💾 Rook Ceph Storage on AlmaLinux 9: Complete Guide

Ready to build bulletproof distributed storage? 🚀 Today we’ll deploy Rook Ceph on AlmaLinux 9, creating self-healing, self-scaling storage that never fails! Let’s orchestrate amazing storage! ✨🎯

🤔 Why is Rook Ceph Important?

Imagine storage that manages itself like magic! 🌟 That’s Rook’s superpower! Here’s why it’s revolutionary:

• 🔄 Self-Healing Storage - Automatically recovers from failures!
• 📦 Multi-Protocol - Block, object, and file storage from one system
• 🚀 Auto-Scaling - Grows with your needs automatically
• 🛡️ Data Protection - Multiple replicas ensure no data loss
• 🎯 Kubernetes Native - Storage as Kubernetes resources
• 📊 Built-in Monitoring - Dashboard and Prometheus metrics
• 🌍 Production Ready - CNCF graduated project
• 💡 No Manual Management - Operator handles everything

🎯 What You Need

Before we orchestrate storage magic, gather these:

• ✅ AlmaLinux 9 servers (3+ nodes, 8GB RAM each minimum)
• ✅ Kubernetes cluster 1.28+ (K3s, K8s, or any flavor)
• ✅ Raw disks or partitions (no filesystem)
• ✅ kubectl configured and working
• ✅ 10GB+ free disk per node for OSDs
• ✅ Network connectivity between nodes
• ✅ Root or sudo access
• ✅ Ready for storage revolution! 🎉

📝 Step 1: Prepare AlmaLinux Nodes

Let’s prepare your systems for Ceph! 🛠️

Install Prerequisites

# Update all nodes
sudo dnf update -y  # Keep everything current

# Install required packages
sudo dnf install -y \
  lvm2 \
  python3 \
  python3-pip \
  kernel-modules-extra

# Load RBD kernel module
sudo modprobe rbd
echo "rbd" | sudo tee /etc/modules-load.d/rbd.conf

# Verify kernel modules
lsmod | grep rbd  # Should show rbd module

# Check available disks
lsblk  # Identify raw disks for Ceph
sudo fdisk -l  # Detailed disk information

# Ensure disks are clean (WARNING: destroys data!)
# Replace /dev/sdb with your disk
sudo dd if=/dev/zero of=/dev/sdb bs=1M count=100 status=progress
sudo sgdisk --zap-all /dev/sdb

Prepare Kubernetes Cluster

# Label nodes for Ceph roles
kubectl label nodes node1 node2 node3 node-role.rook-ceph/cluster=true

# Create rook-ceph namespace
kubectl create namespace rook-ceph

# Verify nodes are ready
kubectl get nodes --show-labels
kubectl top nodes  # Check resources

🔧 Step 2: Deploy Rook Operator

Time to install the Rook operator! 🎊

Clone Rook Repository

# Clone specific version
git clone --single-branch --branch v1.14.0 https://github.com/rook/rook.git
cd rook/deploy/examples

# Or download manifests directly
ROOK_VERSION="v1.14.0"
wget https://raw.githubusercontent.com/rook/rook/${ROOK_VERSION}/deploy/examples/crds.yaml
wget https://raw.githubusercontent.com/rook/rook/${ROOK_VERSION}/deploy/examples/common.yaml
wget https://raw.githubusercontent.com/rook/rook/${ROOK_VERSION}/deploy/examples/operator.yaml

Deploy Rook Operator

# Deploy CRDs and common resources
kubectl create -f crds.yaml
kubectl create -f common.yaml

# Configure operator (optional customization)
cat <<EOF > operator-custom.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: rook-ceph-operator
  namespace: rook-ceph
spec:
  replicas: 1
  selector:
    matchLabels:
      app: rook-ceph-operator
  template:
    spec:
      containers:
      - name: rook-ceph-operator
        image: rook/ceph:v1.14.0
        env:
        # Enable discovery daemon
        - name: ROOK_ENABLE_DISCOVERY_DAEMON
          value: "true"
        # Set log level
        - name: ROOK_LOG_LEVEL
          value: "INFO"
        # Resource limits
        resources:
          limits:
            memory: 512Mi
            cpu: 500m
          requests:
            memory: 256Mi
            cpu: 100m
EOF

# Deploy the operator
kubectl create -f operator.yaml

# Wait for operator to be ready
kubectl -n rook-ceph rollout status deployment/rook-ceph-operator
kubectl -n rook-ceph get pods  # Should be Running

🌟 Step 3: Create Ceph Cluster

Let’s deploy the Ceph storage cluster! 🚀

Create Cluster Configuration

# Create production cluster config
cat <<EOF > cluster.yaml
apiVersion: ceph.rook.io/v1
kind: CephCluster
metadata:
  name: rook-ceph
  namespace: rook-ceph
spec:
  cephVersion:
    image: quay.io/ceph/ceph:v18.2.2  # Latest Reef version
    allowUnsupported: false
  dataDirHostPath: /var/lib/rook
  skipUpgradeChecks: false
  continueUpgradeAfterChecksEvenIfNotHealthy: false
  mon:
    count: 3  # Production should have 3 monitors
    allowMultiplePerNode: false
  mgr:
    count: 2  # Active and standby
    modules:
    - name: rook
      enabled: true
  dashboard:
    enabled: true
    ssl: true
  network:
    provider: host  # Use host network for performance
  crashCollector:
    disable: false
  cleanupPolicy:
    confirmation: ""
    sanitizeDisks:
      method: quick
      dataSource: zero
      iteration: 1
  storage:
    useAllNodes: true
    useAllDevices: true
    # deviceFilter: "^sd[b-z]"  # Use specific disks
    config:
      osdsPerDevice: "1"
      storeType: bluestore
  monitoring:
    enabled: true
    metricsDisabled: false
  resources:
    mgr:
      limits:
        memory: "1Gi"
      requests:
        cpu: "500m"
        memory: "512Mi"
    mon:
      limits:
        memory: "2Gi"
      requests:
        cpu: "1000m"
        memory: "1Gi"
    osd:
      limits:
        memory: "4Gi"
      requests:
        cpu: "1000m"
        memory: "2Gi"
EOF

# Deploy the cluster
kubectl create -f cluster.yaml

# Monitor cluster creation (this takes 5-10 minutes)
watch kubectl -n rook-ceph get cephcluster
kubectl -n rook-ceph get pods -w  # Watch pods being created

Verify Cluster Health

# Deploy toolbox for Ceph commands
kubectl create -f toolbox.yaml

# Wait for toolbox
kubectl -n rook-ceph rollout status deployment/rook-ceph-tools

# Check cluster status
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- ceph status
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- ceph osd status
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- ceph df

✅ Step 4: Configure Storage Classes

Let’s create storage for applications! 📦

Create Block Storage

# Create RBD storage pool
cat <<EOF | kubectl apply -f -
apiVersion: ceph.rook.io/v1
kind: CephBlockPool
metadata:
  name: replicapool
  namespace: rook-ceph
spec:
  failureDomain: host
  replicated:
    size: 3  # Number of replicas
    requireSafeReplicaSize: true
EOF

# Create StorageClass
cat <<EOF | kubectl apply -f -
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: rook-ceph-block
provisioner: rook-ceph.rbd.csi.ceph.com
parameters:
  clusterID: rook-ceph
  pool: replicapool
  imageFormat: "2"
  imageFeatures: layering
  csi.storage.k8s.io/provisioner-secret-name: rook-csi-rbd-provisioner
  csi.storage.k8s.io/provisioner-secret-namespace: rook-ceph
  csi.storage.k8s.io/controller-expand-secret-name: rook-csi-rbd-provisioner
  csi.storage.k8s.io/controller-expand-secret-namespace: rook-ceph
  csi.storage.k8s.io/node-stage-secret-name: rook-csi-rbd-node
  csi.storage.k8s.io/node-stage-secret-namespace: rook-ceph
  csi.storage.k8s.io/fstype: ext4
allowVolumeExpansion: true
reclaimPolicy: Delete
EOF

# Test with a PVC
cat <<EOF | kubectl apply -f -
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: test-pvc
spec:
  accessModes:
    - ReadWriteOnce
  storageClassName: rook-ceph-block
  resources:
    requests:
      storage: 5Gi
EOF

# Check PVC is bound
kubectl get pvc test-pvc  # Should be Bound

Create Object Storage

# Create object store
cat <<EOF | kubectl apply -f -
apiVersion: ceph.rook.io/v1
kind: CephObjectStore
metadata:
  name: my-store
  namespace: rook-ceph
spec:
  metadataPool:
    failureDomain: host
    replicated:
      size: 3
  dataPool:
    failureDomain: host
    replicated:
      size: 3
  preservePoolsOnDelete: false
  gateway:
    type: s3
    port: 80
    instances: 2
    resources:
      limits:
        memory: "2Gi"
      requests:
        cpu: "1000m"
        memory: "1Gi"
EOF

# Create StorageClass for object storage
cat <<EOF | kubectl apply -f -
apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: rook-ceph-object
provisioner: rook-ceph.ceph.rook.io/bucket
parameters:
  objectStoreName: my-store
  objectStoreNamespace: rook-ceph
reclaimPolicy: Delete
EOF

🎮 Quick Examples

Let’s explore Rook’s amazing features! 🎬

Example 1: Deploy Application with Storage

# Deploy PostgreSQL with Ceph storage
cat <<EOF | kubectl apply -f -
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: postgres-pvc
spec:
  accessModes:
    - ReadWriteOnce
  storageClassName: rook-ceph-block
  resources:
    requests:
      storage: 10Gi
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: postgres
spec:
  replicas: 1
  selector:
    matchLabels:
      app: postgres
  template:
    metadata:
      labels:
        app: postgres
    spec:
      containers:
      - name: postgres
        image: postgres:15
        env:
        - name: POSTGRES_PASSWORD
          value: "secretpassword"
        - name: PGDATA
          value: /var/lib/postgresql/data/pgdata
        ports:
        - containerPort: 5432
        volumeMounts:
        - name: postgres-storage
          mountPath: /var/lib/postgresql/data
      volumes:
      - name: postgres-storage
        persistentVolumeClaim:
          claimName: postgres-pvc
EOF

# Check deployment
kubectl get pods | grep postgres  # Should be Running
kubectl exec -it deploy/postgres -- df -h  # See Ceph mount

Example 2: Access Ceph Dashboard

# Get dashboard password
kubectl -n rook-ceph get secret rook-ceph-dashboard-password -o jsonpath="{['data']['password']}" | base64 --decode

# Port-forward dashboard
kubectl port-forward -n rook-ceph svc/rook-ceph-mgr-dashboard 8443:8443 &

# Access dashboard
echo "🎨 Dashboard: https://localhost:8443"
echo "Username: admin"
echo "Password: (from above command)"

Example 3: Create S3 User

# Create object store user
cat <<EOF | kubectl apply -f -
apiVersion: ceph.rook.io/v1
kind: CephObjectStoreUser
metadata:
  name: my-user
  namespace: rook-ceph
spec:
  store: my-store
  displayName: "S3 User"
  quotas:
    maxBuckets: 100
    maxSize: "10G"
EOF

# Get S3 credentials
kubectl -n rook-ceph get secret rook-ceph-object-user-my-store-my-user -o yaml

# Access S3 endpoint
kubectl -n rook-ceph get svc rook-ceph-rgw-my-store

🚨 Fix Common Problems

Don’t panic! Here are solutions! 💪

Problem 1: Cluster Not Healthy

# Check cluster status
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- ceph health detail

# Check OSD status
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- ceph osd tree

# Restart unhealthy OSDs
kubectl -n rook-ceph delete pod -l app=rook-ceph-osd

# Check mon quorum
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- ceph mon stat

Problem 2: PVC Not Binding

# Check CSI pods
kubectl -n rook-ceph get pods | grep csi

# Check provisioner logs
kubectl -n rook-ceph logs -l app=csi-rbdplugin-provisioner

# Verify storage pool
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- ceph osd pool ls

# Check StorageClass
kubectl describe storageclass rook-ceph-block

Problem 3: Slow Performance

# Check cluster performance
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- ceph osd perf

# Enable caching
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- \
  ceph osd pool set replicapool cache_target_dirty_ratio 0.4

# Check network latency
kubectl -n rook-ceph exec -it deploy/rook-ceph-tools -- \
  ceph osd ping

📋 Simple Commands Summary

Your Rook command toolkit! 📚

💡 Tips for Success

Master Rook with these pro tips! 🏆

Storage Planning

• 💾 Use dedicated disks for OSDs
• 🔢 Plan for 3x replication overhead
• 📊 Monitor disk usage regularly
• 🎯 Separate metadata and data pools
• ⚡ Use SSDs for metadata pools

Performance Optimization

• 🚀 Use host networking for speed
• 💡 Enable RBD caching
• 📈 Tune OSD memory limits
• 🔄 Balance PGs across OSDs
• 🎯 Use placement groups wisely

Best Practices

• 🛡️ Always maintain quorum (odd number of mons)
• 📝 Document your storage layout
• 🔍 Monitor cluster metrics
• ⚠️ Set up alerts for health issues
• 💾 Regular backup important data
• 🔐 Enable encryption at rest
• 🎨 Use the dashboard for visibility

🏆 What You Learned

Outstanding work! You’re now a Rook expert! 🎉 You can:

• ✅ Deploy Rook operator on AlmaLinux 9
• ✅ Create production Ceph clusters
• ✅ Configure block and object storage
• ✅ Deploy applications with persistent storage
• ✅ Access Ceph dashboard
• ✅ Monitor cluster health
• ✅ Troubleshoot common issues
• ✅ Optimize storage performance

🎯 Why This Matters

You’ve built enterprise-grade distributed storage! 🚀 With Rook:

• Self-Managing - No more manual storage administration
• Highly Available - Survives node and disk failures
• Infinitely Scalable - Add nodes to grow storage
• Multi-Protocol - Block, object, and file from one system
• Cloud Native - Perfect for Kubernetes workloads
• Production Ready - Used by enterprises worldwide
• Cost Effective - Use commodity hardware

Your storage is now as resilient and scalable as cloud providers! No more storage bottlenecks, no more data loss fears. Everything is automated and self-healing.

Keep exploring features like CephFS for shared filesystems, RGW for S3 compatibility, and multi-site replication. You’re running the same storage tech as major clouds! 🌟

Remember: Great apps need great storage - Rook delivers excellence! Happy storing! 🎊💾

P.S. - Join the Rook community, contribute to the project, and share your storage journey! Together we’re revolutionizing Kubernetes storage! ⭐🙌
