Setting Up Edge Computing Platform with K3s on Rocky Linux

Edge computing has become critical for processing data closer to its source, reducing latency, and enabling real-time decision-making. K3s, a lightweight Kubernetes distribution, is perfectly suited for edge deployments where resources are constrained. This comprehensive guide will walk you through building a production-ready edge computing platform using K3s on Rocky Linux.

Understanding Edge Computing Architecture

Edge computing brings computation and data storage closer to data sources. Key benefits include:

Ultra-Low Latency: Sub-millisecond response times for critical applications
Bandwidth Optimization: Process data locally, send only relevant information to cloud
Offline Capability: Continue operating when disconnected from central infrastructure
Data Sovereignty: Keep sensitive data within geographical boundaries
Cost Efficiency: Reduce cloud egress costs and bandwidth requirements

Why K3s for Edge Computing

K3s is optimized for edge deployments:

Lightweight: ~100MB binary, 512MB RAM minimum
Single Binary: Easy deployment and updates
ARM Support: Runs on Raspberry Pi and other ARM devices
Built-in Components: Includes storage, networking, and ingress
Production Ready: CNCF certified Kubernetes distribution

Prerequisites and Planning

Hardware Requirements

For different edge scenarios:

Edge Gateway (Main Node):

Rocky Linux 9
4 CPU cores
8GB RAM
64GB storage
2x Network interfaces

Edge Worker Nodes:

2 CPU cores
4GB RAM
32GB storage
Network connectivity

IoT/Minimal Nodes:

ARM64/AMD64 processor
1GB RAM minimum
16GB storage

Network Architecture

Plan your edge network:

Management Network: 192.168.1.0/24 (Central management)
Edge Network: 10.0.0.0/16 (Edge devices)
IoT Network: 172.16.0.0/12 (IoT devices)
5G/LTE Backup: Failover connectivity

Preparing Rocky Linux for Edge

Initial System Setup

On all edge nodes:

# Set hostname
sudo hostnamectl set-hostname edge-gateway-01

# Update system
sudo dnf update -y

# Install essential packages
sudo dnf install -y curl wget vim git htop iotop sysstat
sudo dnf install -y NetworkManager-tui firewalld

# Configure firewall for K3s
sudo firewall-cmd --permanent --add-port=6443/tcp # API Server
sudo firewall-cmd --permanent --add-port=10250/tcp # Kubelet metrics
sudo firewall-cmd --permanent --add-port=10251/tcp # Scheduler
sudo firewall-cmd --permanent --add-port=10252/tcp # Controller
sudo firewall-cmd --permanent --add-port=8472/udp # Flannel VXLAN
sudo firewall-cmd --permanent --add-port=51820/udp # Flannel WireGuard
sudo firewall-cmd --permanent --add-port=51821/udp # Flannel WireGuard IPv6
sudo firewall-cmd --reload

# Disable swap
sudo swapoff -a
sudo sed -i '/ swap / s/^\(.*\)$/#\1/g' /etc/fstab

# Configure kernel parameters
cat << EOF | sudo tee /etc/sysctl.d/k3s.conf
net.bridge.bridge-nf-call-iptables = 1
net.bridge.bridge-nf-call-ip6tables = 1
net.ipv4.ip_forward = 1
net.ipv6.conf.all.forwarding = 1
vm.swappiness = 0
vm.panic_on_oom = 0
vm.overcommit_memory = 1
kernel.panic = 10
kernel.panic_on_oops = 1
EOF

sudo sysctl --system

Network Configuration for Edge

# Configure multiple network interfaces
# Management interface
sudo nmcli connection modify ens160 connection.id management
sudo nmcli connection modify management ipv4.addresses 192.168.1.10/24
sudo nmcli connection modify management ipv4.gateway 192.168.1.1
sudo nmcli connection modify management ipv4.dns 8.8.8.8
sudo nmcli connection modify management ipv4.method manual

# Edge network interface
sudo nmcli connection add type ethernet con-name edge ifname ens192
sudo nmcli connection modify edge ipv4.addresses 10.0.0.1/16
sudo nmcli connection modify edge ipv4.method manual
sudo nmcli connection up edge

# Enable IP masquerading for edge network
sudo firewall-cmd --permanent --zone=public --add-masquerade
sudo firewall-cmd --reload

Storage Optimization for Edge

# Configure storage for edge workloads
# Create separate partition for K3s data
sudo fdisk /dev/sdb  # Create new partition

# Create XFS filesystem optimized for containers
sudo mkfs.xfs -f -L k3s-data /dev/sdb1
sudo mkdir -p /var/lib/rancher/k3s

# Mount with optimized options
echo "LABEL=k3s-data /var/lib/rancher/k3s xfs defaults,noatime,nodiratime 0 0" | sudo tee -a /etc/fstab
sudo mount -a

# Configure log rotation for edge
cat << EOF | sudo tee /etc/logrotate.d/k3s
/var/log/k3s.log {
    daily
    rotate 7
    compress
    missingok
    notifempty
    create 0640 root root
}
EOF

Installing K3s

Installing K3s Server (Control Plane)

# Install K3s server with custom configuration
curl -sfL https://get.k3s.io | sh -s - server \
    --write-kubeconfig-mode 644 \
    --disable traefik \
    --disable servicelb \
    --cluster-cidr 10.42.0.0/16 \
    --service-cidr 10.43.0.0/16 \
    --cluster-dns 10.43.0.10 \
    --kubelet-arg="max-pods=110" \
    --kubelet-arg="eviction-hard=memory.available<500Mi" \
    --kubelet-arg="eviction-soft=memory.available<1Gi" \
    --kubelet-arg="eviction-soft-grace-period=memory.available=2m" \
    --kube-controller-manager-arg="node-monitor-period=20s" \
    --kube-controller-manager-arg="node-monitor-grace-period=60s" \
    --data-dir /var/lib/rancher/k3s

# Verify installation
sudo systemctl status k3s
sudo k3s kubectl get nodes

# Get node token for agents
sudo cat /var/lib/rancher/k3s/server/node-token

Installing K3s Agents (Worker Nodes)

On each worker node:

# Set variables
K3S_URL="https://edge-gateway-01:6443"
K3S_TOKEN="K10c42a67d4b6d1b8c3f4e5a6b7c8d9e0f1::server:2a3b4c5d6e7f8g9h0i1j2k3l"

# Install K3s agent
curl -sfL https://get.k3s.io | K3S_URL=$K3S_URL K3S_TOKEN=$K3S_TOKEN sh -s - agent \
    --kubelet-arg="max-pods=110" \
    --kubelet-arg="eviction-hard=memory.available<300Mi" \
    --node-label="node-role.kubernetes.io/edge=true" \
    --node-label="edge.location/zone=warehouse-01"

# Verify agent
sudo systemctl status k3s-agent

Configuring kubectl Access

# Configure kubectl for local user
mkdir -p ~/.kube
sudo cp /etc/rancher/k3s/k3s.yaml ~/.kube/config
sudo chown $USER:$USER ~/.kube/config
chmod 600 ~/.kube/config

# Install kubectl bash completion
kubectl completion bash | sudo tee /etc/bash_completion.d/kubectl > /dev/null

# Test access
kubectl get nodes
kubectl get pods -A

Edge-Specific Configurations

Implementing Network Policies for Edge

# network-policy.yaml
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: edge-isolation
  namespace: edge-apps
spec:
  podSelector:
    matchLabels:
      tier: edge
  policyTypes:
  - Ingress
  - Egress
  ingress:
  - from:
    - namespaceSelector:
        matchLabels:
          name: edge-apps
    - podSelector:
        matchLabels:
          tier: edge
    ports:
    - protocol: TCP
      port: 8080
  egress:
  - to:
    - namespaceSelector:
        matchLabels:
          name: edge-apps
    ports:
    - protocol: TCP
      port: 443
  - to:
    - namespaceSelector:
        matchLabels:
          name: kube-system
    ports:
    - protocol: TCP
      port: 53
    - protocol: UDP
      port: 53

Resource Constraints for Edge

# resource-quota.yaml
apiVersion: v1
kind: ResourceQuota
metadata:
  name: edge-quota
  namespace: edge-apps
spec:
  hard:
    requests.cpu: "4"
    requests.memory: 8Gi
    limits.cpu: "8"
    limits.memory: 16Gi
    persistentvolumeclaims: "10"
    pods: "50"
---
apiVersion: v1
kind: LimitRange
metadata:
  name: edge-limit-range
  namespace: edge-apps
spec:
  limits:
  - max:
      cpu: "2"
      memory: "4Gi"
    min:
      cpu: "100m"
      memory: "128Mi"
    default:
      cpu: "500m"
      memory: "512Mi"
    defaultRequest:
      cpu: "200m"
      memory: "256Mi"
    type: Container

Deploying Edge Applications

IoT Data Collector

# iot-collector.yaml
apiVersion: v1
kind: Namespace
metadata:
  name: edge-apps
  labels:
    name: edge-apps
---
apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: iot-collector
  namespace: edge-apps
spec:
  selector:
    matchLabels:
      app: iot-collector
  template:
    metadata:
      labels:
        app: iot-collector
        tier: edge
    spec:
      nodeSelector:
        node-role.kubernetes.io/edge: "true"
      tolerations:
      - key: node-role.kubernetes.io/edge
        operator: Equal
        value: "true"
        effect: NoSchedule
      containers:
      - name: collector
        image: edge/iot-collector:v1.0
        resources:
          requests:
            memory: "128Mi"
            cpu: "100m"
          limits:
            memory: "256Mi"
            cpu: "500m"
        env:
        - name: MQTT_BROKER
          value: "tcp://localhost:1883"
        - name: COLLECTION_INTERVAL
          value: "10s"
        volumeMounts:
        - name: data
          mountPath: /data
        - name: config
          mountPath: /etc/collector
      - name: mqtt
        image: eclipse-mosquitto:2.0
        resources:
          requests:
            memory: "64Mi"
            cpu: "50m"
          limits:
            memory: "128Mi"
            cpu: "200m"
        ports:
        - containerPort: 1883
          hostPort: 1883
      volumes:
      - name: data
        hostPath:
          path: /var/edge/data
          type: DirectoryOrCreate
      - name: config
        configMap:
          name: collector-config
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: collector-config
  namespace: edge-apps
data:
  collector.yaml: |
    sensors:
      - id: temp-sensor-01
        type: temperature
        interval: 5s
        topic: sensors/temperature/warehouse
      - id: humidity-sensor-01
        type: humidity
        interval: 5s
        topic: sensors/humidity/warehouse
    processing:
      batch_size: 100
      compression: true
      encryption: true
    upstream:
      endpoint: https://cloud.example.com/api/v1/data
      retry_count: 3
      timeout: 30s

Edge ML Inference

# edge-inference.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: ml-inference
  namespace: edge-apps
spec:
  replicas: 1
  selector:
    matchLabels:
      app: ml-inference
  template:
    metadata:
      labels:
        app: ml-inference
        tier: edge
    spec:
      nodeSelector:
        kubernetes.io/arch: amd64
        node-role.kubernetes.io/edge: "true"
      containers:
      - name: inference
        image: edge/ml-inference:v1.0
        resources:
          requests:
            memory: "1Gi"
            cpu: "1"
          limits:
            memory: "2Gi"
            cpu: "2"
        env:
        - name: MODEL_PATH
          value: "/models/edge-model.onnx"
        - name: INFERENCE_THREADS
          value: "4"
        - name: BATCH_SIZE
          value: "1"
        volumeMounts:
        - name: models
          mountPath: /models
        - name: dshm
          mountPath: /dev/shm
        ports:
        - containerPort: 8080
          name: http
        livenessProbe:
          httpGet:
            path: /health
            port: 8080
          initialDelaySeconds: 30
          periodSeconds: 10
        readinessProbe:
          httpGet:
            path: /ready
            port: 8080
          initialDelaySeconds: 5
          periodSeconds: 5
      volumes:
      - name: models
        persistentVolumeClaim:
          claimName: model-storage
      - name: dshm
        emptyDir:
          medium: Memory
          sizeLimit: 1Gi
---
apiVersion: v1
kind: Service
metadata:
  name: ml-inference
  namespace: edge-apps
spec:
  selector:
    app: ml-inference
  ports:
  - port: 80
    targetPort: 8080
  type: NodePort

Video Analytics Pipeline

# video-analytics.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: video-config
  namespace: edge-apps
data:
  pipeline.yaml: |
    sources:
      - name: camera-01
        type: rtsp
        url: rtsp://192.168.1.100/stream
        fps: 15
      - name: camera-02
        type: rtsp
        url: rtsp://192.168.1.101/stream
        fps: 15
    analytics:
      - name: object-detection
        model: yolov5s
        confidence: 0.5
        classes: [person, vehicle]
      - name: motion-detection
        sensitivity: 0.7
        area_threshold: 100
    output:
      - type: mqtt
        topic: analytics/detections
        qos: 1
      - type: http
        endpoint: http://ml-inference/process
        batch: true
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: video-analytics
  namespace: edge-apps
spec:
  serviceName: video-analytics
  replicas: 1
  selector:
    matchLabels:
      app: video-analytics
  template:
    metadata:
      labels:
        app: video-analytics
        tier: edge
    spec:
      nodeSelector:
        node-role.kubernetes.io/edge: "true"
        edge.capability/gpu: "true"
      containers:
      - name: analytics
        image: edge/video-analytics:v1.0
        resources:
          requests:
            memory: "2Gi"
            cpu: "2"
            nvidia.com/gpu: 1  # If GPU available
          limits:
            memory: "4Gi"
            cpu: "4"
            nvidia.com/gpu: 1
        volumeMounts:
        - name: config
          mountPath: /etc/analytics
        - name: cache
          mountPath: /cache
        env:
        - name: CUDA_VISIBLE_DEVICES
          value: "0"
        - name: TF_FORCE_GPU_ALLOW_GROWTH
          value: "true"
      volumes:
      - name: config
        configMap:
          name: video-config
      - name: cache
        emptyDir:
          sizeLimit: 10Gi

Edge Storage Solutions

Local Path Provisioner

# Install local-path-provisioner for edge storage
kubectl apply -f https://raw.githubusercontent.com/rancher/local-path-provisioner/v0.0.24/deploy/local-path-storage.yaml

# Configure as default storage class
kubectl patch storageclass local-path -p '{"metadata": {"annotations":{"storageclass.kubernetes.io/is-default-class":"true"}}}'

Distributed Storage for Edge

# longhorn-edge.yaml
apiVersion: v1
kind: Namespace
metadata:
  name: longhorn-system
---
apiVersion: helm.cattle.io/v1
kind: HelmChart
metadata:
  name: longhorn
  namespace: kube-system
spec:
  repo: https://charts.longhorn.io
  chart: longhorn
  targetNamespace: longhorn-system
  createNamespace: true
  valuesContent: |-
    persistence:
      defaultClass: false
      defaultClassReplicaCount: 1
    csi:
      attacherReplicaCount: 1
      provisionerReplicaCount: 1
      resizerReplicaCount: 1
      snapshotterReplicaCount: 1
    defaultSettings:
      defaultReplicaCount: 1
      guaranteedEngineCPU: 0.1
      storageMinimalAvailablePercentage: 10
      upgradeChecker: false
      createDefaultDiskLabeledNodes: true
      defaultDataLocality: best-effort
      replicaZoneSoftAntiAffinity: false
      nodeDownPodDeletionPolicy: delete-both-statefulset-and-deployment-pod

Networking and Connectivity

5G/LTE Failover Configuration

# network-failover.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: network-monitor
  namespace: kube-system
data:
  monitor.sh: |
    #!/bin/bash
    PRIMARY_GW="192.168.1.1"
    LTE_INTERFACE="wwan0"
    CHECK_INTERVAL=10
    FAIL_COUNT=0

    while true; do
      if ! ping -c 1 -W 2 $PRIMARY_GW > /dev/null 2>&1; then
        FAIL_COUNT=$((FAIL_COUNT + 1))
        if [ $FAIL_COUNT -ge 3 ]; then
          echo "Primary network failed, switching to LTE"
          ip route del default
          ip route add default dev $LTE_INTERFACE
          FAIL_COUNT=0
        fi
      else
        FAIL_COUNT=0
      fi
      sleep $CHECK_INTERVAL
    done
---
apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: network-monitor
  namespace: kube-system
spec:
  selector:
    matchLabels:
      app: network-monitor
  template:
    metadata:
      labels:
        app: network-monitor
    spec:
      hostNetwork: true
      hostPID: true
      containers:
      - name: monitor
        image: alpine:3.18
        command: ["/bin/sh"]
        args: ["/scripts/monitor.sh"]
        securityContext:
          privileged: true
        volumeMounts:
        - name: scripts
          mountPath: /scripts
      volumes:
      - name: scripts
        configMap:
          name: network-monitor
          defaultMode: 0755

Edge-to-Cloud VPN

# wireguard-vpn.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: wireguard-config
  namespace: kube-system
data:
  wg0.conf: |
    [Interface]
    Address = 10.100.0.2/24
    PrivateKey = <EDGE_PRIVATE_KEY>
    ListenPort = 51820

    [Peer]
    PublicKey = <CLOUD_PUBLIC_KEY>
    Endpoint = cloud.example.com:51820
    AllowedIPs = 10.100.0.0/24, 10.43.0.0/16
    PersistentKeepalive = 25
---
apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: wireguard
  namespace: kube-system
spec:
  selector:
    matchLabels:
      app: wireguard
  template:
    metadata:
      labels:
        app: wireguard
    spec:
      hostNetwork: true
      initContainers:
      - name: sysctls
        image: busybox
        command:
        - sh
        - -c
        - |
          sysctl -w net.ipv4.ip_forward=1
          sysctl -w net.ipv6.conf.all.forwarding=1
        securityContext:
          privileged: true
      containers:
      - name: wireguard
        image: linuxserver/wireguard:latest
        securityContext:
          capabilities:
            add:
            - NET_ADMIN
            - SYS_MODULE
          privileged: true
        volumeMounts:
        - name: config
          mountPath: /config/wg0.conf
          subPath: wg0.conf
        - name: modules
          mountPath: /lib/modules
          readOnly: true
      volumes:
      - name: config
        configMap:
          name: wireguard-config
      - name: modules
        hostPath:
          path: /lib/modules

Edge Management and Monitoring

Lightweight Monitoring Stack

# monitoring-edge.yaml
apiVersion: v1
kind: Namespace
metadata:
  name: monitoring
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: prometheus
  namespace: monitoring
spec:
  replicas: 1
  selector:
    matchLabels:
      app: prometheus
  template:
    metadata:
      labels:
        app: prometheus
    spec:
      containers:
      - name: prometheus
        image: prom/prometheus:v2.45.0
        args:
        - '--config.file=/etc/prometheus/prometheus.yml'
        - '--storage.tsdb.path=/prometheus'
        - '--storage.tsdb.retention.time=7d'
        - '--storage.tsdb.retention.size=5GB'
        - '--web.enable-lifecycle'
        resources:
          requests:
            memory: "512Mi"
            cpu: "250m"
          limits:
            memory: "1Gi"
            cpu: "500m"
        volumeMounts:
        - name: config
          mountPath: /etc/prometheus
        - name: data
          mountPath: /prometheus
      volumes:
      - name: config
        configMap:
          name: prometheus-config
      - name: data
        persistentVolumeClaim:
          claimName: prometheus-data
---
apiVersion: v1
kind: ConfigMap
metadata:
  name: prometheus-config
  namespace: monitoring
data:
  prometheus.yml: |
    global:
      scrape_interval: 30s
      evaluation_interval: 30s
    scrape_configs:
    - job_name: 'kubernetes-nodes'
      kubernetes_sd_configs:
      - role: node
      relabel_configs:
      - source_labels: [__address__]
        regex: '(.*):10250'
        replacement: '${1}:9100'
        target_label: __address__
    - job_name: 'kubernetes-pods'
      kubernetes_sd_configs:
      - role: pod
      relabel_configs:
      - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_scrape]
        action: keep
        regex: true
      - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_path]
        action: replace
        target_label: __metrics_path__
        regex: (.+)

Edge Fleet Management

# fleet-manager.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: fleet-config
  namespace: kube-system
data:
  fleet.yaml: |
    clusters:
      - name: edge-warehouse-01
        endpoint: https://10.0.1.10:6443
        location: warehouse
        zone: us-east
      - name: edge-warehouse-02
        endpoint: https://10.0.2.10:6443
        location: warehouse
        zone: us-west
    sync:
      interval: 5m
      applications:
        - name: iot-collector
          version: v1.0
          targets: [warehouse]
        - name: ml-inference
          version: v1.0
          targets: [warehouse]
    monitoring:
      metrics_retention: 7d
      logs_retention: 3d
      alerts:
        - name: edge-offline
          condition: up == 0
          duration: 5m
          severity: critical
---
apiVersion: batch/v1
kind: CronJob
metadata:
  name: fleet-sync
  namespace: kube-system
spec:
  schedule: "*/5 * * * *"
  jobTemplate:
    spec:
      template:
        spec:
          containers:
          - name: sync
            image: edge/fleet-manager:v1.0
            command:
            - /bin/sh
            - -c
            - |
              for cluster in $(kubectl get configmap fleet-config -o jsonpath='{.data.fleet\.yaml}' | yq e '.clusters[].name' -); do
                echo "Syncing cluster: $cluster"
                kubectl --context=$cluster apply -f /manifests/
              done
            volumeMounts:
            - name: config
              mountPath: /etc/fleet
            - name: manifests
              mountPath: /manifests
          volumes:
          - name: config
            configMap:
              name: fleet-config
          - name: manifests
            persistentVolumeClaim:
              claimName: fleet-manifests
          restartPolicy: OnFailure

Security for Edge

Edge Security Policies

# edge-security.yaml
apiVersion: policy/v1
kind: PodSecurityPolicy
metadata:
  name: edge-restricted
spec:
  privileged: false
  allowPrivilegeEscalation: false
  requiredDropCapabilities:
    - ALL
  volumes:
    - 'configMap'
    - 'emptyDir'
    - 'projected'
    - 'secret'
    - 'downwardAPI'
    - 'persistentVolumeClaim'
  hostNetwork: false
  hostIPC: false
  hostPID: false
  runAsUser:
    rule: 'MustRunAsNonRoot'
  seLinux:
    rule: 'RunAsAny'
  supplementalGroups:
    rule: 'RunAsAny'
  fsGroup:
    rule: 'RunAsAny'
  readOnlyRootFilesystem: true
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: edge-restricted
rules:
- apiGroups: ['policy']
  resources: ['podsecuritypolicies']
  verbs: ['use']
  resourceNames:
  - edge-restricted

Certificate Management

# Install cert-manager for edge
kubectl apply -f https://github.com/cert-manager/cert-manager/releases/download/v1.12.0/cert-manager.yaml

# Create self-signed issuer for edge
cat << EOF | kubectl apply -f -
apiVersion: cert-manager.io/v1
kind: ClusterIssuer
metadata:
  name: edge-selfsigned
spec:
  selfSigned: {}
---
apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
  name: edge-ca
  namespace: cert-manager
spec:
  isCA: true
  commonName: edge-ca
  secretName: edge-ca-secret
  issuerRef:
    name: edge-selfsigned
    kind: ClusterIssuer
---
apiVersion: cert-manager.io/v1
kind: ClusterIssuer
metadata:
  name: edge-ca-issuer
spec:
  ca:
    secretName: edge-ca-secret
EOF

Backup and Disaster Recovery

Edge Backup Strategy

#!/bin/bash
# backup-edge.sh

# Backup K3s configuration
kubectl get all --all-namespaces -o yaml > k3s-resources-$(date +%Y%m%d).yaml

# Backup etcd (K3s embedded)
sudo k3s etcd-snapshot save --name edge-snapshot-$(date +%Y%m%d)

# Backup persistent volumes
for pv in $(kubectl get pv -o jsonpath='{.items[*].metadata.name}'); do
  echo "Backing up PV: $pv"
  # Implement your backup logic based on storage type
done

# Sync to cloud
aws s3 sync /var/lib/rancher/k3s/server/db/snapshots/ s3://edge-backups/$(hostname)/

Automated Recovery

# recovery-job.yaml
apiVersion: batch/v1
kind: Job
metadata:
  name: edge-recovery
  namespace: kube-system
spec:
  template:
    spec:
      containers:
      - name: recovery
        image: edge/recovery-tool:v1.0
        command:
        - /bin/sh
        - -c
        - |
          # Check cluster health
          if ! kubectl get nodes | grep -q Ready; then
            echo "Cluster unhealthy, initiating recovery"
            # Download latest backup
            aws s3 cp s3://edge-backups/$(hostname)/latest.db /tmp/
            # Restore etcd
            k3s etcd-snapshot restore /tmp/latest.db
          fi
      restartPolicy: OnFailure

Performance Optimization

Edge-Specific Optimizations

# Optimize K3s for edge
# Disable unnecessary controllers
sudo k3s server \
  --disable-cloud-controller \
  --disable-network-policy \
  --kube-controller-manager-arg="controllers=*,bootstrapsigner,tokencleaner,-attachdetach,-cloud-node-lifecycle" \
  --kubelet-arg="feature-gates=RotateKubeletServerCertificate=true" \
  --kubelet-arg="max-pods=50" \
  --kubelet-arg="pods-per-core=10"

# Configure aggressive image garbage collection
sudo k3s kubectl apply -f - <<EOF
apiVersion: v1
kind: ConfigMap
metadata:
  name: kubelet-config
  namespace: kube-system
data:
  config.yaml: |
    apiVersion: kubelet.config.k8s.io/v1beta1
    kind: KubeletConfiguration
    imageGCHighThresholdPercent: 70
    imageGCLowThresholdPercent: 50
    evictionHard:
      memory.available: "500Mi"
      nodefs.available: "10%"
    evictionSoft:
      memory.available: "1Gi"
      nodefs.available: "15%"
    evictionSoftGracePeriod:
      memory.available: "2m"
      nodefs.available: "2m"
EOF

Troubleshooting

Common Edge Issues

# Debug networking issues
kubectl run debug --image=nicolaka/netshoot -it --rm -- /bin/bash

# Check K3s logs
journalctl -u k3s -f

# Verify cluster connectivity
k3s check-config

# Reset node if needed
sudo k3s-killall.sh
sudo systemctl restart k3s

# Check resource usage
kubectl top nodes
kubectl top pods -A

# Debug DNS issues
kubectl run -it --rm debug --image=busybox --restart=Never -- nslookup kubernetes.default

Best Practices for Edge

Resource Management
- Set appropriate resource limits
- Use node selectors for workload placement
- Implement pod priority classes
Connectivity
- Plan for intermittent connectivity
- Implement local data caching
- Use message queuing for reliability
Security
- Minimize attack surface
- Use network policies
- Regular security updates
Monitoring
- Lightweight monitoring solutions
- Local alerting capabilities
- Efficient log management

Conclusion

You’ve successfully deployed a production-ready edge computing platform using K3s on Rocky Linux. This lightweight yet powerful solution enables you to run Kubernetes workloads at the edge, process data locally, and maintain reliable operations even in challenging environments.

The combination of Rocky Linux’s stability and K3s’s efficiency creates an ideal platform for edge computing scenarios, from IoT data processing to AI inference at the edge. Continue to adapt and optimize your edge deployment based on your specific use cases and requirements.
