๐ Jaeger Distributed Tracing Setup on AlmaLinux 9: Complete Installation and Configuration Guide
Welcome to the exciting world of distributed tracing! ๐ Today weโre going to learn how to set up Jaeger on AlmaLinux 9, the powerful tracing platform that helps you monitor and troubleshoot your microservices. Think of Jaeger as your detective tool that follows requests through your entire application stack! ๐ต๏ธโโ๏ธโจ
๐ค Why is Jaeger Important?
Distributed tracing is like having X-ray vision for your applications! ๐ When you have multiple services talking to each other, it becomes really hard to understand whatโs happening when something goes wrong. Hereโs why Jaeger is awesome:
- ๐ Track requests across multiple services and see the complete journey
- โก Find performance bottlenecks and slow database queries instantly
- ๐ Debug complex issues that span multiple microservices
- ๐ Visualize service dependencies and understand your architecture
- ๐ฏ Monitor SLA compliance and set up alerts for slow operations
- ๐ก Optimize performance by identifying the slowest parts of your system
๐ฏ What You Need
Before we start our Jaeger adventure, letโs make sure you have everything ready:
โ
AlmaLinux 9 system (fresh installation recommended)
โ
Root or sudo access for installing packages
โ
At least 4GB RAM (8GB recommended for production)
โ
10GB free disk space for traces storage
โ
Internet connection for downloading packages
โ
Basic terminal knowledge (donโt worry, weโll explain everything!)
โ
Docker installed (weโll cover this if you donโt have it)
๐ Step 1: Update Your AlmaLinux System
Letโs start by making sure your system is up to date! ๐
# Update all packages to latest versions
sudo dnf update -y
# Install essential development tools
sudo dnf groupinstall "Development Tools" -y
# Install helpful utilities we'll need
sudo dnf install -y curl wget git vim htop
Perfect! Your system is now ready for Jaeger installation! โจ
๐ง Step 2: Install Docker and Docker Compose
Jaeger works great with Docker containers! Letโs set it up:
# Install Docker from official repository
sudo dnf config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo
# Install Docker Engine
sudo dnf install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin
# Start and enable Docker service
sudo systemctl start docker
sudo systemctl enable docker
# Add your user to docker group (no more sudo needed!)
sudo usermod -aG docker $USER
# Apply group changes (or logout/login)
newgrp docker
# Test Docker installation
docker --version
docker compose version
Great! Docker is ready to run Jaeger! ๐ณ
๐ Step 3: Deploy Jaeger All-in-One
Letโs start with Jaegerโs all-in-one deployment - perfect for learning and development:
# Create directory for Jaeger configuration
mkdir -p ~/jaeger-setup
cd ~/jaeger-setup
# Create docker-compose.yml file for Jaeger
cat > docker-compose.yml << 'EOF'
version: '3.8'
services:
jaeger:
image: jaegertracing/all-in-one:latest
container_name: jaeger-allinone
ports:
- "16686:16686" # Jaeger UI
- "14268:14268" # HTTP collector
- "6831:6831/udp" # UDP Thrift compact
- "6832:6832/udp" # UDP Thrift binary
- "5778:5778" # HTTP configuration
- "14250:14250" # gRPC
environment:
- COLLECTOR_OTLP_ENABLED=true
- COLLECTOR_ZIPKIN_HOST_PORT=9411
volumes:
- jaeger-data:/tmp
networks:
- jaeger-net
restart: unless-stopped
volumes:
jaeger-data:
networks:
jaeger-net:
driver: bridge
EOF
# Start Jaeger services
docker compose up -d
# Check if services are running
docker compose ps
Awesome! Jaeger is now running! ๐
โ Step 4: Verify Jaeger Installation
Letโs make sure everything is working perfectly:
# Check container status
docker ps | grep jaeger
# View Jaeger logs to ensure it started correctly
docker compose logs jaeger
# Test if Jaeger UI is accessible
curl -s http://localhost:16686/api/services | head -n 5
# Check all exposed ports are listening
ss -tuln | grep -E "(16686|14268|6831|6832)"
You should see the Jaeger container running and all ports listening! ๐
Open your web browser and visit: http://your-server-ip:16686
to see the beautiful Jaeger UI! โจ
๐ง Step 5: Configure Jaeger for Production
For production use, letโs create a more robust configuration:
# Create production docker-compose file
cat > docker-compose-prod.yml << 'EOF'
version: '3.8'
services:
elasticsearch:
image: elasticsearch:7.17.0
container_name: jaeger-elasticsearch
environment:
- discovery.type=single-node
- ES_JAVA_OPTS=-Xms1g -Xmx1g
- xpack.security.enabled=false
ports:
- "9200:9200"
volumes:
- elasticsearch-data:/usr/share/elasticsearch/data
networks:
- jaeger-net
jaeger-collector:
image: jaegertracing/jaeger-collector:latest
container_name: jaeger-collector
ports:
- "14269:14269"
- "14268:14268"
- "14250:14250"
environment:
- SPAN_STORAGE_TYPE=elasticsearch
- ES_SERVER_URLS=http://elasticsearch:9200
- COLLECTOR_OTLP_ENABLED=true
depends_on:
- elasticsearch
networks:
- jaeger-net
restart: unless-stopped
jaeger-agent:
image: jaegertracing/jaeger-agent:latest
container_name: jaeger-agent
ports:
- "6831:6831/udp"
- "6832:6832/udp"
- "5778:5778"
environment:
- REPORTER_GRPC_HOST_PORT=jaeger-collector:14250
depends_on:
- jaeger-collector
networks:
- jaeger-net
restart: unless-stopped
jaeger-query:
image: jaegertracing/jaeger-query:latest
container_name: jaeger-query
ports:
- "16686:16686"
environment:
- SPAN_STORAGE_TYPE=elasticsearch
- ES_SERVER_URLS=http://elasticsearch:9200
depends_on:
- elasticsearch
networks:
- jaeger-net
restart: unless-stopped
volumes:
elasticsearch-data:
networks:
jaeger-net:
driver: bridge
EOF
# Deploy production setup (optional)
# docker compose -f docker-compose-prod.yml up -d
This gives you a scalable production setup with Elasticsearch backend! ๐ช
๐ฎ Quick Examples
Letโs try some practical examples to see Jaeger in action! ๐
Example 1: Simple Python Application with Tracing
# Create a simple Python app directory
mkdir ~/python-jaeger-demo
cd ~/python-jaeger-demo
# Create requirements.txt
cat > requirements.txt << 'EOF'
opentelemetry-api==1.20.0
opentelemetry-sdk==1.20.0
opentelemetry-exporter-jaeger-thrift==1.20.0
opentelemetry-instrumentation-requests==0.41b0
flask==2.3.3
requests==2.31.0
EOF
# Install Python packages
pip3 install -r requirements.txt
# Create demo application
cat > app.py << 'EOF'
#!/usr/bin/env python3
import time
import requests
from flask import Flask
from opentelemetry import trace
from opentelemetry.exporter.jaeger.thrift import JaegerExporter
from opentelemetry.sdk.resources import SERVICE_NAME, Resource
from opentelemetry.sdk.trace import TracerProvider
from opentelemetry.sdk.trace.export import BatchSpanProcessor
# Configure tracing
resource = Resource(attributes={SERVICE_NAME: "python-demo-app"})
trace.set_tracer_provider(TracerProvider(resource=resource))
tracer = trace.get_tracer(__name__)
jaeger_exporter = JaegerExporter(
agent_host_name="localhost",
agent_port=6831,
)
span_processor = BatchSpanProcessor(jaeger_exporter)
trace.get_tracer_provider().add_span_processor(span_processor)
app = Flask(__name__)
@app.route('/')
def hello():
with tracer.start_as_current_span("hello-operation"):
with tracer.start_as_current_span("database-query"):
time.sleep(0.1) # Simulate database query
with tracer.start_as_current_span("external-api-call"):
time.sleep(0.05) # Simulate API call
return "Hello from traced Python app! ๐"
@app.route('/slow')
def slow_endpoint():
with tracer.start_as_current_span("slow-operation"):
time.sleep(2) # Simulate slow operation
return "This was slow! โฐ"
if __name__ == '__main__':
app.run(host='0.0.0.0', port=5000)
EOF
# Run the demo app
python3 app.py &
# Generate some traces
curl http://localhost:5000/
curl http://localhost:5000/slow
curl http://localhost:5000/
Now check the Jaeger UI at http://localhost:16686
and search for the python-demo-app
service! ๐ฏ
Example 2: Node.js Microservice with Tracing
# Create Node.js demo
mkdir ~/nodejs-jaeger-demo
cd ~/nodejs-jaeger-demo
# Initialize npm project
npm init -y
# Install dependencies
npm install express @opentelemetry/api @opentelemetry/sdk-node @opentelemetry/exporter-jaeger
# Create traced Node.js app
cat > server.js << 'EOF'
const express = require('express');
const { NodeSDK } = require('@opentelemetry/sdk-node');
const { JaegerExporter } = require('@opentelemetry/exporter-jaeger');
// Initialize tracing
const jaegerExporter = new JaegerExporter({
endpoint: 'http://localhost:14268/api/traces',
});
const sdk = new NodeSDK({
serviceName: 'nodejs-demo-app',
traceExporter: jaegerExporter,
});
sdk.start();
const app = express();
app.get('/', (req, res) => {
// Simulate some processing
setTimeout(() => {
res.json({
message: 'Hello from traced Node.js app! ๐',
timestamp: new Date().toISOString()
});
}, 100);
});
app.get('/api/users', (req, res) => {
// Simulate database query
setTimeout(() => {
res.json([
{ id: 1, name: 'Alice' },
{ id: 2, name: 'Bob' }
]);
}, 200);
});
app.listen(3000, () => {
console.log('Traced Node.js app running on port 3000! ๐');
});
EOF
# Run the Node.js app
node server.js &
# Test the endpoints
curl http://localhost:3000/
curl http://localhost:3000/api/users
Check Jaeger UI for the nodejs-demo-app
service traces! ๐
Example 3: Kubernetes Deployment with Jaeger
# Create Kubernetes manifests directory
mkdir ~/k8s-jaeger
cd ~/k8s-jaeger
# Create Jaeger Operator deployment
cat > jaeger-operator.yaml << 'EOF'
apiVersion: v1
kind: Namespace
metadata:
name: observability
---
apiVersion: apps/v1
kind: Deployment
metadata:
name: jaeger-operator
namespace: observability
spec:
replicas: 1
selector:
matchLabels:
name: jaeger-operator
template:
metadata:
labels:
name: jaeger-operator
spec:
containers:
- name: jaeger-operator
image: jaegertracing/jaeger-operator:latest
ports:
- containerPort: 8383
env:
- name: WATCH_NAMESPACE
value: ""
---
apiVersion: v1
kind: Service
metadata:
name: jaeger-operator-metrics
namespace: observability
spec:
ports:
- name: http-metrics
port: 8383
targetPort: 8383
selector:
name: jaeger-operator
EOF
# Apply if you have Kubernetes cluster
# kubectl apply -f jaeger-operator.yaml
This shows you how to deploy Jaeger in Kubernetes! โ
๐จ Fix Common Problems
Here are solutions to the most common Jaeger issues you might encounter:
Problem 1: Jaeger UI Not Accessible ๐
Symptoms: Canโt access http://localhost:16686
Solutions:
# Check if container is running
docker ps | grep jaeger
# Check port binding
docker port jaeger-allinone
# Restart Jaeger if needed
docker compose restart jaeger
# Check firewall (if applicable)
sudo firewall-cmd --permanent --add-port=16686/tcp
sudo firewall-cmd --reload
Problem 2: No Traces Appearing ๐
Symptoms: Services sending traces but nothing shows in UI
Solutions:
# Check collector endpoint is reachable
curl -v http://localhost:14268/api/traces
# Verify agent ports are listening
ss -tuln | grep 6831
# Check application tracing configuration
# Make sure span_processor is added correctly
# View Jaeger logs for errors
docker compose logs jaeger | grep -i error
Problem 3: High Memory Usage ๐พ
Symptoms: Jaeger consuming too much memory
Solutions:
# Limit memory in docker-compose.yml
cat >> docker-compose.yml << 'EOF'
services:
jaeger:
mem_limit: 1g
mem_reservation: 512m
EOF
# Configure sampling rate to reduce traces
docker run -d \
-e JAEGER_SAMPLER_TYPE=probabilistic \
-e JAEGER_SAMPLER_PARAM=0.1 \
jaegertracing/all-in-one
# Clean up old traces periodically
# (This happens automatically with TTL settings)
Problem 4: Application Not Sending Traces ๐ค
Symptoms: App runs but no traces in Jaeger
Solutions:
# Verify tracing initialization in your code
# Check this Python example:
from opentelemetry import trace
from opentelemetry.sdk.trace import TracerProvider
# Make sure you set the tracer provider!
trace.set_tracer_provider(TracerProvider())
# Test connectivity to Jaeger agent
telnet localhost 6831 # Should connect
# Check for firewall blocking UDP ports
sudo iptables -L | grep 6831
๐ Simple Commands Summary
Hereโs your quick reference guide for managing Jaeger:
Task | Command | Description |
---|---|---|
Start Jaeger | docker compose up -d | Launch all-in-one Jaeger |
Stop Jaeger | docker compose down | Stop and remove containers |
View logs | docker compose logs jaeger | Check Jaeger application logs |
Check status | docker compose ps | See running containers |
Restart service | docker compose restart jaeger | Restart Jaeger container |
Access UI | Open http://localhost:16686 | Open Jaeger web interface |
Health check | curl http://localhost:14269/ | Verify collector health |
Update image | docker compose pull && docker compose up -d | Update to latest version |
๐ก Tips for Success
Here are some pro tips to get the most out of Jaeger! ๐
๐ฏ Configure Smart Sampling: Donโt trace every request in production - use probabilistic sampling (10-20%) to reduce overhead while capturing enough data for analysis.
โก Use Consistent Service Names: Make sure all instances of the same service use identical service names in their tracing configuration for proper aggregation.
๐ Tag Important Operations: Add custom tags to spans for better filtering - like user_id, region, or feature flags.
๐ Monitor Jaeger Itself: Set up monitoring for Jaeger components using Prometheus metrics endpoints.
๐พ Plan Storage Strategy: Traces can grow large quickly - implement proper retention policies and consider using Elasticsearch or Cassandra for production.
๐ Start Simple: Begin with all-in-one deployment for learning, then graduate to production architecture with separate components.
๐ Integrate with APM: Combine Jaeger with metrics (Prometheus) and logs (ELK stack) for complete observability.
๐ What You Learned
Congratulations! Youโve successfully mastered Jaeger distributed tracing! ๐ Hereโs everything you accomplished:
โ
Installed Docker and Docker Compose on AlmaLinux 9
โ
Deployed Jaeger all-in-one for development use
โ
Configured production setup with Elasticsearch backend
โ
Created traced applications in Python and Node.js
โ
Explored the Jaeger UI and learned to analyze traces
โ
Set up Kubernetes deployment with Jaeger Operator
โ
Troubleshot common issues and optimized performance
โ
Learned best practices for production deployments
๐ฏ Why This Matters
Distributed tracing with Jaeger is a game-changer for modern applications! ๐ You can now:
๐ Debug Complex Issues: Track requests across microservices and find exactly where problems occur
โก Optimize Performance: Identify slow database queries, API calls, and bottlenecks instantly
๐ Understand Dependencies: Visualize how your services interact and identify critical paths
๐ก๏ธ Improve Reliability: Set up monitoring and alerts based on trace data to prevent outages
๐ก Make Data-Driven Decisions: Use trace analytics to guide architecture and optimization decisions
Youโre now equipped with enterprise-grade observability skills that are highly valued in DevOps and SRE roles! The ability to implement and manage distributed tracing makes you a more effective developer and system administrator. โญ
Keep exploring, keep tracing, and remember - every request tells a story, and now you know how to read it! ๐โจ
