_timeout 60s;
        proxy_send_timeout 60s;
    }

    # Notification service
    location /api/notifications/ {
        proxy_pass http://notification_service/;
        proxy_http_version 1.1;
        proxy_set_header Connection "";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Async processing, don't wait for response
        proxy_buffering off;
    }

    # WebSocket support for real-time features
    location /api/ws/ {
        proxy_pass http://notification_service/ws/;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # WebSocket timeouts
        proxy_read_timeout 86400;
        proxy_send_timeout 86400;
    }

    # API documentation
    location /docs/ {
        root /var/www/api-docs;
        try_files $uri $uri/ /index.html;

        expires 1h;
        add_header Cache-Control "public";
    }
}
EOF

# Create API gateway management script
sudo tee /usr/local/bin/manage-api-gateway.sh << 'EOF'
#!/bin/bash
# API Gateway Management Script

case "$1" in
    status)
        echo "=== API Gateway Status ==="
        curl -s http://localhost:8080/nginx-status

        echo -e "\n=== Service Health ==="
        services=(user_service order_service payment_service notification_service)
        for service in "${services[@]}"; do
            echo "Checking $service..."
            # Add actual health check URLs here
        done
        ;;

    reload)
        echo "Reloading API Gateway configuration..."
        sudo nginx -t && sudo systemctl reload nginx
        ;;

    metrics)
        echo "=== API Metrics ==="
        echo "Total requests: $(curl -s http://localhost:8080/nginx-status | grep requests | awk '{print $3}')"
        echo "Active connections: $(curl -s http://localhost:8080/nginx-status | grep Active | awk '{print $3}')"
        ;;

    *)
        echo "Usage: $0 {status|reload|metrics}"
        ;;
esac
EOF

sudo chmod +x /usr/local/bin/manage-api-gateway.sh

echo "Microservices API Gateway configured"

Example 2: Content Delivery Network (CDN) Setup 🌐

# Configure Nginx as a CDN edge server
sudo tee /etc/nginx/conf.d/cdn.conf << 'EOF'
# CDN Edge Server Configuration

# Origin servers
upstream origin_images {
    server 192.168.1.101:80 weight=3;
    server 192.168.1.102:80 weight=3;
    server 192.168.1.103:80 weight=1 backup;
    keepalive 32;
}

upstream origin_videos {
    server 192.168.1.111:80 weight=2;
    server 192.168.1.112:80 weight=2;
    keepalive 16;
}

upstream origin_static {
    server 192.168.1.121:80;
    server 192.168.1.122:80;
    keepalive 16;
}

# Enhanced cache configuration
proxy_cache_path /var/cache/nginx/cdn-images levels=1:2 keys_zone=cdn_images:200m inactive=7d max_size=10g use_temp_path=off;
proxy_cache_path /var/cache/nginx/cdn-videos levels=1:2 keys_zone=cdn_videos:500m inactive=30d max_size=50g use_temp_path=off;
proxy_cache_path /var/cache/nginx/cdn-static levels=1:2 keys_zone=cdn_static:100m inactive=1d max_size=5g use_temp_path=off;

server {
    listen 443 ssl http2;
    server_name cdn.company.com;

    ssl_certificate /etc/ssl/nginx/nginx.crt;
    ssl_certificate_key /etc/ssl/nginx/nginx.key;

    # Global settings
    client_max_body_size 100m;

    # Image delivery with optimization
    location ~* \.(jpg|jpeg|png|gif|webp|svg|ico)$ {
        proxy_pass http://origin_images;

        # Aggressive caching
        proxy_cache cdn_images;
        proxy_cache_valid 200 301 302 30d;
        proxy_cache_valid 404 10m;
        proxy_cache_lock on;
        proxy_cache_lock_timeout 5s;
        proxy_cache_use_stale error timeout updating http_500 http_502 http_503 http_504;
        proxy_cache_background_update on;

        # Cache headers
        add_header X-Cache-Status $upstream_cache_status always;
        add_header X-Cache-Date $upstream_http_date;

        # Client-side caching
        expires 30d;
        add_header Cache-Control "public, immutable";
        add_header Vary "Accept-Encoding";

        # Image optimization headers
        add_header Accept-CH "DPR, Viewport-Width, Width";

        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Range requests for large images
        proxy_set_header Range $http_range;
        proxy_set_header If-Range $http_if_range;
    }

    # Video delivery with range support
    location ~* \.(mp4|webm|ogg|avi|mov|wmv|flv|3gp)$ {
        proxy_pass http://origin_videos;

        # Video caching
        proxy_cache cdn_videos;
        proxy_cache_valid 200 206 301 302 7d;
        proxy_cache_valid 404 1h;
        proxy_cache_lock on;
        proxy_cache_use_stale error timeout updating http_500 http_502 http_503 http_504;

        # Range request support
        proxy_set_header Range $http_range;
        proxy_set_header If-Range $http_if_range;

        # Headers
        add_header X-Cache-Status $upstream_cache_status always;
        add_header Accept-Ranges bytes;

        expires 7d;
        add_header Cache-Control "public";

        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # Larger buffers for video
        proxy_buffering on;
        proxy_buffer_size 8k;
        proxy_buffers 32 8k;
    }

    # Static assets (CSS, JS, fonts)
    location ~* \.(css|js|woff|woff2|ttf|eot)$ {
        proxy_pass http://origin_static;

        proxy_cache cdn_static;
        proxy_cache_valid 200 301 302 1d;
        proxy_cache_valid 404 1h;
        proxy_cache_use_stale error timeout updating http_500 http_502 http_503 http_504;

        # Compression
        gzip_static on;

        add_header X-Cache-Status $upstream_cache_status always;

        expires 1d;
        add_header Cache-Control "public";
        add_header Vary "Accept-Encoding";

        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }

    # Cache purge endpoint (restricted access)
    location ~ /purge(/.*) {
        allow 192.168.1.0/24;
        deny all;

        proxy_cache_purge cdn_images "$scheme$request_method$host$1";
        proxy_cache_purge cdn_videos "$scheme$request_method$host$1";
        proxy_cache_purge cdn_static "$scheme$request_method$host$1";
    }

    # CDN statistics
    location /cdn-stats {
        allow 192.168.1.0/24;
        deny all;

        access_log off;
        return 200 "CDN Statistics\n";
        add_header Content-Type text/plain;
    }
}
EOF

# Create CDN management script
sudo tee /usr/local/bin/manage-cdn.sh << 'EOF'
#!/bin/bash
# CDN Management Script

CDN_CACHE="/var/cache/nginx"

case "$1" in
    stats)
        echo "=== CDN Cache Statistics ==="
        echo "Images: $(du -sh $CDN_CACHE/cdn-images/ 2>/dev/null | cut -f1)"
        echo "Videos: $(du -sh $CDN_CACHE/cdn-videos/ 2>/dev/null | cut -f1)"
        echo "Static: $(du -sh $CDN_CACHE/cdn-static/ 2>/dev/null | cut -f1)"
        echo "Total: $(du -sh $CDN_CACHE/ 2>/dev/null | cut -f1)"

        echo -e "\n=== Cache Hit Rates ==="
        # Parse access logs for cache hit rates
        tail -n 1000 /var/log/nginx/access.log | grep -o 'X-Cache-Status: [A-Z]*' | sort | uniq -c
        ;;

    purge)
        if [ -z "$2" ]; then
            echo "Usage: $0 purge <path>"
            echo "Example: $0 purge /images/logo.png"
            exit 1
        fi

        echo "Purging cache for: $2"
        curl -X PURGE "http://localhost/purge$2"
        ;;

    clear)
        echo "Clearing all CDN caches..."
        sudo rm -rf $CDN_CACHE/cdn-*
        echo "CDN cache cleared"
        ;;

    *)
        echo "Usage: $0 {stats|purge <path>|clear}"
        ;;
esac
EOF

sudo chmod +x /usr/local/bin/manage-cdn.sh

# Create CDN cache directories
sudo mkdir -p /var/cache/nginx/{cdn-images,cdn-videos,cdn-static}
sudo chown -R nginx:nginx /var/cache/nginx/

echo "CDN configuration complete"

Example 3: Web Application Firewall (WAF) Integration 🛡️

# Configure Nginx with WAF capabilities
sudo tee /etc/nginx/conf.d/waf.conf << 'EOF'
# Web Application Firewall Configuration

# Security maps
map $http_user_agent $blocked_agent {
    default 0;
    ~*malicious 1;
    ~*scanner 1;
    ~*bot 1;
    ~*crawler 0;  # Allow legitimate crawlers
}

map $request_uri $blocked_uri {
    default 0;
    ~*/\.\. 1;  # Directory traversal
    ~*\.(php|asp|jsp)$ 1;  # Script execution
    ~*/admin/phpmyadmin 1;  # Admin tools
    ~*/wp-admin 1;  # WordPress admin (if not using WordPress)
}

map $args $blocked_args {
    default 0;
    ~*union.*select 1;  # SQL injection
    ~*<script 1;  # XSS
    ~*javascript: 1;  # JavaScript injection
    ~*vbscript: 1;  # VBScript injection
}

# Rate limiting zones
limit_req_zone $binary_remote_addr zone=waf_general:10m rate=10r/s;
limit_req_zone $binary_remote_addr zone=waf_login:10m rate=1r/m;
limit_req_zone $binary_remote_addr zone=waf_api:10m rate=100r/m;

# Connection limiting
limit_conn_zone $binary_remote_addr zone=addr:10m;

server {
    listen 443 ssl http2;
    server_name secure.company.com;

    ssl_certificate /etc/ssl/nginx/nginx.crt;
    ssl_certificate_key /etc/ssl/nginx/nginx.key;

    # WAF rules
    if ($blocked_agent) {
        return 444;  # Drop connection
    }

    if ($blocked_uri) {
        return 403;
    }

    if ($blocked_args) {
        return 403;
    }

    # Connection limits
    limit_conn addr 10;

    # Security headers
    add_header X-Frame-Options "SAMEORIGIN" always;
    add_header X-XSS-Protection "1; mode=block" always;
    add_header X-Content-Type-Options "nosniff" always;
    add_header Referrer-Policy "strict-origin-when-cross-origin" always;
    add_header Content-Security-Policy "default-src 'self'; script-src 'self' 'unsafe-inline'; style-src 'self' 'unsafe-inline';" always;
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains; preload" always;

    # Login protection
    location /login {
        limit_req zone=waf_login burst=5 nodelay;

        # Additional login security
        if ($request_method !~ ^(GET|POST)$) {
            return 405;
        }

        proxy_pass http://backend_web;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;

        # No caching for login
        proxy_cache_bypass 1;
        proxy_no_cache 1;
    }

    # API endpoints with protection
    location /api/ {
        limit_req zone=waf_api burst=200 nodelay;

        # Content length limit
        client_max_body_size 1m;

        # Request method filtering
        if ($request_method !~ ^(GET|POST|PUT|DELETE|HEAD|OPTIONS)$) {
            return 405;
        }

        proxy_pass http://backend_api/;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }

    # File upload protection
    location /upload {
        limit_req zone=waf_general burst=10 nodelay;

        # File size limits
        client_max_body_size 10m;

        # File type restrictions
        location ~* \.(php|phtml|php3|php4|php5|pl|py|jsp|asp|sh|cgi)$ {
            return 403;
        }

        proxy_pass http://backend_web;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }

    # Main application
    location / {
        limit_req zone=waf_general burst=20 nodelay;

        proxy_pass http://backend_web;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }

    # Block common attack patterns
    location ~* \.(git|svn|hg)/ {
        return 404;
    }

    location ~* \.(ini|conf|config|log)$ {
        return 404;
    }
}
EOF

echo "WAF configuration complete"

🚨 Fix Common Problems

Here are solutions to common Nginx reverse proxy issues you might encounter! 🔧

Problem 1: Backend Connection Failures ❌

# Check backend server connectivity
for backend in 192.168.1.101 192.168.1.102 192.168.1.103; do
    echo "Testing backend $backend..."
    curl -I http://$backend:8080/ || echo "Backend $backend is not responding"
done

# Check Nginx upstream configuration
grep -A 10 "upstream" /etc/nginx/nginx.conf

# Test upstream health
curl http://localhost:8080/nginx-status

# Check proxy_pass directives
grep -r "proxy_pass" /etc/nginx/conf.d/

# Debug proxy connections
sudo nginx -T | grep -E "(upstream|proxy_pass)"

# Enable debug logging temporarily
sudo tee /etc/nginx/conf.d/debug.conf << 'EOF'
error_log /var/log/nginx/debug.log debug;

server {
    listen 8888;
    location / {
        proxy_pass http://backend_web;
        proxy_set_header Host $host;
        access_log /var/log/nginx/debug_access.log;
    }
}
EOF

sudo systemctl reload nginx

# Test with debug server
curl http://localhost:8888/

# Check debug logs
sudo tail -f /var/log/nginx/debug.log

# Fix common backend issues
echo "Common fixes:"
echo "1. Check backend servers are running"
echo "2. Verify firewall allows connections"
echo "3. Check SELinux: setsebool -P httpd_can_network_connect 1"
echo "4. Verify upstream IP addresses and ports"

echo "✅ Backend connection issues diagnosed!"

Problem 2: SSL/TLS Certificate Problems ❌

# Test SSL certificate validity
sudo /usr/local/bin/manage-proxy-ssl.sh test

# Check SSL configuration
sudo nginx -T | grep -A 20 ssl

# Test SSL handshake
openssl s_client -connect localhost:443 -servername $(hostname -f) < /dev/null

# Check certificate files
ls -la /etc/ssl/nginx/
sudo openssl x509 -in /etc/ssl/nginx/nginx.crt -text -noout | grep -E "(Subject|Not After)"

# Verify certificate chain
openssl verify /etc/ssl/nginx/nginx.crt

# Test different SSL protocols
openssl s_client -connect localhost:443 -tls1_2 < /dev/null
openssl s_client -connect localhost:443 -tls1_3 < /dev/null

# Check for mixed content issues
curl -k -H "Host: api.company.local" https://localhost/api/health

# Generate new certificate if needed
sudo /usr/local/bin/manage-proxy-ssl.sh generate $(hostname -f)

# Test with new certificate
curl -k -I https://localhost/

echo "✅ SSL certificate issues resolved!"

Problem 3: Caching Not Working Properly ❌

# Check cache status
sudo /usr/local/bin/manage-nginx-cache.sh status

# Test cache headers
curl -I http://localhost/static/test.css
curl -I https://localhost/api/test

# Check cache configuration
grep -A 10 "proxy_cache" /etc/nginx/conf.d/

# Verify cache directories exist and have correct permissions
ls -la /var/cache/nginx/
sudo chown -R nginx:nginx /var/cache/nginx/

# Clear cache and test
sudo /usr/local/bin/manage-nginx-cache.sh clear

# Test cache functionality
echo "Testing cache..."
time curl -s http://localhost/static/large-file.jpg > /dev/null
time curl -s http://localhost/static/large-file.jpg > /dev/null

# Check cache hit/miss ratios
tail -n 100 /var/log/nginx/access.log | grep -o 'X-Cache-Status: [A-Z]*' | sort | uniq -c

# Enable cache debugging
sudo tee -a /etc/nginx/conf.d/cache-debug.conf << 'EOF'
location /debug-cache/ {
    proxy_pass http://backend_static/;
    proxy_cache static_cache;
    proxy_cache_valid 200 1m;

    add_header X-Cache-Status $upstream_cache_status always;
    add_header X-Cache-Key "$scheme$request_method$host$request_uri" always;
    add_header X-Cache-Debug "Cache-Path: /var/cache/nginx/static" always;
}
EOF

sudo systemctl reload nginx

echo "✅ Caching issues resolved!"

Problem 4: High CPU and Memory Usage ❌

# Monitor Nginx performance
top -p $(pgrep nginx)
ps aux | grep nginx

# Check worker process configuration
grep worker_processes /etc/nginx/nginx.conf

# Monitor connections
watch -n 1 'ss -s'

# Check for memory leaks
sudo valgrind nginx -t

# Optimize worker configuration
sudo tee -a /etc/nginx/nginx.conf << 'EOF'
# Performance optimizations
worker_processes auto;
worker_cpu_affinity auto;
worker_rlimit_nofile 65535;

events {
    worker_connections 4096;
    use epoll;
    multi_accept on;
}
EOF

# Optimize buffer sizes
sudo tee -a /etc/nginx/conf.d/performance.conf << 'EOF'
# Buffer optimizations
client_body_buffer_size 128k;
client_max_body_size 10m;
client_header_buffer_size 1k;
large_client_header_buffers 4 4k;
output_buffers 1 32k;
postpone_output 1460;

# Timeouts
client_header_timeout 30s;
client_body_timeout 30s;
keepalive_timeout 30s;
send_timeout 30s;

# File operations
sendfile on;
tcp_nopush on;
tcp_nodelay on;
EOF

# Check for excessive logging
du -sh /var/log/nginx/

# Rotate logs if needed
sudo logrotate -f /etc/logrotate.d/nginx

# Monitor after optimizations
sudo systemctl reload nginx
htop -p $(pgrep nginx)

echo "✅ Performance optimizations applied!"

📋 Simple Commands Summary

Here’s a quick reference for essential Nginx reverse proxy management commands! 📚

Command Category	Command	Description
Service Management	`sudo systemctl start nginx`	Start Nginx service
	`sudo systemctl stop nginx`	Stop Nginx service
	`sudo systemctl restart nginx`	Restart Nginx service
	`sudo systemctl reload nginx`	Reload configuration
Configuration	`nginx -t`	Test configuration syntax
	`nginx -T`	Test and dump configuration
	`sudo nano /etc/nginx/nginx.conf`	Edit main configuration
	`sudo nano /etc/nginx/conf.d/site.conf`	Edit site configuration
SSL Management	`/usr/local/bin/manage-proxy-ssl.sh list`	List SSL certificates
	`/usr/local/bin/manage-proxy-ssl.sh generate domain.com`	Generate certificate
	`openssl s_client -connect localhost:443`	Test SSL connection
Cache Management	`/usr/local/bin/manage-nginx-cache.sh status`	Check cache status
	`/usr/local/bin/manage-nginx-cache.sh clear`	Clear all cache
	`/usr/local/bin/manage-nginx-cache.sh clear-api`	Clear API cache
Monitoring	`curl http://localhost:8080/nginx-status`	View basic statistics
	`tail -f /var/log/nginx/access.log`	Monitor access logs
	`tail -f /var/log/nginx/error.log`	Monitor error logs
Backend Testing	`curl -I http://backend-server:8080/`	Test backend connectivity
	`telnet backend-server 8080`	Test TCP connection
Load Testing	`ab -n 1000 -c 10 http://localhost/`	Apache Bench load test
	`curl -w "@curl-format.txt" http://localhost/`	Detailed timing info

💡 Tips for Success

Here are expert tips to make your Nginx reverse proxy even better! 🌟

Performance Optimization ⚡

🎯 Worker tuning: Set worker_processes to match CPU cores
📊 Connection limits: Optimize worker_connections based on memory
🔄 Keep-alive: Use HTTP keep-alive to reduce connection overhead
💾 Buffer optimization: Tune proxy buffers for your content size
🌐 Compression: Enable gzip compression for text content

Security Best Practices 🛡️

🔐 SSL configuration: Use strong ciphers and disable weak protocols
🚫 Rate limiting: Implement rate limiting to prevent abuse
📝 Security headers: Add comprehensive security headers
🔍 WAF rules: Implement web application firewall rules
🎛️ Access control: Use IP allowlists for sensitive endpoints

Caching Excellence 💾

🎯 Cache zones: Configure appropriate cache zones for different content
📊 Cache keys: Use smart cache keys to avoid cache pollution
🔄 Cache invalidation: Implement proper cache purging mechanisms
💽 Storage planning: Plan cache storage based on content volume
📈 Hit rate monitoring: Monitor and optimize cache hit rates

Operational Excellence 🏢

📚 Configuration management: Use version control for configurations
🎛️ Monitoring: Implement comprehensive monitoring and alerting
👥 Documentation: Maintain clear documentation of proxy rules
📊 Capacity planning: Monitor usage and plan for growth
🔧 Automation: Automate configuration deployment and updates

🏆 What You Learned

Congratulations! You’ve successfully mastered AlmaLinux Nginx reverse proxy configuration! Here’s everything you’ve accomplished: 🎉

✅ Reverse Proxy Setup: Installed and configured enterprise-grade Nginx reverse proxy ✅ SSL Termination: Implemented secure HTTPS with certificate management ✅ Load Balancing: Set up intelligent traffic distribution across backend servers ✅ Advanced Caching: Configured multi-tier caching for optimal performance ✅ API Gateway: Created microservices API gateway with routing and security ✅ CDN Capabilities: Built content delivery network functionality ✅ WAF Integration: Implemented web application firewall protection ✅ Monitoring Tools: Set up comprehensive monitoring and metrics ✅ Performance Tuning: Optimized for high-traffic applications ✅ Troubleshooting Skills: Learned to diagnose and fix proxy issues

🎯 Why This Matters

Building robust reverse proxy infrastructure is fundamental to modern web architecture! 🌍 Here’s the real-world impact of what you’ve accomplished:

For Application Architecture: Your Nginx reverse proxy enables microservices architecture, API gateways, and modern application patterns that scale horizontally and provide better security isolation. 🏗️

For Performance: By implementing caching, compression, and intelligent routing, you’ve dramatically improved application performance and reduced backend server load. ⚡

For Security: SSL termination, WAF capabilities, and centralized security controls provide enterprise-grade protection for all your applications behind the proxy. 🛡️

For Scalability: Your reverse proxy setup enables seamless scaling, zero-downtime deployments, and efficient resource utilization across your entire infrastructure. 📈

Your AlmaLinux Nginx reverse proxy is now providing the intelligent gateway that powers modern web applications with high performance, security, and scalability! You’re not just proxying requests – you’re operating the critical infrastructure layer that enables modern application architecture! ⭐

Continue exploring advanced Nginx features like service mesh integration, advanced load balancing algorithms, and cloud-native reverse proxy patterns. The reverse proxy expertise you’ve developed is essential for modern infrastructure! 🙌

🔄 AlmaLinux Reverse Proxy Setup: Complete Nginx Gateway Configuration Guide

Table of Contents

🔄 AlmaLinux Reverse Proxy Setup: Complete Nginx Gateway Configuration Guide

🤔 Why is Reverse Proxy Important?

🎯 What You Need

📝 Step 1: System Preparation and Nginx Installation

🔧 Step 2: Configure Basic Reverse Proxy

🌟 Step 3: Configure SSL/TLS Termination

✅ Step 4: Configure Firewall and Start Services

🔧 Step 5: Configure Advanced Features

🎮 Quick Examples

Example 1: Microservices API Gateway 🏗️

Example 2: Content Delivery Network (CDN) Setup 🌐

Example 3: Web Application Firewall (WAF) Integration 🛡️

🚨 Fix Common Problems

Problem 1: Backend Connection Failures ❌

Problem 2: SSL/TLS Certificate Problems ❌

Problem 3: Caching Not Working Properly ❌

Problem 4: High CPU and Memory Usage ❌

📋 Simple Commands Summary

💡 Tips for Success

Performance Optimization ⚡

Security Best Practices 🛡️

Caching Excellence 💾

Operational Excellence 🏢

🏆 What You Learned

🎯 Why This Matters

Share this article

🔄 AlmaLinux Reverse Proxy Setup: Complete Nginx Gateway Configuration Guide

Table of Contents

🔄 AlmaLinux Reverse Proxy Setup: Complete Nginx Gateway Configuration Guide

🤔 Why is Reverse Proxy Important?

🎯 What You Need

📝 Step 1: System Preparation and Nginx Installation

🔧 Step 2: Configure Basic Reverse Proxy

🌟 Step 3: Configure SSL/TLS Termination

✅ Step 4: Configure Firewall and Start Services

🔧 Step 5: Configure Advanced Features

🎮 Quick Examples

Example 1: Microservices API Gateway 🏗️

Example 2: Content Delivery Network (CDN) Setup 🌐

Example 3: Web Application Firewall (WAF) Integration 🛡️

🚨 Fix Common Problems

Problem 1: Backend Connection Failures ❌

Problem 2: SSL/TLS Certificate Problems ❌

Problem 3: Caching Not Working Properly ❌

Problem 4: High CPU and Memory Usage ❌

📋 Simple Commands Summary

💡 Tips for Success

Performance Optimization ⚡

Security Best Practices 🛡️

Caching Excellence 💾

Operational Excellence 🏢

🏆 What You Learned

🎯 Why This Matters

Share this article

Related Articles

🚢 AlmaLinux Container Orchestration: Complete Kubernetes Setup Guide

⚖️ AlmaLinux Load Balancer Setup: Complete HAProxy High Availability Guide

🔄 Nginx Reverse Proxy and Load Balancing on AlmaLinux: Scale Like a Pro

Scan QR Code
